Hisense HR6VFF177A Instructions de montage

Before operating the unit,please read this manual thoroughly,

and retain for future reference

USER’S OPERATION MANUAL

MODEL:HR6VFF177A

INDEX

Operating Instructions ..............................................................2

Important Safety Instructions ...................................................4

Installation Instruction...............................................................6

Description of the Appliance ....................................................7

Using Your Appliance ................................................................8

Thermostat Control…………………………………………………9

Door reversal.............................................................................10

Hints and Tips ..........................................................................12

Trouble Shooting…………………………………………………..13

Service/Repair ..........................................................................14

Disposal of the appliance........................................................15

Important Safety Instructions

These warnings are provided in the interest of your safety. Ensure that you understand them all

before installing or using this appliance. Your safety is of paramount importance. If you are still

unsure about the meaning of these warnings, contact the Customer Care Department for

assistance.

Intended use

This freezer is intended for use in the home. It is suitable for the storage of food at low

temperature. If the appliance is used for purposes other than those intended or used incorrectly, no

liability can be accepted by the manufacturer for any damage that may be caused. Alterations or

changes to the refrigerator are not permitted for reasons of safety.

Prior to initial start-up

Check the appliance for transport damage. Under no circumstances should a damaged appliance

be plugged in. In the event of serious damage, don’t hesitate to contact your supplier.

Refrigerant

The refrigerant isobutene (R

R600a

) is contained within the refrigerant circuit of the appliance, a natural

gas with a high level of environmental compatibility, which is nevertheless flammable. During

transportation and installation of the appliance, ensure that none of the components of the

refrigerant circuit becomes damaged.

The refrigerant (R600a) is flammable.

Caution: risk of fire

If the refrigerant circuit should become damaged:

zAvoid open flames and sources of ignition.

zThoroughly ventilate the room in which the appliance is situated.

The instructions shall include the warnings:

WARNING!

—Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear

of obstruction.

WARNING!

—Do not use mechanical devices or other means to accelerate the defrosting process,

other than those recommended by the manufacturer.

WARNING!

—Do not damage the refrigerant circuit.

WARNING!

—Do not use electrical appliances inside the food storage compartments of the

appliance.

WARNING!

—This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the appliance by a person responsible for

their safety.

WARNING!

—Young children should be supervised to ensure that they do not play with the

appliance

WARNING!

—If the supply cord is damaged, it must be replaced by the manufacturer, its service

agent or similarly qualified persons in order to avoid a hazard.

WARNING!

—When disposing of the appliance, do so only at an authorized waste disposal centre.

Do not expose to flame.

WARNING!

—Please keep the appliance away from substance, which can cause ignition.

WARNING!

--- Before obtaining access to terminals, all supply circuits must be disconnected.

WARNING!

--- Please remove all the doors before you dispose your refrigerator.

WARNING!

--- The fridge is only applied with power supply of single phase alternating current of

220~240V/50Hz. If fluctuation of voltage in the district of user is so large that the voltage exceeds

the above scope, for safety sake, be sure to apply A.C. Automatic voltage regulator of more than

350W to the fridge. The fridge must employ a special power socket instead of common one with

other electric appliances. Its plug must match the socket with ground wire.

Safety of children

Packaging (e.g. wraps, polystyrene) can be dangerous for children. There is a risk of suffocation!

Keep packaging materials away from children!

Remember to dispose of old appliances in accordance with local laws. Pull out the mains plug, cut

off the mains cable, break or remove spring or bolt catches if fixed. And ensure that children

cannot lock themselves in the appliance when playing (there is risk of suffocation) or involve themselves

in other dangers, for children cannot recognize the hazard present in household appliances themselves.

Therefore, it is very important for parents to make adequate supervision and never let children play

with the appliance!

Daily operation

Containers with flammable gases or liquids can leak at low temperature. There is a risk of explosion!

Do not store any container with flammable materials such as spray cans in the refrigerator.

Do not operate any electrical appliance in the refrigerator (e.g. electric ice cream makers, mixers

etc.).

Before cleaning the appliance, always switch off the appliance and unplug it, or pull the house fuse

or switch off the circuit breaker.

In case of malfunction

If a malfunction occurs, please look first in the “Trouble Shooting” section for help. If the information

given there does not help, just leave it alone and ask your supplier for help. Under no circumstances

should you attempt to repair the appliance yourself.

Remove transport packaging

The appliance and the interior fittings are protected for transportation. Pull off the adhesive tape on

the left and right side of the door. You can remove any remnants of adhesive using white spirit.

Remove all adhesive tape and packing pieces from the interior of the appliance.

Installation Instruction

Before installing, carefully read the instruction in order to avoid a certain number of problems.

Positioning

Position the appliance away from sources of heat such as stoves, radiators, direct sunlight etc.

Maximum performance and safety are guaranteed by maintaining the correct indoor temperature for

the class of unit concerned, as specified on the rating plate. This application perform well from N to

ST. The Appliance may not work properly if it is left for a longer period at a temperature above or

below the indicated range.

IMPORTANT!

-There is a need of good ventilation around the fridge for easy dissipation of heat, high

efficiency of refrigeration and low power consumption. For this purpose, sufficient clear space

should be available around the fridge. It is advisable for there to be 75mm separating the back of the

fridge to the wall, at least 100mm of space at its two sides, height of over 100mm from its top and a

clear space upfront to allow the doors to open 160 Degrees.

Climate classification Ambient temperature

SN 10~32°C

N 16~32°C

ST 16~38°C

T 16~43°C

Appliances must not be exposed to rain. Sufficient air must be allowed to circulate in the lower rear

section of appliances, as poor air circulation can affect performance. Built-in appliances should be

positioned away from heat sources such as heaters and direct sunlight.

Leveling

The appliance should be level in order to eliminate rocking. To make the appliance level, it should be

upright and both adjusters should be firmly contacted with the floor. You can also adjust the level by

screwing out the appropriate level adjuster at the front (use your fingers or a suitable spanner), but

much care should be taken when moving this appliance since it should be heavy.

Drawers in freezer

Freezing or storing foods.The quick-freeze foods must be evenly placed in drawer, and put them

together to store after freezing.

IMPORTANT!

– in order to make the most of the volume of the fresh food storage compartment and

frozen-food storage compartment, the user can remove one or more drawers, out of the appliance,

according to your daily use.

Using Your Appliance

This appliance is designed for domestic use only, specifically for the storage of edible foods. And it is

designed to operate in ambient temperatures (surrounding air temperature) between 16ćand 38ć.

If the temperature exceeds that designed, either colder or warmer, the appliance will not work

effectively and correctly. Should the ambient temperature be exceeded for long period of

time, the temperature in the freezer will rise above -18ćand food spoilage may occur .

Before use

Remove all securing tapes. Wash the inside of the appliance with lukewarm water added with a little

bicarbonate of soda (5ml to 0.5 liter of water). Do not use soap or detergent since the smell may

linger. After cleaning, dry the appliance thoroughly.

To start the appliance

Operating instructions

1. Allow the appliance to stand for 2 hours after installation.

2. Plug in the appliance and turn on the power.

3. Turn the thermostat control to the required setting. A midway setting is usually suitable for

normal operation.

4. Leave the appliance for approximately 4 hours to reach the correct temperature before placing

food inside.

Cold Colder

Important!-Normally we advise you select setting in the middle of Cold and Colder, if you want the

temperature warmer or colder please turn the knob to lower or higher setting accordingly.

Be advised that for maximum efficiency we ask that you set your Freezer settings to suit the ambient

temperature in your area.

Important!-

High ambient temperatures (e.g. on hot summer days) and a cold setting on the

temperature regulator (position Max) can cause the compressor to run continuously or even

non-stop!

Reason: when the ambient temperature is high, the compressor must run continuously to maintain

the low temperature in the appliance.

Door Reversal

The side at which the door opens can be changed from the right side (as supplied) to the left side, if

the installation site requires.We recommend 2 people to perform this.

Before you start lean the freezer on its back on a 45 Degree angle. The second person should hold this

into position. In order to gain access to the base, you should rest it on soft foam packaging or similar

material to avoid damaging the cooling pipes at the rear of the refrigerator.

Warning!

When changing the side at which the door opens, the appliance must not be connected to the

mains. Remove plug from the mains beforehand.

1. Remove the cover of

screws, and unscrew the

screw, then remove the

top cover.

2. Remove the decoration of

the top cover, and fix the

decoration on the opposite

side.

3. Unscrew the upper hinge

and remove it

4. Unscrew the upper hinge

pivot and place it on the

opposite side.

5. Remove the door and the

lift upper hinge cover on

the door, and fix it on the

opposite side.
