Honeywell MF08CESWW Manuel utilisateur

OWNER’S MANUAL

Read these instructions before use

Voltage rating: 120V~60Hz

Power rating : 800W

Portable Air Conditioner

Model: MF08CESWW

Customer Support : 1-800-474-2147

For product inquiries or support : www.honeywellportableac.com Made in China

MODE ALARM

For service questions, contact Honeywell at 1-800-477-0457.

For sales inquiries, contact Sylvane at 1-800-934-9194 or visit

www.sylvane.com.

THANK YOU.....................................................................................................

INDEX .............................................................................................................. 1

USER TIPS........................................................................................................

SAFETY ............................................................................................................

PARTS DESCRIPTION.....................................................................................

INSTALLATION.................................................................................................

USE & OPERATION..........................................................................................

CLEANING & MAINTENANCE..........................................................................

TROUBLESHOOTING GUIDE...........................................................................

WATER CONDENSATION DRAINAGE............................................................

TECHNICAL SPECIFICATIONS.........................................................................

SERVICE AND WARRANTY .............................................................................

10.

11.

12.

SECTION PAGE

INDEX

Read all instructions carefully before setting up and operating the unit. Keep this

instruction manual for future reference. This manual is designed to provide important

information needed to setup, operate, maintain and troubleshoot your portable air

conditioner. Failure to follow these instructions may void the warranty.

THANK YOU

Congratulations on your purchase of this versatile Honeywell Portable Air Conditioner.

Honeywell Portable Air Conditioners are ideal for spot cooling. The compressor, condenser

and evaporator are housed in a compact unit. The air is filtered, dehumidified and cooled while

a flexible air outlet hose sends heat outside. The air conditioner includes a window venting kit.

No permanent installation is needed. The unit is easy to move from room to room and offers a

truly flexible air conditioning solution.

Auto Evaporation System - The unit automatically evaporates the condensate through the air

outlet hose. There is no need to empty the drainage tank except in very high humidity conditions.

Read and follow the instructions carefully.

Cooling, Dehumidifying function Fan function

Important : After transporting the unit, place it UPRIGHT for 20 min.

before use to allow the refrigerant to stabilize.

Follow installation instructions to set up the unit.

Plug the unit into a properly grounded circuit.

To ensure optimal efficiency of the product, keep doors and windows closed when it

is used as an air conditioner or dehumidifier.

If the product is being used with the fan function only, an open window could improve

air circulation.

USER TIPS

MODE ALARM

SAFETY

READ AND SAVE THESE INSTRUCTIONS

Improper handling can cause serious damage to the appliance.

WARNING

DO NOT operate the unit with a damaged plug or loose socket point. If the power

cord is damaged, it must be replaced by the manufacturer or an authorized service agent.

DO NOT cover the air intake and exhaust when in use.

This appliance is not intended for use by children. Children should be supervised

and should not play on or around the appliance.

DO NOT place objects on or sit on the unit.

Always turn off and unplug the unit when cleaning or servicing.

If service is needed contact an authorized service agent.

Unplug the unit when stored or not in use.

SAFETY

DO NOT run the power cord under carpeting and rugs.

10.

11. Basic safety precautions should always be followed when using electrical appliances.

Use caution to prevent tripping on cord.

DO NOT use in areas where gasoline, paint or other flammable goods are stored.

PARTS DESCRIPTION

124

x 1

x 2 x 1

Installation Kit :

1. Window Bracket Kit.............................

2. Window Bracket Panel Adapter..........

3. Plastic Screws....................................

4. Hose Connector..................................

5. Plastic Hose........................................

1 Set

1 Piece

2 Pieces

1 Piece

Mode

Down

1. Control Panel ( Incl. Signal Receptor)

2. Air Outlet

3. Handle

4. Casters

5. Air Filter

6. Back Grill

7. Water Drain Cap (Air Conditioning Mode)

8. Power Supply Cord

9. Exhaust Hose Connector

10. Remote Control

MODE ALARM

ON/OFF

FanSpeed

Timer

Install the plastic hose with window bracket adapter and hose connector on both sides.

Ensure proper fit on both ends.

Adjust the window bracket as per width or height of your window and insert a plastic screw

to fix at the desired position.

Connect the plastic hose to the hose connector on back of the unit.

Note : Do not install the window

bracket to your window. This step

is required only to adjust it to the

size of your window. The bracket

should be removed from the window

after the size is adjusted.

Plastic Screw

INSTALLATION

Push-in Rotate

For service questions, contact Honeywell at 1-800-477-0457.

For sales inquiries, contact Sylvane at 1-800-934-9194 or visit

www.sylvane.com.

Connect the window bracket to the opposite end of the plastic hose. Ensure that

connections are tight and installed properly.

Connect the window bracket to the window.

The Portable Air Conditioner is now ready to use.

INSTALLATION

MODE ALARM

Note:

1. The supplied exhaust hose can be extended from 12 inches (1 foot) to 47 inches

(3.9 feet).

2. Do not bend (to the extent shown below) the exhaust hose.

A bent hose will block exhaust air and cause the unit to malfunction or shut-off.

Warning:

• The length of the exhaust hose is designed acording to the product specifications.

Do not replace or lengthen it with any other pipe or hose as this could cause the

unit to malfunction.

• Make sure the back of the unit is at least 20 inches away from a wall.

Do not place the unit in front of curtains or drapes as this could obstruct the airflow.

INSTALLATION

RECOMMENDEDNOT RECOMMENDED

MIN.

20”

35 cm

MAX. 100 cm
