HIK VISION DS-KIS202 Manuel utilisateur

DS-KIS202

Video Door Phone

Key Features

Door Station

Self-adaptive IR supplement

One-touch calling

Pinhole camera with 720 x 576 @ 25 fps

Unlock controlling

Indoor Station

Hands-free video intercom communication

Supports monitoring the door station and the external analog camera

Remote unlocking

Convenient installation and easy operation

Typical Application

Door Station

Indoor Station 2

Indoor Station 3

Indoor Station 1

Analog Camera 3

Analog Camera 2

Analog Camera 1

Lock

Four-Core Cable

Block to BNC Cable

Electric Lock

Connection Cable

Video Door Phone Model

DS-KIS202

Door Station (DS-KB2411-IM)

Video Parameters

Camera

1/4" CMOS

Resolution

720 × 576

Video frame rate

PAL: 25 fps

Audio parameters

Audio input

Built-in Omnidirectional Microphone

Audio output

Built-in Loudspeaker

Audio quality

Noise Suppression and Echo Cancellation

Light Supplement

Light supplement mode

Photosensitive IR Supplement, IR Range: 2 Meters

Device interfaces

Four-wire interface

1 Four-Wire Interface (1-ch Video Input, 1-ch Audio Input/Output, 1-ch Power

Supply, 1-ch Grounding)

IO output

1 Relay Output

General

Material

Aluminum Alloy

Power consumption

Max. 3W

Working temperature

-30°C to +60°C (-22°F to 140°F)

Working humidity

10% to 90%

Dimension (L x W x H)

128 mm × 42 mm × 24.8 mm (5.0" × 1.7" × 0.9")

Indoor Station (DS-KH2220)

Display parameters

Display screen

7-Inch Colorful TFT LCD

Display resolution

800 × 480

Operation method

Physical Button

Audio parameters

Audio input

Built-in Omnidirectional Microphone

Audio output

Built-in Loudspeaker

Audio quality

Noise Suppression and Echo Cancellation

Device interfaces

Four-wire interface

4 Four-Wire Interfaces

1-ch Video Input, 1-ch Audio Input/Output, 1-ch Power Supply, 1-ch Grounding

General

Power supply

12 VDC

Power consumption

≤5 W

Working temperature

-10°C to + 55°C (14°F to 131°F)

Working humidity

10% to 90%

Dimension (L x W x H)

195.8 mm × 132.8 mm × 18.39 mm (7.7" × 5.2" ×0.7")

Specifications

Index

Description

Microphone

Built-in Camera

Supplement Light

Photoresistor

Call Button

Loudspeaker

Index

Description

Power Supply Indicator

Call Accept/Decline Key

Unlock Key

Live View Key

Switch Key

LCD Display Screen

Microphone

Appearance and Interfaces

0100001070123

Door Station Indoor Station

Video Door Phone

Door Station and Indoor Station

User Manual

UD03871B

Video Door Phone·User Manual

User Manual

This user manual is intended for users of the models below:

Series

Model

Door Station

DS-KB2411-IM

Indoor Station

DS-KH2220

It includes instructions on how to use the Product. The software embodied in the

Product is governed by the user license agreement covering that Product.

About this Manual

This Manual is subject to domestic and international copyright protection. Hangzhou

Hikvision Digital Technology Co., Ltd. (“Hikvision”) reserves all rights to this manual. This

manual cannot be reproduced, changed, translated, or distributed, partially or wholly, by

any means, without the prior written permission of Hikvision.

Trademarks

and other Hikvision marks are the property of Hikvision and are

registered trademarks or the subject of applications for the same by Hikvision and/or its

affiliates. Other trademarks mentioned in this manual are the properties of their

respective owners. No right of license is given to use such trademarks without express

permission.

Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HIKVISION MAKES NO WARRANTIES,

EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, REGARDING THIS MANUAL.

HIKVISION DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE

USE OF THE MANUAL, OR THE CORRECTNESS, ACCURACY, OR RELIABILITY OF INFORMATION

CONTAINED HEREIN. YOUR USE OF THIS MANUAL AND ANY RELIANCE ON THIS MANUAL SHALL BE

WHOLLY AT YOUR OWN RISK AND RESPONSIBILITY.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT WILL HIKVISION, ITS

DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL,

CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES

FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, SECURITY BREACHES, OR LOSS OF DATA

OR DOCUMENTATION, IN CONNECTION WITH THE USE OF OR RELIANCE ON THIS MANUAL, EVEN IF

HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY OR CERTAIN

DAMAGES, SO SOME OR ALL OF THE ABOVE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU.

Support

Should you have any questions, please do not hesitate to contact your local dealer.

Video Door Phone·User Manual

Safety Instruction

These instructions are intended to ensure that user can use the product correctly to

avoid danger or property loss.

The precaution measure is divided into Warnings and Cautions:

Warnings: Neglecting any of the warnings may cause serious injury or death.

Cautions: Neglecting any of the cautions may cause injury or equipment damage.

Warnings

All the electronic operation should be strictly compliance with the electrical safety

regulations, fire prevention regulations and other related regulations in your local

region.

Please use the power adapter, which is provided by normal company. The power

consumption cannot be less than the required value.

Do not connect several devices to one power adapter as adapter overload may cause

over-heat or fire hazard.

Please make sure that the power has been disconnected before you wire, install or

dismantle the device.

When the product is installed on wall or ceiling, the device shall be firmly fixed.

If smoke, odors or noise rise from the device, turn off the power at once and unplug

the power cable, and then please contact the service center.

If the product does not work properly, please contact your dealer or the nearest

service center. Never attempt to disassemble the device yourself. (We shall not

assume any responsibility for problems caused by unauthorized repair or

maintenance.)

Cautions

Do not drop the device or subject it to physical shock, and do not expose it to high

electromagnetism radiation. Avoid the equipment installation on vibrations surface or

places subject to shock (ignorance can cause equipment damage).

Do not place the device in extremely hot (refer to the specification of the device for

the detailed operating temperature), cold, dusty or damp locations, and do not

expose it to high electromagnetic radiation.

The device cover for indoor use shall be kept from rain and moisture.

Warnings Follow

these safeguards to

prevent serious

injury or death.

Cautions Follow these

precautions to prevent

potential injury or

material damage.

Video Door Phone·User Manual

iii

Exposing the equipment to direct sun light, low ventilation or heat source such as

heater or radiator is forbidden (ignorance can cause fire danger).

Do not aim the device at the sun or extra bright places. A blooming or smear may

occur otherwise (which is not a malfunction however), and affecting the endurance of

sensor at the same time.

Please use the provided glove when open up the device cover, avoid direct contact

with the device cover, because the acidic sweat of the fingers may erode the surface

coating of the device cover.

Please use a soft and dry cloth when clean inside and outside surfaces of the device

cover, do not use alkaline detergents.

Please keep all wrappers after unpack them for future use. In case of any failure

occurred, you need to return the device to the factory with the original wrapper.

Transportation without the original wrapper may result in damage on the device and

lead to additional costs.

Improper use or replacement of the battery may result in hazard of explosion.

Replace with the same or equivalent type only. Dispose of used batteries according to

the instructions provided by the battery manufacturer.

Video Door Phone·User Manual

Table of Contents

1 Introduction .................................................................................................1

1.1 Overview.................................................................................................................. 1

1.2 Features ................................................................................................................... 1

2 Appearance Description ...............................................................................2

2.1 Indoor Station.......................................................................................................... 2

2.2 Door Station............................................................................................................. 2

3 Terminals and Wirings..................................................................................3

3.1 Terminals and Interfaces.......................................................................................... 3

3.2 Wiring Description................................................................................................... 4

3.2.1 Wiring 1 (1 Door Station and 1 Indoor Station)................................................. 5

3.2.2 Wiring 2 (1 Door Station and 3 Indoor Stations)............................................... 5

3.2.3 Wiring 3 (2 Door Stations and 3 Indoor Stations) ............................................. 6

4 Installation ...................................................................................................7

4.1 Indoor Station Installation ....................................................................................... 7

4.2 Door Station Installation.......................................................................................... 8

5 Local Operation .......................................................................................... 11

5.1 Door Station Local Operation ................................................................................ 11

5.2 Indoor Station Local Operation.............................................................................. 11

Appendix ...................................................................................................... 12

Installation Notice ....................................................................................................... 12

Specification ................................................................................................................ 12

Specification of DS-KH2220...................................................................................... 12

Specification of DS-KB2411-IM ................................................................................ 13

Video Door Phone·User Manual

1Introduction

1.1 Overview

The video door phone is composed of a

four-wire indoor station and a four-wire

door station. Featuring in the convenient

installation and easy operation, it is mainly

applied in the buildings for improving the

living security.

1.2 Features

Indoor Station Features

Hands-free video intercom communication

Supports three indoor stations simultaneously in the intercom system

Supports monitoring the door station and the external analog camera

Remote unlocking

Convenient installation and easy operation

Door Station Features

Hands-free video intercom communication

Supports two door stations simultaneously in the intercom system

Self-adaptive IR supplement (with photoresistor)

One-touch calling

Pinhole camera with 720 x 576 @ 25 fps

Unlock controlling

Anti-oxidant aluminium alloy

Convenient installation and easy operation

Video Door Phone·User Manual

2Appearance Description

2.1 Indoor Station

Figure 2-1 Indoor Station Appearance

Table 2-1 Components Description

No.

Description

Power Supply Indicator

Call Accept/Decline Key

Unlock Key

Live View Key

Switch Key

LCD Display Screen

Microphone

Terminals and Interfaces

Loudspeaker

Volume Control Knob

2.2 Door Station

Figure 2-2 Door Station Appearance

Table 2-2 Components Description

No.

Description

Microphone

Built-in Camera

IR Supplement Lights

Photoresistor

Call Button

Loudspeaker

Table des matières

Autres manuels HIK VISION Système d'interphone

HIK VISION

HIK VISION DS-KD3002-VM Manuel utilisateur

HIK VISION

HIK VISION DS-KV8213-WME1 Manuel utilisateur

HIK VISION

HIK VISION HYU-559 Manuel utilisateur

HIK VISION

HIK VISION DS-KIS603-P(B) Manuel utilisateur

HIK VISION

HIK VISION DS-KIS703-P Manuel utilisateur

HIK VISION

HIK VISION DS-TMC403-E Manuel utilisateur

HIK VISION

HIK VISION DS-KH6210(L) Manuel utilisateur

HIK VISION

HIK VISION DS-KB2421-IM Manuel utilisateur

HIK VISION

HIK VISION DS-1350HMI Manuel utilisateur

HIK VISION

HIK VISION DS-KD8002-VM Manuel utilisateur

HIK VISION

HIK VISION DS-KIS101-P/FLUSH Manuel utilisateur

HIK VISION

HIK VISION DS-KIS202T Manuel utilisateur

HIK VISION

HIK VISION DS-KV9503-WBE1 Manuel utilisateur

HIK VISION

HIK VISION Villa IP Instructions d'utilisation

HIK VISION

HIK VISION DS-KD9203 Series Manuel utilisateur

HIK VISION

HIK VISION ADS-24S-12 1224GPCN Manuel utilisateur

HIK VISION

HIK VISION DS-KH9310-WTE1B Manuel utilisateur

HIK VISION

HIK VISION DS-KH6320-WTE1-W Manuel utilisateur

HIK VISION

HIK VISION DS-KV8102-IM Manuel utilisateur

HIK VISION

HIK VISION DS-KV8102-IM Manuel utilisateur

HIK VISION

HIK VISION DS-KH6310-W Manuel utilisateur

HIK VISION

HIK VISION ADS-24S-12 1224GPCN Manuel utilisateur

HIK VISION

HIK VISION DS-KV8102-1A Manuel utilisateur

HIK VISION

HIK VISION DS-KH6320-LE1/White Manuel utilisateur

Manuels Système d'interphone populaires d'autres marques

Bticino

Bticino LINEA 3000 Manuel utilisateur

MSI

MSI MSI-140 Manuel utilisateur

golmar

golmar Stadio Plus Manuel utilisateur

CyberData

CyberData 011211 series Manuel

Vidos

Vidos duo M1021 Manuel utilisateur

Vimar

Vimar ELVOX 7539/E Manuel utilisateur

SSS Siedle

SSS Siedle BTSV 850-03 Manuel utilisateur

Dahua

Dahua VTO Series Manuel utilisateur

Elvox

Elvox 5651 Manuel utilisateur

Videx

Videx VIDEOKIT Series Manuel utilisateur

Rocom

Rocom Doortello Business FW T2.05W2.04 Manuel utilisateur

Viking

Viking E-35-EWP Manuel utilisateur

Safeguard Supply

Safeguard Supply LRA-EX1000 Manuel utilisateur

SSS Siedle

SSS Siedle BFCV 850 Series Manuel utilisateur

GRD

GRD MAX V2 Manuel utilisateur

Alecto

Alecto ADI-250 Manuel utilisateur

Aiphone

Aiphone IE-8MD Manuel utilisateur

Perel

Perel EDB4 Manuel utilisateur
