HIK VISION DS-7604-HI-ST Manuel utilisateur

Digital Video Recorder

User Manual

UD.6L0202D1124A01

User manual for HIKVision Hybrid DVR NVR DS-7604-HI-ST, DS-76-08-HI-ST, DS-7616HI-ST

Lo-Call 1890 866 900 www.cctvireland.ie

[email protected]

User Manual of Digital Video Recorder

Hikvision® Network Digital Video Recorder User Manual

This manual, as well as the software described in it, is furnished under license and may be used or copied only in

accordance with the terms of such license. The content of this manual is furnished for informational use only, is subject

to change without notice, and should not be construed as a commitment by Hangzhou Hikvision Digital Technology Co.,

Ltd. (Hikvision). Hikvision assumes no responsibility or liability for any errors or inaccuracies that may appear in the

book.

Except as permitted by such license, no part of this publication may be reproduced, stored in a retrieval system, or

transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written

permission of Hikvision.

HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE

IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,

REGARDING THE HIKVISION SOFTWARE. HIKVISION DOES NOT WARRANT, GUARANTEE, OR MAKE

ANY REPRESENTATIONS REGARDING THE USE OR THE RESULTS OF THE USE OF THE HIKVISION

SOFTWARE IN TERMS OF ITS CORRECTNESS, ACCURACY, RELIABILITY, CURRENTNESS, OR

OTHERWISE. THE ENTIRE RISK AS TO THE RESULTS AND PERFORMANCE OF THE HIKVISION

SOFTWARE IS ASSUMED BY YOU. THE EXCLUSION OF IMPLIED WARRANTIES IS NOT PERMITTED BY

SOME STATES. THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.

IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO

YOU FOR ANY CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES (INCLUDING DAMAGES FOR

LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, AND THE

LIKE) ARISING OUT OF THE USE OR INABILITY TO USE THE HIKVISION SOFTWARE EVEN IF HIKVISION

HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES DO NOT

ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL

DAMAGES, THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.

Lo-Call 1890 866 900 www.cctvireland.ie

[email protected]

User Manual of Digital Video Recorder

Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer.

This manual is applicable to following embedded network DVR series.

Series

Model

Type

7600HI-ST Series

DS-7604/08/16HI-ST

Network HDVR

This manual may contain several technically incorrect places or printing errors, and the content is subject to change

without notice. The updates will be added into the new version of this manual. We will readily improve or update the

products or procedures described in the manual.

In order to simplify the description, we make the following conventions (unless otherwise stated):

We define DS-7600HI-ST series as HDVR (Hybrid DVR) in this manual.

The figures shown in this manual are for reference only. The appearance and interface of the device are subject to the

actual model.

Lo-Call 1890 866 900 www.cctvireland.ie

[email protected]

User Manual of Digital Video Recorder

Regulatory information

FCC information

FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

FCC conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the

applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC, the EMC Directive

2004/108/EC, the RoHS Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in

the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new

equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in

the European Union. See the product documentation for specific battery information. The battery is marked with this

symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return

the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info.

Lo-Call 1890 866 900 www.cctvireland.ie

[email protected]

User Manual of Digital Video Recorder

Preventive and Cautionary Tips

Before connecting and operating your device, please be advised of the following tips:

•Ensure unit is installed in a well-ventilated, dust-free environment.

•Unit is designed for indoor use only.

•Keep all liquids away from the device.

•Ensure environmental conditions meet factory specifications.

•Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of dropping it

may cause damage to the sensitive electronics within the unit.

•Use the device in conjunction with an UPS if possible.

•Power down the unit before connecting and disconnecting accessories and peripherals.

•A factory recommended HDD should be used for this device.

•Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or

equivalent type only. Dispose of used batteries according to the instructions provided by the battery

manufacturer.

Lo-Call 1890 866 900 www.cctvireland.ie

[email protected]

User Manual of Digital Video Recorder

Product Key Features

General

Connectable to the network cameras, network dome and encoders.

Connectable to the third-party network cameras like ACTI, Arecont, AXIS, Brickcom, Bosch,

Canon, PANASONIC, Pelco, SAMSUNG and SANYO, SONY, Vivotek and ZAVIO.

Connectable to the third-party cameras that adopt ONVIF or PSIA protocol.

PAL/NTSC adaptive video inputs.

H.264 video compression with high reliability and superior definition.

Each channel supports dual-stream.

Up to 32 network cameras can be added.

Independent configuration for each channel, including resolution, frame rate, bitrate, image quality,

etc.

The quality of the input and output video is configurable.

Each channel supports two kinds of compression parameters, the normal continuous and event.

Sub-stream can be configured locally.

Encoding for both audio/video composite stream and video stream; audio and video

synchronization during composite stream encoding.

Support CABAC (this feature is supported by analog cameras only).

Watermark technology.

Local Monitoring

Simultaneous HDMI, VGA and CVBS outputs.

HDMI output and VGAoutput at up to 1920×1080P resolution.

1/4/6/8/9/16-division live view is supported, and the display sequence of screens is adjustable.

Live view screen can be switched in group, and manual switch and auto-switch review is also

provided, the interval of auto-switch can be adjusted.

Quick setting menu is provided for live view.

The selected live view channel can be shielded.

Motion detection, video tampering, video exception alarm and video loss alarm functions.

Privacy mask.

Several PTZ protocols supported; PTZ preset, patrol and pattern.

Zooming in by clicking the mouse and PTZ tracing by dragging mouse.

HDD Management

Up to 2 SATA hard disks can be connected, each disk with a maximum of 4TB storage capacity.

8 network disks (8 NAS disks, or 7 NAS disks+1 IP SAN disk) can be connected.

HDD group management.

HDD property: redundancy, read-only, read/write (R/W).

HDD quota management; different capacity can be assigned to different channel.

Support S.M.A.R.T. and bad sector detection.

Recording and Playback

Provide new playback interface with easy and flexible operation.

Holiday recording schedule configuration.

Normal and event video encoding parameters.

Multiple recording types: manual, normal, alarm, motion, motion | alarm, motion & alarm.

Lo-Call 1890 866 900 www.cctvireland.ie

[email protected]

User Manual of Digital Video Recorder

8 recording time periods with separated recording types.

Pre-record and post-record for alarm, motion detection recording, and pre-record time for schedule

and manual recording.

Searching record files by events (alarm input/motion detection).

Customization of tags, searching and playing back by tags.

Locking and unlocking record files.

Local redundant recording.

Searching and playing back record files by camera No., recording type, start time, end time, etc.

Smart search for the selected area in the video.

Zooming in when playback.

Reverse playback for multi-channel.

Supports pause, fast forward, slow forward, skip forward, and skip backward when playback,

locating by dragging the mouse.

Up to 16-ch synchronous playback at WD1 real time.

Backup

Export video data by USB, or SATA device.

Export video clips when playback.

Management and maintenance of backup devices.

Support NTFS and FAT32 formatted backup devices.

Alarm and Exception

Configurable arming time of alarm input/output.

Alarm for video loss, motion detection, tampering, abnormal signal, video input/output standard

mismatch, illegal login, network disconnected, IP confliction, abnormal record, HDD error, and

HDD full, etc.

Alarm triggers full screen monitoring, audio alarm, notifying surveillance center, sending email

and alarm output.

Automatic restore when system is abnormal.

Other Local Functions

Users can operate by mouse and IR remote control.

Three-level user management; admin user is allowed to create many operating accounts and define

their operating permission, which includes the limit to access any camera.

Operation, alarm, exceptions and log recording and searching.

Manually triggering and clearing alarms.

Importing and exporting of device configuration file.

Network Functions

1 self-adaptive 10M/100M/1000M (10M/100M for DS-7604HI-ST) network interface.

IPv6 is supported.

TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, and iSCSI are

supported.

TCP, UDP and RTP for unicast.

Auto/Manual port mapping and automatically discovered by UPnP™.

Remote web browser access by HTTPS ensures high security.

Remote reverse playback by RTSP.

Support accessing by the platform by ONVIF.

Remote search, playback, download, locking and unlocking the record files, and downloading files

Lo-Call 1890 866 900 www.cctvireland.ie

[email protected]

User Manual of Digital Video Recorder

broken transfer resume.

Remote parameters setup; remote import/export of device parameters.

Remote viewing of the device status, system logs and alarm status.

Remote locking and unlocking of control panel and mouse.

Remote HDD formatting and program upgrading.

Remote system restart.

RS-485 transparent channel transmission.

Alarm and exception information can be sent to the remote host

Remotely start/stop recording.

Remotely start/stop alarm output.

Upgraded by remote FTP server is supported.

Remote PTZ control.

Remote JPEG capture.

Two-way voice talk and voice broadcasting.

Embedded WEB server.

Development Scalability:

SDK for Windows and Linux system.

Source code of application software for demo.

Development support and training for application system.

Lo-Call 1890 866 900 www.cctvireland.ie

[email protected]

User Manual of Digital Video Recorder

TABLE OF CONTENTS

Product Key Features.........................................................................................................5

Chapter 1 Introduction....................................................................................................12

1.1 Front Panel............................................................................................................13

1.2 IR Remote Control Operations..............................................................................14

1.3 USB Mouse Operation..........................................................................................17

1.4 Input Method Description .....................................................................................18

1.5 Rear Panel .............................................................................................................19

1.6 Starting Up and Shutting Down the Device..........................................................20

Chapter 2 Getting Started ...............................................................................................21

2.1 Using the Wizard for Basic Configuration............................................................22

2.2 Adding and Connecting the IP Cameras................................................................25

2.2.1 Adding the Online IP Cameras.................................................................25

2.2.2 Configuring the Connected IP Cameras...................................................28

Chapter 3 Live View.........................................................................................................32

3.1 Introduction of Live View.....................................................................................33

3.2 Operations in Live View Mode.............................................................................34

3.2.1 Using the Mouse in Live View.................................................................34

3.2.2 Using anAuxiliary Monitor .....................................................................35

3.2.3 Quick Setting Toolbar in Live View Mode...............................................35

3.3 Adjusting Live View Settings................................................................................38

3.4 User Logout...........................................................................................................40

Chapter 4 PTZ Controls..................................................................................................41

4.1 Configuring PTZ Settings .....................................................................................42

4.2 Setting PTZ Presets, Patrols & Patterns................................................................43

4.2.1 Customizing Presets.................................................................................43

4.2.2 Calling Presets..........................................................................................44

4.2.3 Customizing Patrols .................................................................................45

4.2.4 Calling Patrols..........................................................................................46

4.2.5 Customizing Patterns................................................................................47

4.2.6 Calling Patterns........................................................................................48

4.3 PTZ Control Panel.................................................................................................49

Chapter 5 Record and Capture Settings........................................................................50

5.1 Configuring Encoding Parameters ........................................................................51

5.2 Configuring Record Schedule...............................................................................54

5.3 Configuring Motion Detection Recording ............................................................58

5.4 ConfiguringAlarm Triggered Recording..............................................................60

5.5 Configuring Manual Recording ............................................................................62

5.6 Configuring Holiday Recording............................................................................63

5.7 Configuring Redundant Recording .......................................................................65

5.8 Configuring HDD Group for Recording...............................................................67

5.9 Files Protection......................................................................................................68

Lo-Call 1890 866 900 www.cctvireland.ie

[email protected]

User Manual of Digital Video Recorder

Chapter 6 Playback..........................................................................................................70

6.1 Playing Back Record Files....................................................................................71

6.1.1 Playing Back by Channel.........................................................................71

6.1.2 Playing Back byTime..............................................................................73

6.1.3 Playing Back by Event Search .................................................................75

6.1.4 Playing Back byTag.................................................................................78

6.1.5 Playing Back by Searching System Log ..................................................81

6.1.6 Playing Back External Files.....................................................................82

6.2 Auxiliary Functions of Playback...........................................................................83

6.2.1 Playing Back Frame by Frame.................................................................83

6.2.2 Smart Search ............................................................................................83

6.2.3 Digital Zoom............................................................................................86

6.2.4 Reverse Playback of Multi-channel .........................................................86

Chapter 7 Backup.............................................................................................................88

7.1 Backing up Record Files .......................................................................................89

7.1.1 Quick Export............................................................................................89

7.1.2 Backing up by Normal Video Search.......................................................91

7.1.3 Backing up by Event Search ....................................................................94

7.1.4 Backing up Video Clips............................................................................96

7.2 Managing Backup Devices....................................................................................99

Chapter 8 Alarm Settings..............................................................................................102

8.1 Setting Motion Detection....................................................................................103

8.2 Setting Sensor Alarms.........................................................................................106

8.3 Detecting Video Loss ..........................................................................................109

8.4 Detecting Video Tampering.................................................................................111

8.5 Handling Exceptions...........................................................................................113

8.6 Setting Alarm Response Actions.........................................................................114

8.7 Triggering or ClearingAlarm Output Manually..................................................116

Chapter 9 Network Settings ..........................................................................................117

9.1 Configuring General Settings..............................................................................118

9.2 ConfiguringAdvanced Settings ..........................................................................119

9.2.1 Configuring PPPoE Settings ..................................................................119

9.2.2 Configuring DDNS Settings...................................................................119

9.2.3 Configuring NTP Server Settings...........................................................123

9.2.4 Configuring SNMP Settings...................................................................124

9.2.5 Configuring UPnP™ Settings ................................................................124

9.2.6 Configuring Remote Alarm Host Settings..............................................126

9.2.7 Configuring Multicast Settings ..............................................................127

9.2.8 Configuring RTSP Settings....................................................................127

9.2.9 Configuring Server and HTTP Ports Settings ........................................128

9.2.10 Configuring HTTPS Settings .................................................................129

9.2.11 Configuring High-speed Download Settings..........................................129

9.2.12 Configuring Email Settings....................................................................130

9.3 Checking Network Traffic...................................................................................133

Lo-Call 1890 866 900 www.cctvireland.ie

[email protected]

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HIK VISION DVR

HIK VISION

HIK VISION DS-8004HSI-S Manuel utilisateur

HIK VISION

HIK VISION DS-7608NI-ST Series Guide de l'utilisateur

HIK VISION

HIK VISION DS-9008HUHI-F8/N Manuel utilisateur

HIK VISION

HIK VISION ds-7200HVI-sh series Manuel utilisateur

HIK VISION

HIK VISION ds-7200HVI-sh series Guide de l'utilisateur

HIK VISION

HIK VISION DS-7104HWI-SL Series Manuel utilisateur

HIK VISION

HIK VISION DS-8000HTI-S Series Manuel utilisateur

HIK VISION

HIK VISION DS-7332HGHI-SH Manuel utilisateur

HIK VISION

HIK VISION DS-9000 Series Manuel utilisateur

HIK VISION

HIK VISION DS-8104AH(L) I-S Series Manuel utilisateur

HIK VISION

HIK VISION DS-7104HGHI-SH Manuel utilisateur

HIK VISION

HIK VISION DS-9000 Series Manuel utilisateur

HIK VISION

HIK VISION DS-MP5504 Series Manuel utilisateur

HIK VISION

HIK VISION DS-8000HMFI Series Manuel utilisateur

HIK VISION

HIK VISION DS-7108HGHI-E1 Manuel utilisateur

HIK VISION

HIK VISION DS-8004HCI-S Manuel utilisateur

HIK VISION

HIK VISION DS-96 NI-ST Series Manuel utilisateur

HIK VISION

HIK VISION DS-9000 Series Manuel utilisateur

HIK VISION

HIK VISION 7216HVI-S Manuel utilisateur

HIK VISION

HIK VISION DS-7300HI Series Guide de l'utilisateur

HIK VISION

HIK VISION DS-7208HUHI-K1S Manuel utilisateur

HIK VISION

HIK VISION DeepinMind iDS-6700NXI Series Manuel utilisateur

HIK VISION

HIK VISION DS-1004CDY Manuel utilisateur

HIK VISION

HIK VISION DS-72xx Series Manuel utilisateur

Manuels DVR populaires d'autres marques

FLIR

FLIR M3100E Series Manuel utilisateur

VTRACKPRO

VTRACKPRO FPRO300 Manuel utilisateur

Swann

Swann NVR-7085 models Manuel utilisateur

XtendLan

XtendLan DVR-1670C Manuel utilisateur

urmet domus

urmet domus 1093/004AHD Manuel utilisateur

Holux

Holux M1 Manuel utilisateur

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manuel utilisateur

Whistler

Whistler D16VRS Manuel utilisateur

Defender Security

Defender Security 82-20235 Manuel utilisateur

MISUMI

MISUMI MP-WF100M Manuel utilisateur

Speco

Speco D8HU Manuel utilisateur

UST

UST DDR-E04AA Instructions d'utilisation

Consolidated

Consolidated Digital Video Recorder Manuel utilisateur

Mace

Mace DVR0404RW Guide de démarrage rapide

RCA

RCA RTD315W Manuel utilisateur

FSM

FSM Colibri Grande PRO Manuel utilisateur

Hauppauge

Hauppauge HD PVR 2 Manuel utilisateur

Identivision

Identivision ICR-PH161i PIONEER Manuel utilisateur
