Honeywell HCC485LX Manuel utilisateur

The Honeywell HCC485LX colour camera is ideally suited for use in day-to-day

surveillance applications. Designed for value, the HCC485LX saves time and

money with easy installation and reliable performance. Its off-the-shelf feature set

is developed for high-picture quality in standard applications and requires little to

no adjustment once installed.

The HCC485LX supports direct-drive and drive-style Auto Iris lenses to ensure

quality video even in fluctuating light conditions. Regardless of lens type,

attaching a lens to the camera is simple with a built-in C/CS mounting ring and

four-pin Auto Iris connector standard. A 2-pin appliance coupler and matching

cord set provide reliable power connection, saving installation and maintenance

time.

The HCC485LX includes an automatic electronic shutter for changes in light level,

and an automatic backlight compensation option for viewing objects in the

foreground with bright light in the background. A manual exposure mode can be

used for applications, such as machine vision, that require a constant shutter

speed at all times. The HCC485LX produces 480 TV lines of resolution to provide

reliable video quality even in low-light conditions down to 0.40 lux.

Market Opportunities

The Honeywell HCC485LX is designed for general cost-effective, high-resolution

surveillance applications where a colour image and object identification and

recognition are required. This includes general indoor surveillance applications

in retail, educational, financial, and other commercial markets. Combined with

the AVH environmental housing, the HCC485LX can be used as a solution

for outdoor applications, such as car parks, building entranceways,

and driveways.

Features

HCC485LX

• 1/3" colour CCD with DSP

• 480 TV lines of resolution

• Low-light performance 0.40 lux (F1.2)

• Automatic Electronic Shutter (AES)

• Manual Exposure Mode for setting

shutter speed

• Automatic Backlight Compensation

(BLC)

• 230 with line lock

• C/CS lens mount

• DC, Video and Manual Iris

lens support

HIGH RESOLUTION COLOUR CAMERA

HCC485LX

SPECIFICATIONS

Video Standard PAL

Scanning System 625/50 lines

Image Sensor 1/3" Interline Transfer CCD

Number of Pixels

(H x V) 752 x 582

Minimum Illumination 0.40 lux @ F1.2

Horizontal Resolution 480 TVL

Video Output 1.0 Vp-p @ 75 Ohms

Sync System 230 VAC: Line lock

S/N Ratio >50

Auto Gain Control On/off

ALC Variable Iris control for DC drive lenses

Automatic Electronic

Shutter 1/50 – 1/100,000 sec

Manual Electronic

Shutter 1/50 – 1/100,000 sec

Lens Iris Control DC drive/Video drive

White Balance ATW/AWB/Manual/Fixed

Line Lock Phase

Adjust Adjustable AC Line lock

BLC On/off

Electrical

Voltage Input 230 VAC

Input Range 207 - 253 VAC

Surge Suppression 1.5 kW transient

Power Consumption 4.2 W

Mechanical

Dimensions

(W x H x D) 68 mm x 56 mm x 140 mm

Weight 0.41 kg camera only

Construction Housing: Aluminium

Finish: Cool grey powder coat

Camera Mount 1/4 - 20 UNC mounting shoe

Lens Mount C/CS adjustable mounting ring

Connector

Video Output: BNC connector

Lens: 4-pin connector

Power Input: 2-pin appliance coupler

Power Indicator Green LED indicates Power On

Accessories:

Recommended Lens Options

HLD28V8F95L 2.8 - 8 mm, F0.95, DC Auto Iris lens

HLD27V13DNL 2.7 - 13.5 mm, F1.3, DC Auto Iris lens

HLD5V50F13L 5.0 - 50 mm, F1.3, DC Auto Iris lens

Environmental

Temperature Operating: -10°C to 50°C

Storage: -20°C to 70°C

Regulatory

Relative Humidity 20% to 80%, non-condensing

Emissions CE (EN55013)

Immunity CE (EN50130-4)

Safety EV: 73/23/EEC LVD

Ordering

HCC485LX 1/3" CCD, High-Resolution Colour Camera with DSP, 480 TVL, 230 VAC, PAL

NOTE: Honeywell reserves the right, without notification, to make changes in product design or specifications.

Housing and Mounts

AVH530SH5 Housing - 110-240VAC, Aluminium,

sunshield

AVH500WMB Wall bracket - standard

AVH500CMB Wall bracket - cable management

HVS-HCC485LX-01-EN(0807)DS-COE

August 2007

Honeywell Security

Honeywell Video Systems

Aston Fields Road

Whitehouse Industrial Estate

Runcorn

Cheshire WA7 3DL

Tel: 08448 000 235

Fax: +44 (0) 1928 701063

Email: [email protected]

www.honeywell.com/security/uk

Operational

PWR

VSD

VIDEO

~207-253VAC 50HZ

REMOTE UP

DOWN

2.68” (68 mm)

1.18” (30 mm)

0.25”

(6.5 mm) 2.2”(56 mm)

4.69” (119.3 mm)

0.9” (23 mm)

Ø2.15” (Ø54.7 mm)

0.35”

(9 mm)

Front View Rear View

Side View
