Holley EFI Digital Dash

User Manual

CONTENTS

Introduction ........................................................................................................................................... 4

Quick Start Guide .................................................................................................................................. 5

Package Contents ................................................................................................................................. 5

Specifications ........................................................................................................................................ 5

General .......................................................................................................................................................... 5

Mounting ........................................................................................................................................................ 6

Connectors .................................................................................................................................................... 7

CAN1/Power ............................................................................................................................................... 7

USB ............................................................................................................................................................ 7

CAN Adapter Harness ................................................................................................................................ 7

Using the Dash ..................................................................................................................................... 8

Touchscreen Basics ....................................................................................................................................... 8

Dashboard ..................................................................................................................................................... 8

Main Menu ..................................................................................................................................................... 8

Configuration .............................................................................................................................................. 8

Dashboard ................................................................................................................................................ 12

Data Log ................................................................................................................................................... 12

Utilities ...................................................................................................................................................... 12

Customize ................................................................................................................................................ 12

Customizing Your Layout .................................................................................................................... 12

Import/Export ............................................................................................................................................... 12

Starting from a Blank Layout ........................................................................................................................ 12

Adding Gauges ............................................................................................................................................ 13

Gauge Types ............................................................................................................................................ 13

Customizing the Gauge ................................................................................................................................ 16

Adding Labels .............................................................................................................................................. 26

Adding Switches .......................................................................................................................................... 26

Changing the Background ............................................................................................................................ 28

Saving Your Layout ...................................................................................................................................... 29

Exporting / Importing Layouts ................................................................................................................... 29

Importing Layouts ..................................................................................................................................... 29

Start-up Gauge Layout ................................................................................................................................. 30

Preconfigured Layouts ........................................................................................................................ 30

Modifying Channels on a Preconfigured Layout ........................................................................................... 32

Data Log Record and Playback .......................................................................................................... 32

Local Data Record ....................................................................................................................................... 32

Data Log Playback ....................................................................................................................................... 32

USB Flash Drive Removal .................................................................................................................. 33

Utilities Menu ...................................................................................................................................... 33

Global Config ............................................................................................................................................... 33

Downloading the Current EFI Configuration.............................................................................................. 34

Uploading a New EFI Configuration .......................................................................................................... 34

Deleting EFI configuration files ................................................................................................................. 34

File Utilities .................................................................................................................................................. 34

Backup/Restore ........................................................................................................................................... 35

Security Settings .......................................................................................................................................... 35

Default Password ..................................................................................................................................... 35

EFI Tuning .......................................................................................................................................... 37

Menu Organization ....................................................................................................................................... 37

Using the Tuning Menu ................................................................................................................................ 37

Enable/Disable Toggle ............................................................................................................................. 37

Numeric Editor .......................................................................................................................................... 38

Pull-Down/List .......................................................................................................................................... 38

Graph Editor ............................................................................................................................................. 39

Table Editor .............................................................................................................................................. 40

User Customizable Menus ........................................................................................................................... 41

Cleaning .............................................................................................................................................. 41

Appendix A.......................................................................................................................................... 42

List of EFI Monitored Values ........................................................................................................................ 42

Appendix B.......................................................................................................................................... 44

Increasing Internal Logging Storage (micro-SD card) ................................................................................... 44

Optional I/O Connector ................................................................................................................................ 45

Appendix C ......................................................................................................................................... 46

Introduction

The Holley EFI Digital Dash is completely customizable with a variety of gauge and indicator screens that can

be programmed to display any parameter you need. Users can select from pre-configured layouts, or

personalize their own. The dash also offers a virtual switch panel, user defined alarms, configurable shift lights

and can control on-screen playback of your EFI data logs. This all new Holley EFI Digital Dash claimed the

SEMA New Product Award for Best Engineered New Product 2015.

The Holley EFI Digital Dash measures 7.5" wide, 4.625" tall and 1" deep, making it a compact, customizable

dash for use in a variety of motorsports applications. The Dash features a 7" low glare, high brightness, high

contrast, full color touch screen for easy viewing even in full sun, plug and play connection to all Holley EFI

systems as well as a weather proof aluminum housing featuring flexible mounting options. Monitor the power of

your Holley EFI system at a glance!

Quick Start Guide

A CAN/power harness is supplied with the digital dash. Connect the black wire to negative, white wire to a

switched +12V circuit.

Connect the harness from the CAN connector on the vehicles main harness to the digital dash using the

supplied 4’ CAN/Power extension

Once all connections have been made the Holley EFI Digital Dash may be powered up. After a brief initial

loading sequence the gauge display will appear.

Package Contents

Specifications

General

Weather-proof aluminum housing engineered to withstand harsh racing environments

7” Low Glare, High Brightness, High Contrast, Full Color Touchscreen

800x480 Resolution

Operating voltage 8V - 20V

Auto Brightness

Plug and Play connection with all Holley EFI systems via CAN bus

Completely customizable display of all EFI parameters including every user configured input and output

Multiple gauge and indicator types with limitless customization options

Quickly toggle between two or more active screens (tune, warm-up, race, drive, etc.)

Virtual switch panel

User defined channel alarms

Configurable progressive shift lights and light bar

On screen playback of EFI data logs

Download and save Holley EFI data logs to external USB memory stick

Expandable internal storage on micro SD card

Flexible mounting options

Support for future USB devices

Upgradable with future software/firmware enhancements

Multiple units can be used simultaneously on a Holley EFI system for larger dashboards

Internal 3-axis accelerometer

Mounting

The product has eight tapped 8-32 mounting holes to allow the user to surface mount or flush mount the

enclosure. There are four mounting holes located on the rear of the unit, and two mounting holes are located

on the left and right sides. Included with the contents of this kit is a separate template with a 1:1 layout of the

hole locations for fabricating a mounting bracket.

NOT TO SCALE – USE THE TEMPLATE INCLUDED IN YOUR KIT

Connectors

CAN1/Power

4 pin Mizu-P25 male receptacle connector used to connect main power and to a Holley EFI. The dual

connector allows the product to be connected to multiple devices on the CAN bus.

Function

Color

Description

+12V

WHT

Main power in

CAN1H

ORG/BLK

CAN_H Holley EFI communications

CAN1L

ORG

CAN_L Holley EFI communications

GND

BLK

GND

USB

The unit has two standard USB type A receptacles that can accept USB flash drives for saving data logs,

uploading gauge screen layouts, background images, or firmware updates.

CAN Adapter Harness

271R1075A CAN ADAPTER HARNESS - used to connect switched +12V ignition power (white wire)

and ground (black wire) to the dash, as well as for connecting to the main harness CAN connector.

Using the Dash

Touchscreen Basics

The Holley EFI Digital Dash has been designed with a resistive touchscreen, meaning it will work with bare

skin, a stylus, or even through driving gloves. This dash responds to localized point pressure on the screen,

not ‘swiping’, which is common on capacitive screens found on current smart phones and tablets.

Dashboard

The dashboard will appear when you power on your Dash. There are several screen layouts that can be

selected. Press anywhere on the display to bring up the navigational buttons, then choose ‘Next’ or ‘Prev’ to

cycle through the screen layouts.

Main Menu

Pressing anywhere on a gauge screen will bring up the navigational buttons. To access the main menu

choose ‘Menu’ in the upper right corner of the screen.

Configuration

The configuration screen allows you to change the display brightness, modify the number of gauge display

layouts (screens), update firmware, and calibrate the touchscreen if required.

Standalone vs EFI Connected Mode

The Dash has two main modes of operation, standalone and EFI-connected. If you have a Holley EFI installed

in your vehicle, ensure that the standalone mode is unchecked in the configuration menu.

If you are using the Digital Dash without a Holley EFI, select Standalone mode. The EFI specific Datalog and

Tuning buttons will no longer be shown in this mode.

Layouts

You may choose the number of layouts or gauge display screens that are configured. An example would be 4

screens, representing tuning, warm up, race, and street.

The Dash will use the last saved layout as the preferred screen to display at power on.

Auto Brightness

The Dash has an ambient light sensor at the lower left corner of the display. This sensor is used to set the

backlight brightness when auto brightness is enabled. If this sensor is covered, the auto brightness feature

will not function.

Press on the “Auto” beside brightness to enable the auto-brightness function. For manual brightness control,

use the slider to adjust the screen brightness.

Clock

The Dash has an internal real-time clock that can be adjusted using this screen. If you connect the 554-140

10Hz USB GPS to the Dash, please ensure the time zone is set correctly as the Dash will automatically set the

clock using the GPS time.

About

This screen contains firmware and software version information along with the CAN id for the Digital Dash.

When connected with a Holley EFI it will show details of the connected EFI.

To perform a firmware update, follow these steps:

1. Extract the contents of the firmware .zip file onto a USB memory stick

2. Connect the USB memory stick to one of the USB cables on the Digital Dash.

a. If the unit is off, the firmware update will take place automatically as soon as the Dash is

powered on with the USB stick plugged in. No further action is required.

b. If the dash is already powered on, proceed to step 3

3. Select ‘Update Firmware’ from the Configuration menu and follow the on screen prompts.

Dash Configuration

This option configures the local dash settings.

Local I/O Tab

Configures the inputs and outputs that are available using the 558-432, 558-433 or 558-434 I/O Adapter.

Consult the I/O Adapter Instruction manual for more information on configuring the Local I/O tab. Pin refers the

physical pin number on the I/O Adapter.

CAN Devices Tab

Configures CAN-connected devices such as the Holley 553-107 LED Light Bar.
