HIK VISION 720TVL Manuel utilisateur

720TVL High Resolution

Day & Night Color Camera

Please read this manual thoroughly before use, and keep it handy for future reference.

INSTRUCTION MANUAL

WARNINGS AND CAUTIONS

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT

THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT.

EXPLANATION OF GRAPHICAL SYMBOLS

The lightning flash with arrowhead symbol, within an equilateral triangle,

is intended to alert the user to the presence of uninsulated ''dangerous

voltage'' within the product's enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of important operating and maintenance

(Servicing) instructions in the literature accompanying the product.

PRECAUTIONS

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICABLE PARTS INSIDE.

REFFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

Installation

Do not install the unit in an extremely hot or humid place or in a place subject to excessive dust, mechanical vibration.

Cleaning

Clean the unit with a slightly damp soft cloth.

Use a mild household detergent. Never use strong solvents such as thinner or benzene as they might damage the

finish of the unit.

Retain the original carton and packing materials for safe transport of this unit in the future.

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug.

A polarized plug has two blades with one wider than the other. A

grounding type plug has two blades and a third grounding prong. The

wide blade or the third prong are provided for your safety. If the provided

plug does not fit into your outlet, consult an electrician for replacement of

the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at

plugs, convenience receptacles, and the point where they exit from the

apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table

specified by the manufacturer, or sold with the apparatus.

When a cart is used, use caution when moving the

cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when

unused for long periods of time.

14. Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug

is damaged, liquid has been moisture, does not operate normally, or has

been dropped.

15. CAUTION –THESE SERVICING INSTRUCTIONS ARE FOR USE BY

QUALIFIED SERVICE PERSONNEL ONLY. TO REDUCE THE RISK OF

ELECTRIC SHOCK DO NOT PERFORM ANY SERVICING OTHER

THAN THAT CONTAINED IN THE OPERATING INSTRUCTIONS

UNLESS YOU QRE QUALIFIED TO DO SO.

16. Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed

Class 2 power source only.

FCC COMPLIANCE STATEMENT

CE COMPLIANCE STATEMENT

INFORMATION TO THE USER: THIS EQUIPMENT HAS BEEN TESTED AND

FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE,

PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO

PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN

THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS

EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY ENERGY

AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION

MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

CAUTION: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE

PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER'S AUTHORITY

TO OPERATE THE EQUIPMENT.

THIS CLASS A DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003.

CET APPAREIL NUMÉRIQUE DE LA CLASSE A EST CONFORME À LA NORME NMB-

003 DU CANADA.

WARNING: This is a Class A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take adequate

measures.

INTRODUCTION

The camera provides high-resolution images using 720TVL CMOS and digital

Signal processors.

Features:

●1/3" 720TVL CMOS for an image of high sensitivity

● 2.8-12mm Vari-Focal lens

●Excellent picture quality

●720 lines of horizontal resolution

●Auto electronic shutter

●Auto white balance modes

●Day & Night ( ICR-Filter )

●AGC ( Auto Gain Control )

●VIDEO OUT ( BNC )

●30M IR LED’s

●IP66 Ingress Rating

●Operates in 12VDC

( Power supply not included so please use a power supply capable of

supplying over 1,000mA.)

●Use Certified / Listed Class 2 power source only.

IMPORTANT: The user of this camera is responsible for

checking and complying with local, state, and federal laws

and statutes concerning the recording and monitoring of

audio signals.

INSTALLATION

Carefully remove the contents from the box, and verity that nothing was damaged in

shipment.

1) Mark the screw hole positions on the ceiling or wall surface using the Template

Sheet.

2) Disassemble the camera by removing the dome cover.

3) Mount the camera assembly using the Anchors (x2) and Screws (x2) to

the surface of the ceiling or wall.

4) Adjust Zoom and Focus.

EXTERNAL DIMENSION (mm)

SPECIFICATIONS

VIDEO

Image Device

1/3'' DIS

TV System

PAL/NTSC

Effective Pixels

853(H)×640(V)

Scanning System

Progressive

Synchronization

Internal

Horizontal Resolution

720TVL

Min. Illumination

0 Lux (IR LED on)

S/N Ratio

>52dB

Video Output

1Vp-p, 75ohm, BNC

LENS

Focal Length

2.8-12mm Vari-Focal Lens

OPERATIONAL

Day & Night

Auto (ICR)

Backlight Compensation

Auto

Gain control

Auto

White Balance

Auto

Electronic Shutter Speed

1/25 ~ 1/15,000sec

Infrared LED

36 EA

IR Distance

30 Meters

IR-CUT Filter

YES

Infrared Spectrum

850nm

ENVIRONMENTAL

Operation Temperature

-20℃~ +50℃

Water-proof Casing

IP66

ELECTRICAL

Input Voltage/Current

DC12V480mA

Adapter Requirement

DC12V1A

MECHANICAL

Color

white

Bracket

All-Oriented Bracket

Dimensions

135x105 mm

Net Weight

746g/pcs

720TVL Super High Resolution

Day & Night Color Camera
