Hirschmann OWL3G Manuel utilisateur

Installation OWL 3G

Release

06/2017

Technical Support

https://hirschmann-support.belden.eu.com

User Manual

Installation

OWL 3G (Industrial Cellular Router)

The naming of copyrighted trademarks in this manual, even when not specially indicated, should

not be taken to mean that these names may be considered as free in the sense of the trademark

and tradename protection law and hence that they may be freely used by anyone.

translation, conversion into any electronic medium or machine scannable form is not permitted,

either in whole or in part. An exception is the preparation of a backup copy of the software for

your own use.

The performance features described here are binding only if they have been expressly agreed

when the contract was made. This document was produced by Hirschmann Automation and

Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right

to change the contents of this document without prior notice. Hirschmann can give no guarantee

in respect of the correctness or accuracy of the information in this document.

Hirschmann can accept no responsibility for damages, resulting from the use of the network

components or the associated operating software. In addition, we refer to the conditions of use

specified in the license contract.

You can get the latest version of this manual on the Internet at the Hirschmann product site

(www.hirschmann.com).

Hirschmann Automation and Control GmbH

Stuttgarter Str. 45-51

72654 Neckartenzlingen

Germany

Installation OWL 3G 12.06.2017

Installation OWL 3G

Release

06/2017 3

Contents

About this Guide 5

Legend 5

GPL License 5

Safety Instructions 6

1 Router Description 10

2 Contents of Package 12

3 Router Design 13

3.1 Delivery Identification 13

3.2 Basic Dimensions of Router Box 14

3.3 Mechanical Dimensions and Mounting Recommendations 14

3.4 Removing from the DIN rail 17

3.5 Description of the Front Panel 18

3.5.1 Status Indication 19

3.5.2 Power Connector 20

3.5.3 Grounding the device (functional earth) 20

3.5.4 Antenna Connectors 21

3.5.5 SIM Card Reader 22

3.5.6 Reset 22

3.5.7 Ethernet Ports ETH0 & ETH1 23

4FirstUse 25

4.1 Connecting Components before the First Use 25

4.2 Start 26

4.3 Configuration 27

4.3.1 Configuration using a Web Browser 27

5 Technical Parameters 28

5.1 Basic parameters 28

5.2 Type tests and environmental conditions 28

5.3 Technical Parameters of module 29

5.4 Technical Parameters of the processor 30

6 Recommended literature 31

4Installation OWL 3G

Release

06/2017

6.1 Available Literature 31

7 Possible problems 32

7.1 Solutions 32

8FAQ 33

9 Customers Support 35

9.1 CE-marking 35

9.2 E marking 36

A Further support 37

Installation OWL 3G

Release

06/2017 5

About this Guide

This document provides technical specifications for the Industrial Cellular

Router and illustrates the hardware installation for a Hirschmann Industrial

Cellular Router. It also helps the developers to validate their application

design using the Industrial Cellular Router.

The information in this publication contains general descriptions or

performance factors which, when applied in an actual situation, do not

always correspond with the described form and may be amended by way of

further development of products. The desired performance factors shall only

be deemed binding if these are expressly agreed on conclusion of the

contract. Please note that some characteristics of the recommended

accessory parts may differ from the appropriate product. This might limit the

possible operating conditions for the entire system.

Legend

The designations used in this manual have the following meanings:

GPL License

Source codes under the GPL license are available free of charge. Send an

email request to:

[email protected]

List

Work step

Subheading

Link Cross-reference with link

Note: A note emphasizes an important fact or draws your attention to a dependency.

Courier ASCII representation in the graphical user interface

6Installation OWL 3G

Release

06/2017

Safety Instructions

General safety instructions

You operate this device with electricity. The safe operation of the device

depends on proper handling during transportation, storage and assembly,

and proper use of operation and maintenance procedures. Improper use

of this device can cause injury or property damage.

Read this documentation, safety instructions and warnings before

connecting any cables.

Never start an operation with damaged components.

The device does not contain any service components. If the device is

not functioning correctly, or if it is damaged, turn off the power supply

and return the device to Hirschmann for inspection.

Qualification requirements for personnel

Allow only qualified personnel to work on the device who have the

following characteristics:

Properly trained personnel who have practical knowledge and

experience. This is the prerequisite for grounding and labeling

circuits, devices, and systems in accordance with current

technology safety standards.

Qualified personnel are aware of the dangers that exist in their

work.

Qualified personnel are familiar with appropriate measures against

these hazards in order to reduce the risk for themselves and others.

Qualified personnel receive training on a regular basis.

WARNING

UNCONTROLLED MACHINE ACTIONS

To avoid uncontrolled machine actions caused by data loss, configure all

the data transmission devices individually.

Before you start any machine which is controlled via data transmission, be

sure to complete the configuration of all the data transmission devices.

Failure to follow these instructions can result in death, serious injury,

or equipment damage.

Installation OWL 3G

Release

06/2017 7

Intended usage

Use the product only for the application cases described in the

Hirschmann product information, including this manual.

Operate the product according to the technical parameters. See “First

Use” on page 25.

Connect components which are suitable for the requirements of the

specific application to the product.

National and international safety regulations

Verify that the electrical installation meets applicable national and

international safety regulations.

Working voltage

Connect only a working voltage that corresponds to the type plate of

your device.

Make sure the following requirements are met every time you connect

the electrical conductors:

The power supply conforms to over voltage category I or II.

The power supply has an easily accessible disconnecting device

(such as a switch or a plug) which is clearly identified. So in case

of an emergency, it is clear which disconnecting device belongs to

which power supply cable.

The electrical wires are voltage-free.

The power supply is Class 2 compliant.

The working voltage inputs are designed for operation with safety

extra-low voltage. Connect only SELV circuits with voltage

restrictions in line with IEC/EN 60950-1 to the working voltage

connections.

The wire diameter of the power supply cable is at least 0.5 mm²

(North America: AWG20) on the working voltage input.

The wire diameter of the ground conductor is at least 0.5 mm²

(North America: AWG20).

The power supply cables used are permitted for the temperature

range required by the application case.

The power cords are suitable for ambient air temperatures of at

least 167 °F (75 °C). The power cord wires are made of copper.

Turn on the operating voltage for the device only when the following

requirements are fulfilled:

The housing is closed

The terminal block is wired correctly

The terminal block for the operating supply is connected

8Installation OWL 3G

Release

06/2017

Installation site requirements

Verify that there is at least 4 in (10 cm) of space above and below the

device.

Verify that there is at least 0.8 in (2 cm) of space on the right and left

sides of the device.

Verify that there is at least a minimum distance of 20 cm between the

antenna and the human body.

Housing

Never insert pointed objects (narrow screwdrivers, wires, etc.) into the

device or into the connection terminals for electric conductors. Do not

touch the connection terminals.

Installation OWL 3G

Release

06/2017 9

Please, observe the following instructions:

To prevent injury and damage to the device and to ensure that you comply

with the relevant provisions, use original accessories only. Unauthorized

modifications or unapproved utilization of accessories can result in

damage to the router and in a breach of applicable regulations.

Unauthorized modifications or unapproved utilization of accessories can

result in the termination of the guarantee.

Before handling the SIM card, disconnect the router from the power

supply.

Do not exceed the maximum voltage of 30 V DC at the power

connector of the router.

Do not expose the router to extreme ambient conditions. Protect the

router against dust, moisture and high temperature. See table 8 on

page 28.

It is recommended that you should create an appropriate copy or

backup of the important settings that are stored in the memory of the

device.

Caution! The SIM card can be swallowed by small children.

It is recommended that you do not use the router at petrol filling

stations. We recommend observing local restrictions concerning the

use of radio-based devices while working with explosive material for

example, at petrol filling stations, or in chemical plants.

While using the router close to personal medical devices, such as

cardiac pacemakers or hearing aids, proceed with heightened caution.

Note: Insert the SIM Card holder in the SIM card slot very carefully. When

inserted improperly, you can damage the SIM card slot. Also, the SIM

card can fall out of the holder and end up in the router.

10 Installation OWL 3G

Release

06/2017

1 Router Description

Hirschmann has designed the OWL router for wireless communication in

mobile networks that make use of the following technologies:

HSPA+

UMTS

EDGE

GPRS

Due to the high speed data transfer, up to 14.4 Mbit/s (download) and up to

5.76 Mbit/s (upload), this router is an ideal wireless solution for connecting

the data stream and security camera systems, individual computers, LAN

networks, automatic teller machines (ATM) and other self-service terminals.

As a standard, the router is supplied in a metal casing.

The cellular router is also equipped with the following interfaces located on

the front panel:

2 Fast Ethernet 10/100BaseTX ports, RJ45

2 SIM Cards readers, for 3 V and 1.8 V SIM cards

2 SMA antenna connectors, Main + Rx Div

1 Connector (2-pin) for the power supply adapter

1 Reset button

Configuring the cellular router is possible using a graphical user interface

which is password protected. The graphical user interface provides, after

logging in, detailed statistics about the activities of the router such as, signal

strength, and a detailed system log. This device supports the creation of VPN

tunnels using technologies such as IPSec, OpenVPN and L2TP for secure

communications. The router also supports the following functions:

DHCP

NAT

DynDNS

IPSec

OpenVPN

NTP

VRRP

control by SMS

primary/backup connection

Diagnostic functions, which provide for continuous communication, include

an automatic inspection of a PPP connection, offering an automatic restart

feature in case of an unexpected termination of the connection. Another

diagnostic function is the hardware watchdog, which monitors the status of

the router.

Autres manuels pour OWL3G

Table des matières

Autres manuels Hirschmann Routeur réseau

Hirschmann

Hirschmann RS20 series Manuel utilisateur

Hirschmann

Hirschmann OWL-IPG-AMERICAS Manuel utilisateur

Hirschmann

Hirschmann MACH104-16TX-PoEP+2X Series Manuel utilisateur

Hirschmann

Hirschmann RS30-...U Series Manuel utilisateur

Hirschmann

Hirschmann RS20 series Manuel utilisateur

Hirschmann

Hirschmann OWL LTE M12 Manuel utilisateur

Hirschmann

Hirschmann RSR20-0900 Manuel utilisateur

Hirschmann

Hirschmann RS20 series Manuel utilisateur

Hirschmann

Hirschmann MM2-2FXM3/2TX1 Manuel

Hirschmann

Hirschmann RS2-FX-LH/FX-LH Manuel

Hirschmann

Hirschmann RS2-5TX/FX Manuel

Hirschmann

Hirschmann MS30, Power MICE, MACH 4000, OCTOPUS Manuel utilisateur

Hirschmann

Hirschmann OCTOPUS OS3 Manuel utilisateur

Hirschmann

Hirschmann Power MICE Manuel utilisateur

Hirschmann

Hirschmann HiSecOS EAGLE20 Manuel utilisateur

Hirschmann

Hirschmann RS20 series Manuel utilisateur

Hirschmann

Hirschmann RS20 series Manuel utilisateur

Hirschmann

Hirschmann OCTOPUS 5TX-EEC Manuel

Hirschmann

Hirschmann MACH 4002 Family Manuel utilisateur

Hirschmann

Hirschmann RSB20-0800T1T1 Manuel utilisateur

Hirschmann

Hirschmann MACH 1020 Manuel utilisateur

Hirschmann

Hirschmann SPIDER 3TX-TAP Manuel

Hirschmann

Hirschmann OWL LTE M12 Manuel utilisateur

Hirschmann

Hirschmann MACH104-20TX-FR Series Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
