Honeywell GKP Manuel utilisateur
Installer Programming mode User Programming mode Master User Programming
mode
GKP advanced functionalities
Version V1.0
Author: Florent Busnoult, EMEA Residential Sales Support EMEA, HSF
Date: 15/11/2016
© 2015 by Honeywell International Inc. All rights reserved.
9
Recap’
1
Installer
Procedure Sucrebox Domonial
Step by step guide
Set
arming with
identification
Here
Set quick
arming Here
Associate a TAG to a
user
Here
Change a user’s code
Here
Disable a user’s code
Here
Disable a user
Here
Enable a user
Here
© 2015 by Honeywell International Inc. All rights reserved.
9
Recap’
1
Master User
Adjust beep volume
Here
Enable Chime
Here
Disable Chime
Here
Assign TAG
Here
Changing
Code
Here
Disabling
Code
Here
Enable user
Here
Disable user
Here
User
Procedure Sucrebox Domonial
Step by step guide
© 2015 by Honeywell International Inc. All rights reserved.
9
Set arming with identification
1
3 -Press “Total arming” button to select function
4 -Press to activate arming with identification (code and TAG)
Installer Programming mode
Enter the installer programming mode
1 -Press simultaneously the two buttons “1” and “3” more than 2
seconds and release them.
A double beep is played and all Status LEDs light up.
2 -Enter installer’s code. On sucrebox: 001234
All Status LEDs start flashing and a long beep is played
5 -Press (⑤to exit programming and save your changes
All LEDs stop flashing and a double beep is played
© 2015 by Honeywell International Inc. All rights reserved.
9
Set quick arming (no identification needed)
1
3 -Press “Total arming” button to select function
4 -Press to activate quick arming
Installer Programming mode
Enter the installer programming mode
1 -Press simultaneously the two buttons “1” and “3” more than 2
seconds and release them.
A double beep is played and all Status LEDs light up.
2 -Enter installer’s code. On sucrebox: 001234
All Status LEDs start flashing and a long beep is played
5 -Press (⑤to exit programming and save your changes
All LEDs stop flashing and a double beep is played
© 2015 by Honeywell International Inc. All rights reserved.
9
Associate a TAG to a user
1
3 -Press “0 to 9” button to select user’s number
4 -Present the TAG to the tag reader
Installer Programming mode
Enter the installer programming mode
1 -Press simultaneously the two buttons “1” and “3” more than 2
seconds and release them.
A double beep is played and all Status LEDs light up.
2 -Enter installer’s code. On sucrebox: 001234
All Status LEDs start flashing and a long beep is played
5 -Press (⑤to exit programming and save your changes
All LEDs stop flashing and a double beep is played
© 2015 by Honeywell International Inc. All rights reserved.
9
Change a user’s code
1
3 -Press “0 to 9” button to select user’s number
4 -Enter new user’s code (4 or 6 digits)
5 -Re-enter new user’s code
Installer Programming mode
Enter the installer programming mode
1 -Press simultaneously the two buttons “1” and “3” more than 2
seconds and release them.
A double beep is played and all Status LEDs light up.
2 -Enter installer’s code. On sucrebox: 001234
All Status LEDs start flashing and a long beep is played
6 -Press (⑤to exit programming and save your changes
All LEDs stop flashing and a double beep is played
© 2015 by Honeywell International Inc. All rights reserved.
9Disable a user’s code (disable the code for a user and keep the
TAG only)
1
3 -Press “0 to 9” button to select user’s number
4 -Enter 0000 (or 000000 if 6 digits)
5 -Press
Installer Programming mode
Enter the installer programming mode
1 -Press simultaneously the two buttons “1” and “3” more than 2
seconds and release them.
A double beep is played and all Status LEDs light up.
2 -Enter installer’s code. On sucrebox: 001234
All Status LEDs start flashing and a long beep is played
6 -Press (⑤to exit programming and save your changes
All LEDs stop flashing and a double beep is played
© 2015 by Honeywell International Inc. All rights reserved.
9
Disable a user
1
3 -Press “0 to 9” button to select user’s number
4 -Press to disable the user (code and TAG)
Installer Programming mode
Enter the installer programming mode
1 -Press simultaneously the two buttons “1” and “3” more than 2
seconds and release them.
A double beep is played and all Status LEDs light up.
2 -Enter installer’s code. On sucrebox: 001234
All Status LEDs start flashing and a long beep is played
5 -Press (⑤to exit programming and save your changes
All LEDs stop flashing and a double beep is played
© 2015 by Honeywell International Inc. All rights reserved.
9
Enable a user
1
3 -Press “0 to 9” button to select user’s number
4 -Press to enable the user (code and TAG)
Installer Programming mode
Enter the installer programming mode
1 -Press simultaneously the two buttons “1” and “3” more than 2
seconds and release them.
A double beep is played and all Status LEDs light up.
2 -Enter installer’s code. On sucrebox: 001234
All Status LEDs start flashing and a long beep is played
5 -Press (⑤to exit programming and save your changes
All LEDs stop flashing and a double beep is played
