Hisense LTDN40K320UHK Manuel utilisateur

LTDN40K320UHK

LTDN50K320UHK

USER MANUAL

Before using the TV, Please read this manual

thoroughly, retain it for future reference.

English

ＲＳＡＧ２．０２５．４７６１ＳＳ

条形码定位框，长３５ｍｍ，高度请根

据长度等比例缩放。该定位框不做印

刷处理。物料号：

Ｔｉｐｓ

More Product Features, you can see the TV Featuring Application Guide.

Before using the TV, Please read this manual thoroughly, retain it for future reference.

Our company does not assume any liability for any accident arising from violation of

the matters of attention and instruction on use in this manual.

This product involves high voltage. The user may not open the cabinet

without authorization. Any person other than the repairer may not repair and

replace parts without authorization to avoid shock and re accidents.

Please clean and maintain the entire TV set with clean and soft cotton cloths,

and repeated forcible cleanings are prohibited.

The screen may not be scribed, tapped, impacted with hard objects or

rubbed with any grinding materials.

During placement and use, the product should be kept from water droplet

and splash. In case of adverse weather e.g. thunderstorm, the power plug

and cable TV (or outdoor antenna) plug shall be rapidly pulled off to avoid

damage due to lightning strike.

Still images can result in permanent damage to TV screen.

1. The time for displaying static images on the LCD TV screen may not ex-

ceed 2 hours, otherwise it will result in residual image on the screen. To

avoid this, you need to lower the screen brightness and contrast when

displaying the still images.

2. When viewing 4:3 format program over long time, different traces will be

left on the left and right sides of the screen and the edge of margin. So

the user is advised not to use such pattern over long time.

3. Long-time display of electronic games and computer static images may

result in local residual image, and the screen may get burnt and result in

residual image on the screen. To avoid this, you need to lower the screen

brightness and contrast during use.

For any image residual shadow, local residual image and trace problems

with the TV screen due to the said reasons, the display screen is not within

the range of warranty.

The TV set is a Type II equipment, and used without requiring grounding.

Tips for energy saving:

1. Please choose AC power off (turn off the TV through the power switch) when

not viewing TV program to minimize energy consumption.

2. Under condition that the view quality is not impacted, reduce the brightness

of display screen to minimize the energy consumption of TV during use.

Triangle enclosing a lightning arrow is a warning symbol,

reminding you of the high voltage danger in the product. √The correct way.

Triangle enclosing an exclamation mark is a warning symbol,

reminding you of the important notes related to the product. ×The wrong way.

·Attention. －＞ Next step.

Check the Symbol

Important Safety Instrctions

1 Power and signal

When it is rainy, please pull out the power plug, CATV plug or outside antenna plug

to avoid any possible damage to the TV set. Do not touch the inducting wire of the

antenna.

Where the MAINS plug or an appliance coupler is used as the disconnect device,

the disconnect device shall remain readily operable.

If you do not use the product for a long time, please pull out the power plug.

If you nd abnormal sound or smell, or there is sound but no image, please turn off

the TV and pull out the plug immediately and contact the Hisense Service.

·Please do not press the power line and signal line with other things.

·Please do not make the power outlet overloaded, or it will result in the danger of

re.

·Keep the power line away from high temperature and heating things.

·There are some changes for the outdoor antenna if it stays outside for a long time,

which may affect the picture quality of the TV, so please check the antenna or

replace it regularly.

·Do not place containers with water on the TV, such as a cosmetic or medicament.

·If foreign objects or water falling into the television, unplug the power cord and

timely and Hisense Services.

·Beware of children standing on top of a TV or climb to the television.

·After the TV from the cold to a warm area where, for the full distribution of drying

condensation inside the machine, you should place some time after the power is

turned on.

·To prevent injury, you must follow the installation instructions of the device after the

installation base, placed on a horizontal table, or is not installed base, use can be

xed to the wall after wall mounting.

·Do not expose the battery to sunshine, re and other excessive heat, or there will

be an explosion hazard.

Alerts: Before using the product, please read the following clauses carefully.

III

2 Maintenance

·Do not clean this unit with volatile oils or dilution, which may cause cabinet

deterioration or damage its coating surface.

·If the cabinet becomes dirty, please clean it with a soft cloth which has neutral

detergent wet with water.

3 LCD display instruction and maintenance

LCD display panel is the advanced S&T product, composed of several millions of

Movie transistors inside. There can be dark or bright spots appearing on the panel.

please note that this is a normal phenomenon, which does not affect the overall

performance.

The incorrect maintenance will lead to damage to the LCD screen, which will affect the

image effect, so you must pay attention to the following items:

Don't clean the screen with the organic solvents, such as alcohol, gasoline, etc. or

chemical reagents ,such as acid, alkali, etc.

Do not clean the screen with any kind of detergent.

After the TV is turned off, you, when necessary, can clean the screen with a clean

and soft cotton cloth to properly safeguard it, but repeatedly cleaning with force is

prohibited.

·Please do not directly touch the screen with your ngers, which may damage the

screen surface. What's more, the oil and fat on the screen is difcult to remove.

·Please do not put pressure on the LCD, for the LCD screen is delicate and

vulnerable.

·The hard object is not allowed to touch the LCD screen, for it is easily scratched.

5 Method of placement

√Even and steady occasions.

×Places under direct sunshine or close to heating devices.

×Places with poor ventilation.

×Places close to furnace or places to which water, oil or smoke is easy to enter.

×Places where ventilating openings are closed.

4 Product

·Please do not try to decompose any part of the product, which may cause damage

to the product as well as harm to the human. And it will also make you face the

product warranty failure.

·Please do not remove the back cover. The adjust and check inside the unit should

only be carried out by the professional technicians.

·Please do not cover or block the heat-radiating holes in order not to hamper the

unit to give off heat.

·Please do not stick the sharp objects, metal, or liquid into or use them to touch the

signal interface or heat-radiating holes in case of short circuit or damage to the product.

7 Others

·It is recommended that 2 or more people should load, unload and carry the unit; try

to avoid any crash when carrying the unit, and protect the LCD screen in particular.

·If you touch the LCD screen when turning on or off the TV, you can feel the slight

electric shock, which is the so-called electrostatic and does no harm to your health.

·Plastic shell newly purchased television, internal transformer insulating paint,

rubber and other pieces of furniture will be like a new purchase as distributing

certain smell, temperature, odor will be more apparent. The odor is determined by

the nature of the material. Materials scheme we use fully meet the requirements

of environmental regulations sales regions, so consumers can be assured. TV

odors over time gradually reduce and eventually disappear, consumers should pay

attention to use ventilation environment.

×Unsteady places.

×Places suffering from easy vibration.

×Places of lot of dust or moist places.

×Places of high temperatures.

·In the case where such substances that are painted with paint or organic solvent

and grease, etc. on the surface of the TV cabinet, the chemical reaction may

be occurred in between the rubber cushion on the base and such substances

hereinbefore, which may cause a slight corrosion on the surface of the TV cabinet.

Therefore, users are recommended to rstly put a layer of protective material (such

as pressboard or glass sheet, etc.) on the TV cabinet and then place the TV set.

6 Watching TV

·Watch TV at a proper distance, and the best distance is 3 to 4 times the length of

the vertical distance of LCD.

·Keep the lighting indoors bright enough to read newspaper.

·The volume should be properly set in order not to disturb your neighbors, esp.

when it is during the night.

8 Securing the Installation Space

·Never cover or block the heat-radiating holes.

·Avoid operating the TV below 5 ℃.

·Make sure that your TV has adequate air circulation. Allow enough space around

the TV as shown below.

Install with stand:

Leave enough space around the set.

Install on the wall:

Wall Wall

Air circulation is blocked.

·Never install the TV set as follows:

Inadequate air circulation can lead to overheating of the TV and

may cause damage to your TV or cause re.

Leave enough space around the set.

Accessories List........................................................................................................2

Installing the Stand................................................................................................... 2

Remote Control ........................................................................................................ 3

Control Panel............................................................................................................ 4

Terminal Introduction ................................................................................................ 5

Connection Description ............................................................................................ 6

Using the TV for the First Time................................................................................10

Others......................................................................................................................11

Specications ..........................................................................................................13

Contents

Accessories List

Installing the Stand

•Carefully place your TV face-up on a soft, flat surface to prevent damage to the TV

or scratching to the screen.

•Install the base stand with the provided screws in the accessory bag in case of

causing damage to TV.

•Appearance prevail in kind.

BASE STAND

Ｍ４×１２（４０＂）

Ｍ４×２０（５０＂）

Ｍ４×１２（４０＂）

Ｍ４×２０（５０＂）

User Manual

Warranty Card

Remote Control

Power line

AAA Battery

Ｓｃｒｅｗ

Insert the base stand into the bottom

slots of the TV, use the two screws to

the base stand and TV together.

Insert the base stand into the bottom

slots of the TV, use the two screws to

the base stand and TV together.

Remote Control

Channel increasing button

Channel down button

ＴＶＭｅｄｉａＧａｍｅＡｐｐｓ

Information

ＴＶ

ＥｎｔｅｒＬｉｖｅＴＶ

Ｍｅｄｉａ

ＥｎｔｅｒＶＯＤ

Ｇａｍｅ

ＥｎｔｅｒＧａｍｅ

Ａｐｐｓ

ＥｎｔｅｒＡｐｐｓ

▲／

▲

／

▲

／

▲

Up/down/left/right button

Ｓｐｅｃｉａｌｆｕｎｃｔｉｏｎｂｕｔｔｏｎｓ

Ｓｏｕｒｃｅｂｕｔｔｏｎ

Select input sources

Switch sources

Standby button

Enter standby/exit standby

Setting button

Start/stop quick setup menu

Home button

Enter the television's Home

page

Return button

Exit the current menu

Volume increasing button

Volume down button

Mute button

Start/Exit the mute state

OK button

Conrm the selection

Battery cover hand-clasping

·Change the battery

1.Open the battery cover,

battery cover separated from

the body in a remote control

, in the battery cover hand-

clasping place.

2. Install two AAA size (1.5V)

batteries. Match the "+" and

"-" signs on the batteries

to the signs on the battery

compartment.

3. Close the battery cover until

the body is fully consistent

with the remote control.

The effective range of remote control

1. Remote control distance: In front

of the remote distance 8 meters

effective range.

2. The remote control angle: taking

the television infrared light

receiver window as an apex, 6

meters away, its controlled angle

(left to right) is within 30 degrees,

while the vertical angle (up to

down) is within 15 degrees.

·Attention

1. If the remote control doesn't work

normally, unstable, or cannot

control the TV, please update

Battery.

2. If you do not use the remote

control for a long time, remove

the batteries.(Used batteries

pollute the environment, properly

handle.)

3.To achieve the best remote

reception, the black square on

the back of the remote control

transmitter window aligned

television remote control receiver

window position for remote

operations.

Control Panel

Ｓｉｄｅｂｕｔｔｏｎ（５０＂）Ｓｉｄｅｂｕｔｔｏｎ（４０＂）

remote control receiver window/

Power indicator(40")

remote control receiver window/

Power indicator(50")

Power button

Item Description

Power button Turn on or off the TV set.

Infrared remote control

receiver window Receive remote signals from the remote control.

Power indicator Boot blue light, red light standby.

/ SOURCE Select among the different input signal sources.

/ Turn on the TV or put the TV in standby mode.

CH+/▲

CH+ Select the next channel / up or move the pointer focus.

CH-/

▲

CH+ Select a channel / down to move the pointer or focus.

OK Conrm the selected menu item under the relevant /

Press OK button to pop up the menu button.

VOL+/

▲

Select the next favorite channel / right to move the pointer or

focus / In the HDMI channel for controlling volume increases.

VOL-/

▲

Select a favorite channel / left to move the pointer or focus

/ In the HDMI channel for controlling volume decrease.

Ｎｏｔｅ：Ｔｈｉｓｍａｃｈｉｎｅｄｏｅｓｎｏｔｓｕｐｐｏｒｔ

ｒｅｔｒｉｅｖｅｒｅｍｏｔｅｃｏｎｔｒｏｌｆｕｎｃｔｉｏｎｓ．

Ｐｒｅｓｓｔｈｅｂｕｔｔｏｎｔｏｐｏｐ

ｕｐｔｈｅｍｅｎｕｂｕｔｔｏｎ．

Home Back Power

Source Close Volume Up

Settings Remote Volume Down

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Hisense TV

Hisense

Hisense 65A6H Manuel utilisateur

Hisense

Hisense LCD19W57ACA Manuel utilisateur

Hisense

Hisense Roku TV R6 Series Manuel utilisateur

Hisense

Hisense LHDN32V88MH Manuel utilisateur

Hisense

Hisense LHD32A300JEU Manuel utilisateur

Hisense

Hisense 85R7 Manuel utilisateur

Hisense

Hisense H5C series Manuel utilisateur

Hisense

Hisense GM642XF Manuel utilisateur

Hisense

Hisense LHD32D50TUK Manuel utilisateur

Hisense

Hisense LCD42P69P Manuel utilisateur

Hisense

Hisense LEDN32K300M Manuel utilisateur

Hisense

Hisense Roku TV R43B7120UK Manuel utilisateur

Hisense

Hisense 32K220W Manuel utilisateur

Hisense

Hisense R7G5 Series Manuel utilisateur

Hisense

Hisense H80L5UK Manuel utilisateur

Hisense

Hisense 55A6BG Manuel utilisateur

Hisense

Hisense HL55V89PZ Manuel utilisateur

Hisense

Hisense 32W22 Manuel utilisateur

Hisense

Hisense A6HAU Series Manuel utilisateur

Hisense

Hisense 32H4E Manuel utilisateur

Hisense

Hisense K660HK3D series Manuel utilisateur

Hisense

Hisense HL46T39PZLN3D Manuel utilisateur

Hisense

Hisense Roku TV 70R6200F Manuel utilisateur

Hisense

Hisense XClass Manuel utilisateur

Manuels TV populaires d'autres marques

Philips

Philips Colour Television Manuel utilisateur

Toshiba

Toshiba 27A10 Manuel utilisateur

Philips

Philips 42PF9630A/37 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Philips

Philips Matchline 21CE7551 Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Philips

Philips 25PT4523-16 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Philips

Philips PR0930X3 Manuel utilisateur

Philips

Philips Brilliance 231P4QPY Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Philips

Philips 32HF9385D Guide de dépannage

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Philips

Philips 32PFH5300 Manuel utilisateur
