Hidden 208119 Manuel utilisateur

- 1 -

Item No. 208119

HIDDEN CAMERA AND BUG DETECTOR

User Guide

Thank you for purchasing the Hidden Camera and Bug Detector. Please take a few minutes to

read this guide and store it for future reference.

- 2 -

INTRODUCTION

Every day we read about new threats to our personal privacy. Wireless spy cameras, listening

devices (“bugs”) and GPS car trackers are now available to everyone. As a result, we must

constantly be vigilant about privacy intrusions in our homes, hotels, gyms and vehicles. The Hidden

Camera and Bug Detector uses military-grade technology to detect wireless signals and magnetic

ﬁelds created by covert spy devices, so you can feel safe and secure in your surroundings. As

with all advanced electronics, the more you use the Hidden Camera and Bug Detector, the more

proﬁcient you will become in detecting hidden spy devices.

NOTE: This device does not capture sound or video, and it does not prevent signals. It is an anti-

spying device that helps you ﬁnd hidden electronic equipment such as wireless spy cameras,

listening bugs and GPS trackers.

FEATURES

• Portable wireless signal and magnetic ﬁeld detection device

• Detects wireless pinhole cameras, wireless nanny cameras, wireless surveillance cameras, GPS

car trackers, 2G/3G/4G signals from SIM card bugs and other security devices

• LED laser technology detects wired and wireless cameras in standby mode

• Detects CDMA (Code Division Multiple Access) signals that conventional radio wave detectors

cannot

• Detects electromagnetic radiation in your home or workplace

• Adjustable detection range

• 10 levels of detection with buzzer or silent (vibration) alerts

• Military-grade technology

• Detects devices in areas up to 160 sq. ft. (15 sq. meters)

• Easy to use — the closer the detector gets to a transmitting spy device, the louder and faster

the alert becomes

POTENTIAL USES

• To detect secret cameras in hotel rooms, restrooms, locker rooms, changing rooms, etc.

• To detect a listening device (bug) in your home, oﬃce or corporate boardroom

• To detect a GPS vehicle tracker on your car

• To detect if your mobile phone is being eavesdropped (i.e., a signal is being emitted when your

phone is not in use)

• To detect base station radiation in or around your home

• To detect cheating devices in casinos

CONTENTS OF PACKAGE

1. Hidden Camera and Bug Detector

2. Antenna

3. Magnetic Field Probe

4. USB Cable

5. User Guide

- 3 -

DESCRIPTION OF PARTS

1. Antenna interface. Install the antenna here.

2. Magnetic Field Probe interface. Install the Magnetic Field Probe here.

3. Power supply and sensitivity knob. Turn clockwise to turn the device on and adjust the

detection sensitivity.

4. Scanning Window. This special ﬁlter lens scans for hidden wireless equipment using LED

infrared laser technology.

5. LED display. Shows code type, signal strength and power status.

6. Buzzer/Vibration mode button. Switch from audible alarm (buzzer) to silent alarm (vibration).

7. Strong Magnetic Detection mode button.

8. Camera Detection mode button.

9. Intelligent Detection mode button.

10. USB charging port

11. Charging indicator. Automatically turns oﬀ when the battery is fully charged.

INSTRUCTIONS FOR USE

1. Install the antenna.

2. Install the Magnetic Field Probe.

3. Turn the Power knob clockwise. You will hear a long beep as the device enters detection

mode. The LED main screen lights up to indicate normal operation.

- 4 -

RF WIRELESS SIGNAL DETECTION

1. Turn on the Power and adjust the knob to the ﬁrst stage of the signal strength pointer to

enter the standby mode. The code-type signal strength indicator is divided into 10 levels in 4

color-coded ﬁelds: White, Green, Yellow and Red:

White = Safe

Green = Suspicious

Yellow = Danger

Red = Locked onto signal source

2. During normal detection, ﬁrst adjust the pointer to the white part of the LED display

(between 1 and 2). If there is a strong signal environment, the pointer will ﬂuctuate back and

forth, and the buzzing alarm will be activated. The closer the detector gets to a transmitting

spy device, the louder and faster the alert becomes, until it becomes an uninterrupted alarm

(level 10).

3. The detection range can be set with the power/sensitivity knob. The higher the level of

adjustment, the wider the range. (If the buzzer alarm is not working when the red area is

adjusted, the pointer has no ﬂuctuation. That is, there is no signal in a wide range.)

NOTE: If you are using this device in a city or metropolitan environment, you must adjust the

sensitivity knob gradually to check for suspicious devices. Otherwise, you may pick up stray

signals.

MAGNETIC FIELD DETECTION

1. Install the Magnetic Field Probe.

2. Turn on the power, and then press the Strong Magnetic Detection button.

3. When the purple light is on, the device is in magnetic ﬁeld signal detection standby mode.

4. Use the magnetic ﬁeld probe to scan a vehicle or a room. If a magnetic ﬁeld (spying device)

is detected, the LEDs will light up and the buzzer will sound.

NOTE: Magnetic locators and eavesdroppers are mostly used in cars, often hidden in the bottom

of the car, or inside the car. Use the Magnetic Field Probe to search inside the car, under the car,

under the hood and in the trunk.

CAMERA DETECTION

1. Turn on the power, and then press the Camera Detection button.

2. The scanning function is turned on at this point, and the laser scanning light on the back

ﬂashes.

3. Scan in a ﬁxed range of the Scanning Window. If a suspicious reﬂective spot is found, the

buzzer will sound. Turn the sensitivity knob to widen the range if needed.

- 5 -

INTELLIGENT DETECTION MODE

1. Turn on the power

2. Press the Intelligent Detection button. The device enters the Intelligent Search mode, and the

device will automatically identify, classify and record a suspicious signal with intensity above

8 every minute.

3. As a signal source transmits the signal, the device will automatically alarm ﬁve times (the

LED pointer is at level 1, and the buzzer alarm will be uninterrupted to indicate the presence

of a suspicious signal nearby.) This function is mainly used to detect intermittent devices

that turn on and oﬀ automatically throughout the day.

IMPORTANT - SCANNING FOR GPS CAR TRACKERS

Due to the high sensitivity of this device, you may receive signals such as TV broadcasts such as

mobile phone base stations while scanning for GPS car trackers. It may be necessary to drive your

car to a place where signal sources are relatively weak. In addition, we recommend you turn oﬀ

your cellular phone while scanning for GPS car trackers.

FALSE ALARMS

If there is an alarm where there is obviously no suspicious object, there are several possibilities:

1. You are detecting your own communication equipment.

2. The suspicious objects is next door.

3. You are too close to a wireless router. (In this case, adjust the sensitivity knob.)

TECHNICAL SPECIFICATIONS

Frequency range 1MHZ-8000MHZ

Detection dynamic range >73DB

Detection sensitivity ≤0.03mv (main frequency band)

Detection range (2.4G) 107 sq. ft. (10 sq. meters, standard 10mw)

Detection range (1.2G) 160 sq. ft. (15 sq. meters, standard 10mw)

Detection range 160 sq. ft. (15 sq. meters)

(Mobile phone band 2G/3G/4G signal)

Power Built-in 1200mA polymer lithium battery

Charge time 3 hours

Continuous working time 8-10 hours

Working current 80-150mA

Material ABS plastic

Dimensions 2.4” L x 1.1” W x 5.4” H

Weight 0.4 lbs.
