Honeywell 10282 Manuel utilisateur

BLUFTON 52” CEILING FAN

MODEL #10282, 10283

Questions, problems, missing parts? Before returning to your retailer, call our customer

service department at 1-877-361-3883, Monday - Thursday, 8 am - 6 pm, EST and Friday,

8 am - 5 pm, EST.

Español p. 20

RATED FOR

DAMP LOCATIONS

WELCOME

PREPARATION

Before beginning the assembly of this product,

ensure all parts are present. Compare all parts with

the package contents list and hardware contents list.

If any part is missing or damaged, do not attempt to

assemble the product.

After opening the top of the carton, remove the

mounting hardware package from the foam inserts,

then remove the motor from the packaging and place it

on a soft surface, such as a carpet, to avoid damage to

the nish.

Estimated Assembly Time: Approximately 120 minutes

Tools Required for Assembly (not included): Electrical

Tape, Phillips Screwdriver, Pliers, Safety Glasses, Step

Ladder, and Wire Strippers

Helpful Tools (not included): AC Tester Light, Tape

Measure, Wiring Handbook, and Wire Cutters

CARE AND MAINTENANCE

At least twice each year, lower the canopy to check the

downrod assembly, and then tighten all screws on the

fan. Clean the motor housing with only a soft brush or

lint-free cloth to avoid scratching the nish. Clean the

blades with a lint-free cloth.

Important: Shut off the main power supply before you

begin any maintenance tasks. Do not use water or a

damp cloth to clean the ceiling fan.

FAN WEIGHT

The net weight of this fan is: 15.97 lbs. (7,24 kg).

TABLE OF CONTENTS

ATTACH YOUR RECEIPT HERE

Serial Number

Purchase Date

Care and Maintenance ........................2

Package Contents ...........................3

Safety Information ...........................4

Mounting Options ............................5

Mounting Bracket Installation ...................6

Standard or Angle Mounting Instructions . . . . . . . . . .7

Closemount Instructions......................10

Wiring ....................................11

Canopy Installation..........................12

Blade Installation ...........................13

Light Kit Installation .........................14

Operating Instructions .......................16

Replacement Parts List ......................17

Troubleshooting ............................18

Limited Lifetime Warranty.....................19

PACKAGE CONTENTS

Unpack your fan and check the contents. You

should have the following items:

1. Blade (5)

2. Downrod

3. Downrod Pin

4. Downrod Clip

5. Yoke Cover

6. Switch Housing Cap

7. Plug Button

8. Blade Arm (5)

9. Canopy

10. Mounting Bracket

11. Canopy Cover

12. Motor Assembly

13. Switch Housing

14. Light Kit

15. Bulbs (2)

16. Glass Bowl

17. Loose parts bag (not shown) containing:

Mounting hardware, blade attachment

hardware, pull chain extensions, wire

connectors, etc.

18. Owner’s Manual (not shown)

SAFETY INFORMATION

Please read and understand this entire manual before attempting to assemble, operate, or install the product.

• Before you begin installing the fan, disconnect the power by removing fuses or turning off the

circuit breakers.

• Make sure that all electrical connections comply with local codes, ordinances, the National Electrical

Code, and ANSI/NFPA 70-199. Hire a qualied electrician or consult a do-it-yourself wiring handbook if

you are unfamiliar with installing electrical wiring.

• Make sure the installation site you choose allows a minimum clearance of 7 ft. (2,14 m) from the blades

to the oor and at least 30 in. (76 cm) from the end of the blades to any obstruction.

DANGER

WARNING

When using an existing outlet box, make sure

the outlet box is securely attached to the building

structure and can support the full weight of

the fan. Failure to do this can result in serious

injury or death. The stability of the outlet box is

essential in minimizing wobble and noise in the

fan after installation is complete.

To reduce the risk of re or electric shock, do not

use the fan with any solid-state speed-control

device or control the fan speed with a full-range

dimmer switch.

To reduce the risk of re, electric shock, or personal

injury, mount the fan to an outlet box marked

“ACCEPTABLE FOR FAN SUPPORT” and use the

mounting screws provided with the outlet box. Most

outlet boxes commonly used for the support of

lighting xtures are not acceptable for fan support

and may need to be replaced. Consult a qualied

electrician if in doubt. Secure the outlet box directly

to the building structure. The outlet box and its

support must be able to support the moving weight

of the fan, at least 35 lbs. (15,88 kg).

WARNING

CAUTION

To reduce the risk of re, electric shock, or

personal injury, do not bend the blade arms

when installing them, balancing the blades, or

cleaning the fan. Do not insert objects between

the rotating fan blades.

Read all instructions and safety information

before installing your new fan. Review the

accompanying assembly diagrams.

Be sure the outlet box is properly grounded or

that a ground (green or bare) wire is present.

WARNING

If using the fan in a damp location, the fan must

be connected to a supply circuit that is

protected by a Ground Fault Circuit Interrupter

(GFCI) to reduce the risk of personal injury,

electrical shock or death.

! !

MOUNTING OPTIONS

Fig. 1

Fig. 2

Fig. 3

1. Your fan has 3 mounting options:

• Standard (Fig. 1)

• Angle (Fig. 2)

• Closemount (Fig. 3)

Note: The fans in gures 1 through 3 are not the

actual fan in your package, they are representation

of the 3 different mounting options.

Important: If using the angle mount, check to

ensure the ceiling angle is not steeper than 16°.

Standard mounting is best suited for ceilings 8 ft.

or higher. For taller ceilings you may want to use a

longer downrod (sold separately).

Angle mounting is best suited for angled or vaulted

ceilings. A longer downrod is sometimes necessary

to ensure proper blade clearance.

Closemount is more suitable for ceilings lower than

8 ft. (2,44 m) high.

2. Ensure the blades of the fan are at least 30 in.

(76 cm) from any obstruction.

3. Check the downrod length to ensure the blades will

be at least 7 ft. (2,14 m) above your oor.

6. Secure the mounting bracket to the outlet box using

screws, spring washers, and at washers provided

with the outlet box (not included) (Fig. 6).

Note: It is very important to use proper hardware

when installing the mounting bracket as it supports

the fan.

Important: If using the angle mount, ensure the

open end of the mounting bracket is installed facing

the peak of the ceiling.

Fig. 5

Fig. 6

Mounting

Bracket

Screws

Mounting

Bracket

Canopy

Mounting Bracket

Screw

5. Loosen all four mounting bracket screws and

completely remove the two mounting bracket

screws from the round holes of canopy. Set aside

for later use. Detach mounting bracket from canopy

(Fig. 5).

Fig. 4

4. Turn off the circuit breakers and wall switch leading

to the fan wire leads (Fig. 4).

WARNING

Failure to disconnect the power supply prior to

installation may result in serious injury or death.

! !

MOUNTING BRACKET INSTALLATION

Set Screw

STANDARD OR ANGLE MOUNTING INSTRUCTIONS

8. Remove the downrod clip and downrod pin from

the downrod (Fig. 8). Downrod

Clip

Downrod

Fig. 8

Fig. 7

Fig. 9

Downrod

Canopy

Yoke

Cover

Downrod Pin

Downrod Clip

9. Insert the downrod through the canopy and yoke

cover. Feed the wires from the fan through the

downrod (Fig. 9).

7. Partially loosen the two set screws in the yoke at

the top of the motor housing (Fig. 7).

Fig. 11

Cut Wires

Yoke

Setscrew

STANDARD OR ANGLE MOUNTING INSTRUCTIONS

10. Slide the downrod into the yoke of the motor

assembly, align the holes, and reinstall the

downrod pin and downrod clip. Then retighten the

two set screws (Fig. 10).

11. Depending on the length of downrod you use, you

may need to cut the lead wires back to simplify the

wiring. If you decide to cut back the lead wires,

it is suggested that you do so in the following

manner: Take the lead wires and make sure that

you have pulled them all the way through the top

of the downrod and measure 8 in. of lead wire, and

then cut the excess wire off with wire cutters (not

included) (Fig. 11).

12. If you decided to cut back the lead wire in Step 11,

strip 1/2 in. of insulation from the end of the white

wire. Twist the stripped ends of each strand of

wire within the insulation with pliers (not included)

(Fig. 12).

Note: If you did not cut back the lead wires in

Step 11, Step 12 is not necessary and you may

proceed to Step 13 instead.

Downrod

Pin Downrod

Clip

Fig. 10

Fig. 12

Stripped

Wires

Slot

Tab

STANDARD OR ANGLE MOUNTING INSTRUCTIONS

13. Install the ball end of the downrod into the

mounting bracket opening. Align the slot in the ball

with the tab in the mounting bracket. The downrod

should not rotate if installed correctly (Fig. 13).

Mounting

Bracket Downrod

Ball

Fig. 13

WARNING

Failure to align the slot in the downrod with the tab

on the mounting bracket could cause the fan to fall,

which could result in serious injury or death.

Closemount

Screws

Fig. 15

CLOSEMOUNT INSTRUCTIONS

16. Lift the fan and place the hole in the canopy on the

mounting bracket hook during the wiring process

(Fig. 16).

Canopy

Hook

Canopy

Cover

Fig. 14

Fig. 16

14. Remove the canopy cover from the bottom of the

canopy (Fig. 14).

Helpful Hint: The downrod, canopy cover and

yoke cover are not used in this type of installation.

Closemount Screw

15. Align the canopy with the holes in the top of motor

assembly. Then, secure the canopy to the top of

the motor assembly using the three closemount

screws from the hardware bag (Fig. 15).
