HIK VISION DS?2CD753F?E Manuel utilisateur

Hikvision Technical Manual

Network Camera

Technical Manual

Hikvision Technical Manual

Notices

The information in this documentation is subject to change without notice and does not represent any

commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data

that may appear in this documentation. The product(s) described in this documentation are furnished

subject to a license and may only be used in accordance with the terms and conditions of such license.

This documentation is issued in strict confidence and is to be used only for the purposes for

which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or

be used for any other purpose without prior written consent of HIKVISION and then only on the

condition that this notice is included in any such reproduction. No information as to the contents or

subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,

shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party

being an individual, firm, or company or any employee thereof without the prior written consent of

HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use

this product. HIKVISION reserves the right to make changes to its products as circumstances may

warrant, without notice.

This documentation is provided “as-is,” without warranty of any kind.

Please send any comments regarding the documentation to:

overseabusiness@hikvision.com

Find out more about HIKVISION at www.hikvision.com

Hikvision Technical Manual

DS-2CD753F-E(I)(Z)

Key Features

Up to 2 megapixel (1600 × 1200) resolution, and real time video encoding at HD 720P

Standard video compression with high compression ratio

Progressive scan CMOS, capture motion video without incised margin

Support e-PTZ

Support Motorized VF lens

Support dual stream, and the sub-stream for mobile surveillance

Up to 32 GB SD/SDHC card for on-board storage

Two-way audio

PoE (Power over Ethernet)

Auto-iris, electronic shutter for different surveillance environments

Support analog video output for adjustment and installation

3-axis (pan/tilt/rotation) positioning allows adjustment for optimum camera rotation and position

Impact Protection: IEC60068-2-75 test, Eh, 50J; EN50102, up to IK10

Other functions: heartbeat, PTZ control, alarm, reset button, mirror, etc.

Specification

Model

Parameter

DS-2CD753F-E(I)(Z)

2 Megapixel CMOS Vandal-proof Network Dome Camera

Camera

Image Sensor

1/3”Progressive Scan CMOS

Min.

Illumination

0.5 Lux @ (F1.2, AGC ON), 0.1 Lux @ (F1.2, AGC ON, sensitivity × 5)

-I: 0.5 Lux @ (F1.2, AGC ON), 0.1 Lux @ (F1.2, AGC ON, sensitivity × 5)

0 Lux with IR

Shutter Speed

1/25 s to 1/100,000 s

Lens

2.7-9mm @ F1.2,Angle of view: 101°-30.4°

Hikvision Technical Manual

-Z: Motorized VF lens, 2.7-9mm @ F1.2,Angle of view: 101°-30.4°

Lens Mount

Φ14

Auto-iris

DC drive

Angle

Adjustment

Pan:0°- 360°, Tilt: 0°- 75°, Rotation: 0°- 360°

Day & Night

Electronic (-I: IR cut filter with auto switch)

Compression Standard

Video

Compression

H.264/MPEG4/MJPEG

Bit Rate

32 Kbps –16 Mbps

Audio

Compression

G.711/G.726

Dual Stream

Yes


Max. Resolution

1600 x 1200

Frame Rate

50 Hz: 12.5 fps (1600 × 1200), 12.5 fps (1600 × 912), 25 fps (1280 × 960), 25

fps (1280 × 720)

60 Hz: 15 fps (1600 × 1200), 15 fps (1600 × 912), 25 fps (1280 × 960), 30 fps

(1280 × 720)

Image Setting

Saturation, Brightness, Contrast adjustable by client software or web

browser

Network

Network Storage

NAS (iSCSI optional)

Alarm Trigger

Motion detection, Video tampering, Network disconnect , IP address

conflict, Storage exception

Protocols

TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP,

SNMP, FTP, 802.1x, QoS, HTTPS ( SIP,SRTP,IPv6 optional )

Security

User Authentication, Watermark

Standard

ONVIF, PSIA, CGI

Interface

Audio Input

1-ch 3.5 mm audio interface, MIC IN/Line IN

Audio Output

1-ch 3.5 mm audio interface (Line level, 600 Ω)

Communication

Interface

1 RJ45 10M/100M Ethernet port and 1 RS-485 interface

Alarm Input

Alarm Output

Video Output

1Vp-p composite output (75 Ω/RCA)

On-board

storage

Built-in SD/SDHC slot, up to 32 GB

Reset Button

Yes

General

Hikvision Technical Manual

Operating

Conditions

-10 °C –60 °C (14 °F –140 °F)

Humidity 90% or less (non-condensing)

Power Supply

12 V DC ± 10%

PoE (802.3af)

Power

Consumption

4.5W~9.5W

(IR: 2W,Motorized VF lens: 3W)

IR Range

-I: Approx. 10 to 20 meters

Impact

Protection

IEC60068-275Eh, 50J; EN50102, up to IK10

Dimensions

Φ 140 × 114 mm (Φ 5.51” × 4.49”)

Weight

1400 g (3.09 lbs)

* “-Z” is equipped with Motorized VF lens

Order Models

DS-2CD753F-E, DS-2CD753F-EI

DS-2CD753F-EZ, DS-2CD753F-EIZ

Dimensions

Unit: mm

Accessories

Hikvision Technical Manual

Indoor in-ceiling mount Vandal-proof wall mount

DS-1227ZJ DS-1229ZJ
