Please read this manual thoroughly before use and keep it handy for future reference.

Rev.0400908

CAMERA HOUSING

CAMERA HOUSINGCAMERA HOUSING

CAMERA HOUSING

Series

SeriesSeries

Series

INSTALLATION MANUAL

10-Inch/12-Inch CAMERA

ENCLOSURES

TABLE OF CONTENTS

1. CAMERA HOUSING SERIES INTRODUCTION

1.1 PURPOSE ............................................................................ 1

1.2 FEATURES........................................................................... 1

2. HOUSING INSTALLATION INTRODUCTIONS

2.1 CONTENTS OF PACKAGE …………………………………. 2

2.2 PREPARATION FOR INSTALLATION …………………….. 2

2.3 INSTALLATION OF OPTIONAL COMPONENTS ………... 4

2.3-1 Blower Kit Installation ………………………………………… 4

2.3-2 Heater Kit Installation ………………………………………… 5

2.3-3 Blower Kit with Heater Kit ……………………………….…… 7

2.4 CAMERA MOUNTING ………………………………………. 9

2.5 SUNSHIELD INSTALLATION............................................. 11

2.6 WALL BRACKET MOUNTING ...........................................11

2.7 MAINTENANCE.................................................................. 12

3. SPECIFICATIONS

3.1 CAMERA HOUSING SERIES SPECIFICATIONS .............13

3.2 SUNSHIELD (OPTIONAL).................................................. 14

3.3 HEATER (OPTIONAL)........................................................ 14

3.4 BLOWER (OPTIONAL) ......................................................14

1. CAMERA HOUSING SERIES INTRODUCTION

1.1 PURPOSE

The camera housing series are stylishly and functionally

designed enclosures for 1/2" and 1/3" CCD cameras with fixed

focal length or small zoom lenses. This manual describes how to

assemble the housing and its optional components, affix the

camera, and mount the assembly to a suitable surface.

1.2 FEATURES

The camera housing series includes the fallowing feature:

•Contemporary design

•Die-cast and extruded aluminum construction

•Adjustable mounting track

•Removable body for easy servicing

•Optional heater kit, blower kit and snap-on sunshield

components

•Indoor/outdoor applications

•Epoxy powder coating for corrosion resistance

•IP66 rated

2. HOUSING INSTALLATION INSTRUCTIONS

2.1 CONTENTS OF PACKAGE

Remove the camera housing from the carton and verify that it

was not damaged in shipment.

The package includes:

1. Camera housing (including screws and washers)

2. Optional accessories and hardware

(varies by specific model purchased.)

3. Desiccant bag

4. UNC 1/4"-20 machine screws

5. Manual

2.2 PREPARATION FOR INSTALLATION

This section contains comprehensive instructions for installing

the heater kit and blower kit for the camera housing series.

These kits are sold as add-on components or are available in a

pre-assembled package. The MODEL A(B)-HB is a 10(12)-inch

camera housing with an installed sunshield, heater and blower.

After unpacking and identifying the package contents, perform

the following steps to mount the camera in the housing:

1. Locate the following items which may be needed during

installation but are NOT supplied with the enclosure:

•Screwdriver

•Camera and camera cable

•Power supply

2.2 PREPARATION FOR INSTALLATION

2. If applicable, move the sunshield by sliding it forward on the

main housing unit. Set the sunshield aside until needed.

3. Unlatch the lid and open the upper body.

4. Before closing the housing, remove the desiccant bag from

the protective packaging and place the desiccant bag inside

the housing to absorb moisture.

5. Locate the gold, panhead 1/4"-20 UNC screws and set them

aside for later use.

6. Continue with installation of additional components as needed.

If no additional components are installed, continue to

instructions for camera mounting.

OPEN

UNLATCH

LID

2.3 INSTALLATION OF OPTIONAL COMPONENTS

2.3-1 BLOWER KIT INSTALLATION

1. Mount the blower unit located two on the rear of the housing.

Align the hole and secure using the small Philips panhead

screw.

2. Mount the blower circuit board located on the lower body.

Align the holes and keep the wiring on the same side. Insert

the small Philips panhead screws and secure the assembly.

BLOWER UNIT

SMALL

PHILIPS

PANHEAD

SCREWS

SMALL

PHILIPS

PANHEAD

SCREWS

2.3 INSTALLATION OF OPTIONAL COMPONENTS

3. Connect the external power supply (not included) to the circuit

board. The recommended power supply is 24Vac, 50VA.

4. If adding a heater kit, see instructions for adding both the

blower kit and heater kit. If no other components will be

added, proceed to camera mounting instructions.

2.3-2 HEATER KIT INSTALLATION

1. Mount the heater unit in on the support rail on the lower body.

Align the tapped hole and secure the unit using the small

Phillips panhead screw.

24Vac Out

to Heater

24Vac Power

Supply Output

24Vdc Out

to Blower

24Vac Power

Supply Input

Ground Ground

(B+)

(Ground)

J6J4J5

LOWER BODY

SMALL PHILIPS

PANHEAD SCREW

2.3 INSTALLATION OF OPTIONAL COMPONENTS

2. Mount the heater circuit board on the lower body. Align the

holes and keep the wiring on the same side. Use the small

Phillips panhead screws to secure the assembly.

3. Connect the external power supply (not included) to the circuit

board. The recommended power supply is 24Vac, 50VA.

4. Continue with instructions for mounting the camera.

SMALL

PHILIPS

PANHEAD

SCREWS

24Vac Out

to Heater

24Vac Power

Supply Output

24Vac Power

Supply Input

Ground Ground

J6J4J5

2.3 INSTALLATION OF OPTIONAL COMPONENTS

2.3-3 BLOWER KIT WITH HEATER KIT

1. Follow steps detailed previously to install the Blower Kit.

2. Using a small screwdriver, disconnect the wiring to the J1 and

J5 ports on the heater circuit board.

3. Replace the heater circuit board with the circuit board that is

wired to the blower. To do this, locate the two Philips

panhead screws on the heater circuit board. Unscrew them

and remove the board from the lower body of the housing.

Mount the blower circuit board located on the lower body.

Align the holes and keep the wiring on the same side. Use

the small Philips panhead screw to secure the assembly.

(Refer to drawing on next page.)

HEATER

CIRCUIT

BOARD

DISCONNECT

WIRING TO

J1 AND J5

PORTS
