Honeywell Dolphin
99EX 99GX Quick Start
THIS DOWNLOAD APPLIES TO THE FOLLOWING
Dolphin 99EX
Dolphin 99GX
Dolphin™99EX/99GX
with Windows
®
Embedded Handheld 6.5
Quick Start Guide
Disclaimer
Honeywell International Inc. (“HII”) reserves the right to
make changes in specifications and other information
contained in this document without prior notice, and the
reader should in all cases consult Honeywell to determine
whether any such changes have been made. The
information in this publication does not represent a
commitment on the part of HII.
HII shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or
consequential damages resulting from the furnishing,
performance, or use of this material.
This document contains proprietary information that is
protected by copyright. All rights are reserved. No part of
this document may be photocopied, reproduced, or
translated into another language without the prior written
consent of HII.
Web Address: www.honeywellaidc.com
Trademarks
Dolphin and HomeBase are trademarks or registered
trademarks of Hand Held Products, Inc. or Honeywell
International Inc. Microsoft, Windows, Windows Mobile,
Windows Embedded Handheld, Windows 7, Windows Vista,
Windows XP, Windows Mobile Device Center, ActiveSync,
and the Windows logo are trademarks or registered
trademarks of Microsoft Corporation. TORX is a trademark
or registered trademark of Textron Inc. Other product
names or marks mentioned in this document may be
trademarks or registered trademarks of other companies
and are the property of their respective owners.
©2011 Honeywell International Inc. All rights reserved.
1
This documentation is relevant for the following Dolphin
models: 99EXL0, 99EXLW, 99EXLG, 99GXL0, and
99GXLG.
Out of the Box
Verify that the carton contains the following items:
• Dolphin mobile computer (the terminal)
• Main battery pack
• Quick Start Guide
Note: If you ordered accessories for your terminals, verify that they
are also included with the order.
Be sure to keep the original packaging in the event that the
Dolphin terminal should need to be returned for service.
99EX/99GX Models
Dolphin 99EX and 99GX model terminals are designed
for use with standard battery pack model 99EX-BTSC
(Li-poly 3.7V, 11.3 watt hour) and extended battery pack
99EX-BTEC (Li-ion 3.7V, 18.5 watt hour) manufactured
for Honeywell International Inc.
Dolphin 99EX and 99GX model terminals are not
designed for use in hazardous locations.
!
2
Front and Side Panel
Note: Your Dolphin model may differ from the models illustrated;
however, the features are standard for all 99EX/99GX
models unless otherwise noted.
Power Key
Front Speaker
Navigation Keys
Microphone
General
Notification
LED
Touch Panel Display
Volume
Button
Right Button
Scan Key
Charge Indicator LED
Rear Speaker
(99GX only)
Lanyard Strap
(99GX only)
Scan Trigger
(99GX only)
Handle
(99EX only)
I/O Connector
3
Back Panel
Left Button
IRDA Port
Battery Door
StylusFastener
Hand Strap
(99EX only)
Stylus
Slot
ProtectiveSIM/Memory
CardDoor
Rear Speaker
Flashlight/Camera
Flash (99EX only)
Color Camera
(99EX only)
Image/Scan Engine
Window
BatteryWell
Battery Door Release
T6TORX®
Screw
Hand Strap Hook
(99EX only)
4
Available Keyboards
Note: The flashlight function ( ) is disabled on all 99GX
models.
1
SCAN
VOL
PG
TAB
ESC
SEND END
ENT
☼
3
456
7
.
+-/\
;—
:
0,#
*@
89
DEF
GHI JKL MNO
PQRS TU V WXYZ
F1
F5 F2
F6 F3
F7 F4
F8
SFT SP BKSP DEL
ALT
CTRL ALPHA
2ABC
7
SCAN
VOL PG
TAB
ESC
SEND END
ENT
☼
9
456
1
.
+-/\
;:—
0,#
@
*
23
F1
F5 F2
F6 F3
F7 F4
F8
SFT SP BKSP DEL
ALT
CTRL ALPHA
8DEF
GHI JKL MNO
PQRS TU V WXYZ
ABC
34-Key Numeric
(Calculator) Keyboard
34-Key Alpha/Numeric
Keyboard
5
ALT
CTRL
NUM
AB C D E
F G H I J
K L M N O
P Q R S T
UVWX Y
Z
1
+
@
#
*
F1 F2 F3 F4 F5
F6 F7 F8 F9 F10
F15F14F13F12F11
F17 F18 F19 F20F16
F21 F22 F23 F24 F25
23
456
789
.0
SFT SP
BKSP
,
SCAN
VOL PG
TAB
ESC
SEND END
ENT
☼
ALT
CTRL
A
123
456
789
0
BCDE
FGH IJ
KL MNO
PQRST
UVWX Y
Z
SFT
#
!
?
;
@
$&
—
~`
.
,
*
F6 F7 F8 F9 F10
F15F14F13F12F11
F17 F18 F19 F20F16
F21 F22 F23 F24 F25
BKSP
SP
DEL
+
-()
=
:
‘
SCAN
VOL PG
TAB
ESC
ENT
☼
F1 F2 F3 F4 F5
55-Key Full Alpha/
Numeric Keyboard
43-Key Alpha/Numeric
Keyboard
6
Install the Main Battery Pack
The 99EX/99GX is shipped with the battery packaged
separate from the terminal. Follow the steps below to
install the main battery. For information on how to remove
the battery, see page 6.
Ensure all components are dry prior to placing the battery
in the terminal. Mating wet components may cause
damage not covered by the warranty.
1. Release the hook securing the hand strap to the back
panel of the terminal (99EX only).
2. Remove the battery door by lifting up the latches near
the base of the battery door.
3. Insert the battery into the battery well.
4. Replace the battery door. Apply pressure to engage
the door latch. The battery door must be installed
prior to powering the unit.
5. Reattach the hand strap (99EX only).
6. Connect the terminal to one of the 99EX series
charging peripherals to charge the main battery pack.
We recommend use of Honeywell Li-poly or Li-ion
battery packs. Use of any non-Honeywell battery may
result in damage not covered by the warranty.
!
2
3
!
7
Removing the Main Battery Pack
When removing a battery from the terminal, put the device
in Suspend Mode (see page 9) before removing the
battery door. Once the battery door is removed, wait at
least 3 seconds before removing the main battery. This
process allows the device to shut down properly and to
maintain memory during the battery swap.
Battery Error Notification
If your terminal displays the following indicators, replace
the battery with a new Honeywell battery pack.
• appears in the Title bar at the top of the touch panel
display.
• The General Notification LED flashes red.
• A notification appears on the Tile bar at the bottom of
the touch panel display.
Battery Pack Use and Disposal
The following are general guidelines for the safe use and
disposal of batteries:
• Do not disassemble or open, crush, bend or deform,
puncture or shred.
• Do not modify or remanufacture, attempt to insert
foreign objects into the battery, immerse or expose to
water or other liquids, expose to fire, explosion or other
hazard.
• Improper battery use may result in a fire, explosion or
other hazard.
