Holux 240 Manuel utilisateur

Quick Guide

Accessories

Standard Optional

Holux Wireless GPS

Receiver x 1

2-piece Car Charger x 1

Tool CD x 1

Quick Guide x 1

Warranty Card x 1

1. USB data cable

(Data cable can be used for data transfer

between and Notebook / PC.)

Wireless Bluetooth GPS

Instructions for First Use

1. Charge the Battery

2. Switch on the Power

3. Establish Bluetooth Link

ou can charge the battery with one of the following

two ways:

A: Car charger: provides connection between the GPS Receiver

and the vehicle via mini USB connector by plugging the car-charge

adaptor into the power/ cigarette lighter outlet.

B. USB adaptor that comes with the charger or other USB data

cables: provide direct connection to the mini USB port on the

receiver, while the other end is connected to the PC or notebook fo

both battery charging as well as data transmission.

zNote: The direction of the mini USB connector

zSlide the power switch to the

ON position.

To link the receiver with a PDA (Personal Digital

Assistant), follow these steps:

•Activate the Bluetooth Manager, select

Search and then link.

•Select the HOLUX icon and choose

SPP slave to establish the Bluetooth link.

•Refer to the “Software Installation” section in

the user manual for further details if you have

Note about Bluetooth Connection

When you power on the , you must wait five seconds for Bluetooth to

self-test before a connection is established. Wait until the Bluetooth light

begins to flash (once every second). A Bluetooth link can now be established

between a PDA and the .

4. Install and Open the GPS Viewer

Warning

Do not place the under strong sunlight for a long time. Do not

place it in a high-temperature environment, or near heat radiating

devices such as a stove or radiator. Doing so will cause the device to

malfunction. For further information, refer to the user manual that comes

on the supplied CD.

[Notes]

1. It is prohibited to operate this system while driving your car.

2. GPS signals are unable to go through non-transparent objects, such

as tall buildings, tunnels, underpasses, and forests. Bad weather may

also effect the signal reception. If your car window heat shield contains

metal, the receiver will not be able to pick up GPS signals.

3. All wireless communication products, such as mobile phones and

speed limit warning systems will interfere with the communication

satellite and will affect signal reception.

4.Before you setting, while the car is stationary, ensure that you have

searched for and fixed your position using the positioning function.

•You can install the GPS viewer program from

the supplied CD to check current positioning

and satellite signal reception.

•Activate the GPS Viewer, set the Baud Rate to

38400, and press Scan for automatic

scanning. Once you find the correct COM port,

choose GPS status to start viewing.

•Refer to the “Software Installation” section for

5. For further information, please read the user’s manual in the supplied

CD.

6. PASSKEY – 0000

(For security, some PDAs will prompt users for the Passkey)
