Preface
Applicable Models
This manual is applicable to the DS-3WF Series wireless bridge.
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note Provides addional informaon to emphasize or supplement
important points of the main text.
Safety Instrucons
Cauon
●This is a class A product and may cause radio interference in which case the user may be
required to take adequate measures.
●No naked ame sources, such as lighted candles, should be placed on the equipment.
●The serial port of the equipment is used for debugging only.
●Install the equipment according to the instrucons in this manual.
●To prevent injury, this equipment must be securely aached to the oor/wall in accordance with
the installaon instrucons.
●Keep vercal downward when moving or using the equipment.
Warning
●In the use of the product, you must be in strict compliance with the electrical safety regulaons
of the naon and region.
●The socket-outlet shall be installed near the equipment and shall be easily accessible.
Wireless Bridge Quick Start Guide
vi
●Do not connect several devices to one power adapter as adapter overload may cause over-
heang or a re hazard.
●Please make sure that the plug is rmly connected to the power socket.
Wireless Bridge Quick Start Guide
vii
Contents
Chapter 1 Introducon ............................................................................................................... 1
1.1 Interface/Buon .................................................................................................................... 1
1.2 SSID ........................................................................................................................................ 2
1.3 Indicator ................................................................................................................................. 2
1.4 Packing List ............................................................................................................................. 3
Chapter 2 Installaon ................................................................................................................. 5
2.1 Preparaons for Installaon .................................................................................................. 5
2.2 Pole Mounng ....................................................................................................................... 5
2.3 Wall Mounng ....................................................................................................................... 7
2.4 Connecon and Power On ..................................................................................................... 8
2.4.1 AP Connecon ............................................................................................................... 9
2.4.2 CPE Connecon ............................................................................................................. 9
Chapter 3 Acvaon and Login ................................................................................................. 11
3.1 Acvaon Using Web Browser ............................................................................................. 11
3.2 Acvaon Using iVMS 4200 ................................................................................................. 11
Chapter 4 Get More Informaon .............................................................................................. 12
Wireless Bridge Quick Start Guide
viii
Chapter 1 Introducon
The 5 GHz gigabit wireless bridge (hereinaer referred to as the device) is used for long-distance
wireless connecon, which is suited for outdoor video security and transmission between sites in a
LAN. The device supports 16 SSIDs, point-to-point as well as point-to-mulpoint transmission.
1.1 Interface/Buon
Figure 1-1 Interface/Buon of Wireless Bridge
Table 1-1 Interface/Buon Descripon
Interface/Buon Descripon
CPE/AP DIP Switch Switch up or down to set the device as AP or CPE.
SSID 4-character SSID to realize 16 kinds of matching ways by switching up
or down. The CPE will connect to the AP when its SSID matches the
AP's.
Note
The AP's SSID should be unique.
PoE/LAN 1 The 10/100/1000 Mbps adapve RJ45 port, also can be used as a PoE
port.
LAN 2 The 10/100/1000 Mbps adapve RJ45 port.
Reset Long press for 4 sec to restore to factory sengs.
DC 12V If the PoE injector is not used for powering on the device, you can use
the aached power adapter to connect the device to socket.
Wireless Bridge Quick Start Guide
1
Autres manuels pour DS-3WF Series
2
Table des matières
Autres manuels HIK VISION Matériel réseau
HIK VISION
HIK VISION DS-7104NI-SL Manuel utilisateur
HIK VISION
HIK VISION DS-7600NI-E1/E2 series Manuel utilisateur
HIK VISION
HIK VISION Network Video Recorder Manuel utilisateur
HIK VISION
HIK VISION DS-MP7608HN Series Manuel utilisateur
HIK VISION
HIK VISION iDS-9664NXI-M8/X Manuel utilisateur
HIK VISION
HIK VISION DS-9600NI-I8 Series Manuel utilisateur
HIK VISION
HIK VISION DS-9600NI-SH Series Manuel utilisateur
HIK VISION
HIK VISION DS-7716NXI-I4/16P/4S Manuel utilisateur
HIK VISION
HIK VISION DS-1100KI(B) Manuel utilisateur
HIK VISION
HIK VISION UD.6L0202B1194A01 Guide de l'utilisateur
HIK VISION
HIK VISION DS-7716NI-I4/16P Manuel utilisateur
HIK VISION
HIK VISION HWN Series Manuel utilisateur
HIK VISION
HIK VISION S-7708NI-I4/8P Manuel utilisateur
HIK VISION
HIK VISION DS-9600NI-I8B Series Manuel utilisateur
HIK VISION
HIK VISION DS-7104NI-SL/W Guide de l'utilisateur
HIK VISION
HIK VISION DS-7600NI-K1/W Series Manuel utilisateur
HIK VISION
HIK VISION BCS-V-NVRXX02-4K Series Manuel utilisateur
HIK VISION
HIK VISION DS-7100NI-E1 Series Manuel utilisateur
HIK VISION
HIK VISION DS-7600NI-K2/4G Series Manuel utilisateur
HIK VISION
HIK VISION DS-9600 Series Guide de l'utilisateur
Manuels Matériel réseau populaires d'autres marques
Matrix Switch Corporation
Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur
B&B Electronics
B&B Electronics ZXT9-IO-222R2 Manuel utilisateur
Yudor
Yudor YDS-16 Manuel utilisateur
D-Link
D-Link ShareCenter DNS-320L Manuel utilisateur
Samsung
Samsung ES1642dc Instructions d'utilisation
Honeywell Home
Honeywell Home LTEM-PV Instructions de montage
