Hocom TAP Series Manuel utilisateur

TAP-Pricing Scale

User Manual

TAP Series

DIGITAL PRICING SCALE

TAP-Pricing Scale

User Manual

Cautions

Upon receiving the scale, please take at least 8 hours

to recharge the battery before you start to operate

this scale.

Please recharge the battery after a long period of

storage (more than one month). It takes 8~10 hours

to fully recharge the battery.

Please assemble the platter before powering on the

scale.

Do not keep the weight placed on the platter for a

long period.

Keep the scale away from the environment with high

temperature、high humidity、heavy press、heavy

bump.

Always make sure the scale is located in a flat and

plane surface.

TAP-Pricing Scale

User Manual

Dimensions

The below panel & keyboard are suitable for table

scale / indicator / bench scale.

TAP-Pricing Scale

User Manual

Symbols on LCD

ZERO Indication ():

Cursor appears on the WEIGHT LCD Display (above

of ZERO printed on the display-overlay), and indicates

the scale is at zero-point.

NET Weight Indication ():

Cursor appears on the WEIGHT LCD Display (above

of NET printed on the display-overlay). This cursor

indicates the tare weight that has been deducted.

Accumulation Indication ():

Cursor appears on the WEIGHT LCD Display(above

of M+ printed on the display-overlay), and indicates the

memory bank that has stored accumulative data of

weight, unit price, and total price.

Indication of Weighing Range () :

Cursor appears on UNIT PRICE LCD Display, (above

of W1 or W2 printed on the display-overlay), and

indicates the present weighing range to be Weighing

Range 1 (W1) or Weighing Range 2 (W2).

Notice:The indication of weighing range is only

available for the scale with multiple range (2 ranges)

TAP-Pricing Scale

User Manual

Indication of kg、100g Weighing Unit () :

Cursor will flash on the UNIT PRICE LCD Display

(above of kg, 100g printed on the display-overlay). This

cursor indicates the present weighing unit.

Battery Symbol () :

When LCD indicates and the scale sounds beep

for four times, it means the battery is running in

low-voltage status. LCD will indicate continuously

for reminding the user to recharge the battery. If the

battery is still running in low-voltage status without being

recharged, LCD will indicate -OFF- and the scale will

sound beep for eight times.Please power off the scale

and recharge the battery immediately.

-

TAP-Pricing Scale

User Manual

Operation Instructions



Press these keys to key in the unit price.

:

(1) Press this key to set the decimal point for the unit

price.

(2) Press and hold [] key till the scale sounds beep to

enable or disable optional Backlight.



Press this key to delete the setting of unit price. Users

could key in the unit price directly without pressing [CE]

key while the last transaction had been finished for more

than 3 seconds.

:

Press this key once, WEGIHT LCD Display will indicate

chg -, and then press [1] or [2] key to select the

weighing unit:

Press [1] key to select kg unit.

Press [2] key to select 100g unit.

UNIT

SET

TAP-Pricing Scale

User Manual

:

(1) Press this key to make the scale be at zero-point.

WEIGHT LCD Display will indicate cursor on the

above of ZERO (printed on the display-overlay).

(2) Press this key could get the net weight. Place a

package or container on the platter and press this key

to deduct the tare weight, WEIGHT LCD Display will

show 0.000 and indicate cursors on the above of

ZERO and NET printed on the display-overlay.

+:

Press this key to operate the non-weighing items. Key in

a unit price and then press [+] key to save the figure into

the memory bank, then show the accumulation amount.



Press this key to operate the multiplication.

Example: Key in 25 »Press [x] key »Press 3»

TOTAL PRICE LCD Display will indicate 75.00

(25 x3 = 75).

At this moment, press [+] key could save this figure into

the memory bank, or press [CE] key to delete this figure.

TARE

ZERO

TAP-Pricing Scale

User Manual



M+

Press this key could save the measured weight, unit

price, and total price into the memory bank (up to 99 data

accumulation).



Press this key to recall the data (16 data recall) one by

one that is saved in the memory bank by press [M+] or [+]

key. When the last data is showed, press [MR] key again

will get the total accumulated price on TOTAL PRICE

LCD.



CHANGE

Press this key to operate money-change function.

Example:

When TOTAL PRICE LCD Display shows $17.15, and

the customer gives $20.00. Press [CHANGE] key once,

and then key in 20. LCDs will show:

WEIGHT

20 (amount from the customer)

UNIT PRICE

17.15 (total amount of transaction)

TOTAL PRICE

C 2.85 (return to the customer)



Press this key could delete all accumulated data in the

memory bank (the scale will sound beep beep when

[MC] key has been operated).

TAP-Pricing Scale

User Manual

RS232 Interface Connection:<optional device>

RS232 Wiring Configuration:

Baurate: 9600

Parity: None

Stop Bit: 1

Data Bit: 8

GND

DATA OUT

TAP-Pricing Scale

User Manual

Recharge the Battery

Power off the scale and connect the power cord to an

AC outlet. CHARGE LED will indicate the ongoing

status of the battery. It takes about 8~10 hours to fully

recharge the battery.

CHARGE LED:

Color of LED

Status of the battery

RED

Initial Connection

ORANGE

Charging

GREEN

Fully-charged

Power Requirement

AC: 110V±10%, 60Hz

DC: 6V/4Ah rechargeable battery;

P=0.2W(max)
