HIK VISION DS-D5032FL/D Manuel utilisateur

32 and 42-inch LCD Unit User Manual

DS-D5032FL

User Manual

UD00253N

32 and 42-inch LCD Unit User Manual

User Manual

About this Manual

This Manual is applicable to 32 and 42-inch LCD Unit.

The Manual includes instructions for using and managing the product. Pictures, charts, images and all

other information hereinafter are for description and explanation only. The information contained in

the Manual is subject to change, without notice, due to firmware updates or other reasons. Please find

the latest version in the company website

Please use this user manual under the guidance of professionals.

Legal Disclaimer

REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL

BE WHOLLY AT YOUR OWN RISKS. OUR COMPANY SHALL NOT TAKE ANY

RESPONSIBILITES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER

DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS INSPECTION,

OR OTHER INTERNET SECURITY RISKS; HOWEVER, OUR COMPANY WILL PROVIDE

TIMELY TECHNICAL SUPPORT IF REQUIRED.

SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS

IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT

YOUR USE CONFORMS THE APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE

IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE

LAW, THE LATER PREVAILS.

32 and 42-inch LCD Unit User Manual

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to comply with the limits for a digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used

in accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired

operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE"

and comply therefore with the applicable harmonized European standards listed

under the Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC.

2002/96/EC (WEEE directive): Products marked with this symbol cannot be

disposed of as unsorted municipal waste in the European Union. For proper

recycling, return this product to your local supplier upon the purchase of equivalent

new equipment, or dispose of it at designated collection points. For more

information see: www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery that cannot be disposed

of as unsorted municipal waste in the European Union. See the product documentation

for specific battery information. The battery is marked with this symbol, which may

include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper

recycling, return the battery to your supplier or to a designated collection point. For

more information see: www.recyclethis.info.

32 and 42-inch LCD Unit User Manual

iii

Safety Instruction

These instructions are intended to ensure that user can use the product correctly to avoid danger or property

loss.

The precaution measure is divided into “Warnings” and “Cautions”

Warnings: Serious injury or death may occur if any of the warnings are neglected.

Cautions: Injury or equipment damage may occur if any of the cautions are neglected.

Warnings

Proper configuration of all passwords and other security settings is the responsibility of the

installer and/or end-user.

In the use of the product, you must be in strict compliance with the electrical safety

regulations of the nation and region. Please refer to technical specifications for detailed

information.

Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited

Power Source with 100 to 240 VAC or 12 VDC according to the IEC60950-1 standard.

Please refer to technical specifications for detailed information.

Do not connect several devices to one power adapter as adapter overload may cause

over-heating or a fire hazard.

Please make sure that the plug is firmly connected to the power socket.

If smoke, odor or noise rise from the device, turn off the power at once and unplug the

power cable, and then please contact the service center.

Warnings Follow these safeguards

to prevent serious injury or death.

Cautions Follow these precautions to

prevent potential injury or material

damage.

32 and 42-inch LCD Unit User Manual

Table of Content

Chapter 1 Introduction...............................................................................................................5

1.1 Main Features...................................................................................................................5

1.2 Power Supply Connection................................................................................................ 6

Chapter 2 Device Interfaces....................................................................................................... 7

2.1 DS-D5032FL/D and DS-D5042FL/D............................................................................... 7

2.2 DS-D5032FL/S and DS-D5042FL/S................................................................................7

2.3 DS-D5032FL and DS-D5042FL....................................................................................... 8

Chapter 3 Panel Buttons............................................................................................................. 9

Chapter 4 Remote Control .......................................................................................................10

Chapter 5 Basic Operation....................................................................................................... 12

5.1 Input Source................................................................................................................... 12

5.2 Main Menu..................................................................................................................... 13

5.2.1 Image Parameters......................................................................................................13

5.2.2 Overscan ................................................................................................................... 17

5.2.3 System Information and Maintenance.......................................................................18

5.2.4 Settings .....................................................................................................................20

5.3 USB Menu...................................................................................................................... 25

Chapter 6 Appendix: ................................................................................................................26

6.1 Specifications.................................................................................................................26

6.2 Structure Diagram.......................................................................................................... 30

32 and 42-inch LCD Unit User Manual

IntroductionChapter 1

1.1Main Features

8 bit/10 bit 2-ch LVDS(1920×1080) HD display

3-D digital comb filter

True color OSD and user-friendly operation menu

Mstar ACE-5 auto color and image enhancement engine, improve the image contrast, details,

color of skin and edges, and so on

Programmable 12-bit RGB gamma correction technology

1-ch HDMI with1.3 input interface

HDCP 1.2

Spread-spectrum technology reduces EMI radiation

Adopt 3D noise reduction technology

High definition JPEG decoding

BNC interface with professional monitoring standard supports 1-ch BNC video input

Support multimedia playing: text, image, audio, video, and so on

Signal source decoding (DS-5032FL/D and DS-D5042FL/D)

SDI signal input and output (DS-5032FL/S and DS-D5042FL/S)

32 and 42-inch LCD Unit User Manual

1.2Power Supply Connection

Insert the power adapter into the well-grounded socket and turn the power switch on.

Figure 1.1 Power Adapter

Power Adapter

Input Voltage

100 to 240VAC

Output Voltage

12 V

Output Current

3.33 A

Output Power

40 W

Power adapter shall operate within input specification from 100V AC to 240V AC or

provide automatic switching between high line and low line input ranges.

Turn off the main power switch of the LCD unit, and pull the plug from the power outlet

if the LCD unit will not be used for a long time.

Never connect the device to a DC power.

32 and 42-inch LCD Unit User Manual

Device InterfacesChapter 2

2.1DS-D5032FL/D and DS-D5042FL/D

Figure 2.1 Rear Panel (1)

Table 2. 1 Interface Description

Interfaces

Description

FIBER

Optical fiber interface

LAN

Network interface

HDMI IN

HDMI digital signal input

DVI IN

DVI digital signal input

VGA IN

VGAanalog signal input

CVBS/IN

Composite video input

USB

USB interface

RS232 IN

Serial port input

AUDIO IN

Audio input

AUDIO OUT

Audio output

2.2DS-D5032FL/S and DS-D5042FL/S

Figure 2. 1 Rear Panel (2)

32 and 42-inch LCD Unit User Manual

Table 2. 2 Interface Description

Interfaces

Description

SDI IN

SDI signal input

SDI OUT

SDI signal output

HDMI IN

HDMI digital signal input

DVI IN

DVI digital signal input

VGA IN

VGAanalog signal input

CVBS/IN

Composite video input

USB

USB interface

RS232 IN

Serial port input

AUDIO IN

Audio input

AUDIO OUT

Audio Output

2.3DS-D5032FL and DS-D5042FL

Figure 2. 2 Rear Panel (3)

Table 2. 3 Interface Description

Interfaces

Description

HDMI IN

HDMI digital signal input

DVI IN

DVI digital signal input

VGA IN

VGAanalog signal input

CVBS/IN

Composite video input

USB

USB interface

RS232 IN

Serial port input

AUDIO IN

Audio input

AUDIO OUT

Audio output

32 and 42-inch LCD Unit User Manual

Panel ButtonsChapter 3

Buttons on lower right corner of the LCD unit panel are shown as the Figure 3.1.

Figure 3.1 Buttons on the Display Unit

Table 3. 1 Button Description

Buttons

Description

SOURCE

Press to show source menu

Press to show Menu

UP/DOWN

Press to move the cursor up/down

LEFT/RIGHT

Press to move the cursor left/right

POWER

Press to confirm/start up; hold down to shut down
