HIK VISION DS-D5032 Series Manuel utilisateur

32/40-inch LCD Display Unit

User Manual

G6AUM315000009

Thank you for purchasing our product. If there is any question or request, please do not hesitate to

content is subject to change without notice. The updates will be added into the new version of

this manual. We will readily improve or update the products or described in the manual.

Ⅰ

Regulatory Information

2002/96/EC (WEEE directive): Products marked with this

symbol cannot be disposed of as unsorted municipal waste in the

European Union. For proper recycling, return this product to

your local supplier upon the purchase of equivalent new

equipment, or dispose of it at designated collection points. For

more information see: www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery

that cannot be disposed of as unsorted municipal waste in the

European Union. See the product documentation for specific

battery information. The battery is marked with this symbol, which may

include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For

proper recycling, return the battery to your supplier or to a designated

collection point. For more information see: www.recyclethis.info.

EU Conformity Statement

This product and - if applicable - the supplied accessories too

are marked with"CE"and comply therefore with the applicable

harmonized European standards listed under the EMC Directive

2014/30/EU,the LVD Directive 2014/35/EU,the ROHS

Directive 2011/65/EU.

III

Hikvision® 32/40-inch LCD Display Unit User’s Manual

This manual, as well as the software described in it, is furnished under license and may be

used or copied only in accordance with the terms of such license. The content of this

manual is furnished for informational use only, is subject to change without notice, and

should not be construed as a commitment by Hikvision Digital Technology Co., Ltd.

(Hikvision). Hikvision assumes no responsibility or liability for any errors or inaccuracies

that may appear in the book.

Except as permitted by such license, no part of this publication may be reproduced, stored

in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical,

recording, or otherwise, without the prior written permission of Hikvision.

HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT

LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE, REGARDING THE HIKVISION SOFTWARE. HIKVISION DOES NOT

WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE USE OR THE

RESULTS OF THE USE OF THE HIKVISION SOFTWARE IN TERMS OF ITS CORRECTNESS,

ACCURACY, RELIABILITY, CURRENTNESS, OR OTHERWISE. THE ENTIRE RISK AS TO THE

RESULTS AND PERFORMANCE OF THE HIKVISION SOFTWARE IS ASSUMED BY YOU. THE

EXCLUSION OF IMPLIED WARRANTIES IS NOT PERMITTED BY SOME STATES. THE ABOVE

EXCLUSION MAY NOT APPLY TO YOU.

IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE

LIABLE TO YOU FOR ANY CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES

(INCLUDING DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS

OF BUSINESS INFORMATION, AND THE LIKE) ARISING OUT OF THE USE OR INABILITY TO

USE THE HIKVISION SOFTWARE EVEN IF HIKVISION HAS BEEN ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION

OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE

LIMITATIONS MAY NOT APPLY TO YOU.

TABLE OF CONTENTS

Important safeguards ............................................................................... 2

Introduction ............................................................................................... 4

Features ..................................................................................................... 5

Assembling the monitor ........................................................................... 6

Wall hanging Standard ............................................................................. 7

The function of the interface ................................................................... 7

Front panel controls ................................................................................. 8

Control panel .............................................................................................. 8

Changing a monitor parameter ................................................................. 9

Hot keys .................................................................................................... 9

Adjustment procedure ............................................................................ 9

OSD function ........................................................................................... 10

VGA menu ................................................................................................ 10

Cam menu ................................................................................................ 12

HDMI menu ............................................................................................... 13

Self-diagnosis.......................................................................................... 21

Troubleshooting...................................................................................... 22

Specifications.......................................................................................... 23

DVI menu.................................................................................................. 15

IMPORTANT SAFEGUARDS

1. Installation cautions

•Do not block any ventilation openings.

•Always ensure that the monitor is located in a well-ventilated area topreventthe

unit from overheating.

•Only use accessories specified bythe manufacturer orthose sold with the product

•Avoid operating or placing the monitor in the following environments:extremes of

temperatures, both hot and cold; high humidity; direct sunlight;excessivelydusty

surroundings; avoid close proximity to other equipment that generates astrong

magnetic field

2. Water and moisture

Do not use this appliance near water. To reduce the risk of fire or electric shock,do

not expose this unit to rain ormoisture.

3. Power cord and power cord protection

Power cords should be routed so that they not likely to be walked on or pinched. Pay

particular attention to the location of cords and plugs, convenience receptacles, and

the point of exit from theappliance.

4. Product care

Do not touch the screen directly with fingers. The oils from your skinmayleave

marks on the surface of the screen, which are difficult to be removedandmay

damage the screen permanently. Do not apply pressure to thescreen.

5. Cleaning

Clean only with a drycloth.

6. Servicing

Do notattempt to service this unit yourself. Opening orremoving covers mayexpose

you to dangerous voltage or other hazards. Refer all servicing to qualifiedservice

personnel.

7. Lightning

For added protection during a lighting storm or when this unit is left unattended and

unused for long periods of time, unplug the unit from the wall outletanddisconnect

the cable system. This will prevent damage to the unit due to lightningandpower

line surges.

IMPORTANT SAFEGUARDS

8. Mains plug (2 pin/3 pin)

•Do not remove the grounding or earth connection from the power supply /mains

plug.

•Always remember to unplug the monitor from the power supply underthe

following circumstances if the monitor will not be used for a long period of time, if

the power supply cable or plug/connector is damaged or if the monitorhousingis

damaged or broken.

CAUTION: Do not attempt to dismantle this product. Any attempt to dismantle

or remove the covers from this product will invalidate the warranty and may also

result in serious injury.

INTRODUCTION

This manual explains how to correctly install, operate and get thebestperformance

from your monitor. Please read this user manual carefully before installingyour

monitor then keep it near your monitor for quick reference. First, please checkthat

the contents of the box correspond with the followingchecklist:

•LCD monitor

•Power cord

•VGA cable

•Remote control(optional)

•User manual

If any item is missing or damaged, please contact your dealer. Please keepthebox

and packing materials so that you may properly store or transportyourmonitor.

•HDMI cable(optional)

•Audio cable(optional)

FEATURES

•The monitor is designed foruse in a small work area or for those who need more

work space on the desk.

•The convenient and user-friendly onscreen display allows for easy andaccurate

adjustments of screen size, position and screencolor.

•The monitor complies with the VESA Display Data Channel (DDC)specification

for Plug and Play compatibility. Advanced microcircuitry makes setupand

configuration fast and effortless.

•The monitor features Advanced Color Controls for fine-tuning to meet yourown

personal tastes or application requirements. Use the on-screen controls to adjust

the color temperature,

•RGB gain value for the best possible screen color andintensity.

• Press the Menu button and activate the Self-Diagnosis menu todetermine

whether your monitor is functioning normally, not receiving a signal oris

receiving a signal that is out of scanning range.

•Activate the higher refresh rates of the monitor to stabilize the screenand

eliminate the annoying flicker that contributes to eye-strain andheadaches.

•The monitor supports the optimal display performance with 1920x1080 @ 60 Hz

•The monitor can be connected to various types of video devices withsupporting

video input signals such as Composite video (CVBS), and Separatevideo.

•The internal stereo speakers produce a good quality audiosound.

ASSEMBLING THE MONITOR

The monitors are designed for use on adesktop.

The arm of the monitor stand is shipped preinstalled on themonitor.

To assemble the monitor:

1. Put a smooth pad or cloth on a level surface. Place the monitor on itfacing

downwards.

2. Insert the arm of the monitor stand of the monitorinto the pedestal foot provided.

See figures below.

To disassemble the monitor:

1. Put a smooth pad or cloth on a level surface. Place the monitor on itfacing

downwards.

2. Shrapnel with fingersorsimilar objects hold the base below, carefullydetach

the supporting arm from the foot by pressing the groove on the back ofthe

supporting arm. (Note that the fixation point can be broken if too much forceis

applied). See figures below.
