HID OMNIKEY 2061 Manuel utilisateur

15370 Barranca Parkway

Irvine, CA 92618-2215

OMNIKEY®

2061 Bluetooth Reader

USER MANUAL

Firmware Version 1.30

March 23, 2010

2061-905, Rev A.1

2061-905_A.1 OMNIKEY 2061 Bluetooth Reader

User Manual, Firmware V1.27

Read Me First

About This Guide

This manual describes the OMNIKEY 2061 Bluetooth reader. This user manual describes the

reader configuration, operation and software installation.

See www.hidglobal.com/omnikey for additional information like a technical FAQ.

Cont a ct s

Europe, Middle East and Africa

HID Global Corporation, Ltd. (Haverhill, UK)

email: [email protected]

main: +44 (0) 1440 714 850

support: +44 (0) 1440 711 822

fax: +44 (0) 1440 714 840

HID GLOBAL, HID, the HID logo, OMNIKEY are the trademarks or registered trademarks of HID Global

Corporation, or its licensors, in the U.S. and other countries.

Con t ent s

Read Me First..........................................................................................................................................2

1Overview ....................................................................................................................................3

2Operation ...................................................................................................................................4

3Getting Started ..........................................................................................................................4

4Bluetooth Configuration Software ..........................................................................................6

5Conditions ...............................................................................................................................13

6Manual Installation..................................................................................................................15

Page 2 of 17 March 24, 2010

OMNIKEY 2061 Bluetooth Reader 2061-905_ A.1

User Manual, Firmware V1.27

1 Overview

The OMNIKEY®2061 Bluetooth Reader is a Bluetooth connected reader that provides a contact

interface, which reads/writes to virtually any ISO7816-3 compatible contact smart card.

1 .1 Pa r t s List

Verify the OMNIKEY 2061Bluetooth Reader contents.

1 OMNIKEY 2061 Bluetooth reader

1 USB cable

1 Software CD

2 Belt Clips

1 Safety and Product Information Manual

Contact the dealer if your OMNIKEY 2061 Bluetooth reader package is incomplete.

1 .2 Sy st em Re qu ir e m e nt s

Operating System Windows®Vista®- 32-bit (x86)

- 64-bit (x64)

Windows 7 - 32-bit (x86)

- 64-bit (x64)

Windows XP®- 32-bit

- 64-bit

Hard Disk Space 50 MB

Video Adapter SXGA (1024 x 768) or higher-resolution recommended

Bluetooth Interface Microsoft®Bluetooth Stack

Toshiba®Bluetooth Stack

March 24, 2010 Page 3 of 17

2061-905_A.1 OMNIKEY 2061 Bluetooth Reader

User Manual, Firmware V1.27

2 Operat ion

The following describes the OMNIKEY 2061 Bluetooth reader operation.

3 Ge t t ing St art ed

3 .1 Soft w a r e I n st a lla t ion

Insert the software Installation CD. Click Install Bluetooth Reader Configuration. For new

software versions, go to http://www.hidglobal.com/omnikey.

3 .2 Ba t t e ry Ch a rging

Ensure the battery is fully charged before use. For a discharged battery, it takes approximately

four hours to charge.

To charge the battery, connect the OMNIKEY 2061 Bluetooth reader to a computer through the

enclosed USB cable.

3 .3 Re a de r Se t up

Define a common name for the reader before installation. See 4.2.3 Installation Properties, page 8

for details.

1. Connect the reader to the computer using the enclosed USB cable.

2. Switch on the reader by pressing the Power button.

3. Start the Bluetooth Reader Configuration Software. See Section 4 Bluetooth

Configuration Software, page 6for additional details.

Click Start > Programs > OMNIKEY > Bluetooth Reader Configuration.

4. From the Reader menu, click Select Reader…

Page 4 of 17 March 24, 2010

OMNIKEY 2061 Bluetooth Reader 2061-905_ A.1

User Manual, Firmware V1.27

5. From the drop-down list, select the USB connected reader, click OK.

6. From the Reader menu, select Install Reader…

7. From the Installation dialog, click Start. Clicking Start pairs the reader and installs the

Bluetooth device driver.

8. If successful, the Bluetooth LED displays constant illumination.

March 24, 2010 Page 5 of 17

2061-905_A.1 OMNIKEY 2061 Bluetooth Reader

User Manual, Firmware V1.27

4 Bluet oot h Configu rat ion Soft w a re

The Bluetooth Configuration Software installs and manages your OMNIKEY 2061 Bluetooth

readers.

4 .1 Pr ofile M a nage m e n t

Using the Profile menu, setup the reader settings. Options include defining, storing and loading

different profiles.

The Profile concept maintains a mechanism for easily configuring a large number of OMNIKEY

2061 Bluetooth readers with one single Profile.

A Profile stores the configuration parameters of Parameter Sets. Manage the values of a

Parameter Set with the Installation Properties and Energy Saving Parameters dialogs.

If a Profile is not opened and no reader is selected the current Parameter Set is initiated with the

default parameters as defined in the default.ini file, stored in the installation directory.

Create a new profile by clicking Profile > New. The current Parameter Set is initiated with the

default parameters from default.ini. Save the new Profile by clicking Profile > Save or Profile >

Save As.

If opening an existing profile (click Profile > Open), the configuration parameters from the Profile

are read and stored in the current Parameter Set. Click Update Profile to modify the configuration

parameters of the opened Profile using Installation Properties and Energy Saving Parameters.

You cannot change a Profile when selecting a Profile and a Reader.

If simultaneously selecting a Profile and Reader the current Parameter Set always contains the

parameters from the Profile File. Therefore, it is possible to transfer the configuration parameters

from the current Parameter Set to the currently connected OMNIKEY 2061 Bluetooth reader.

From Installation Properties and Energy Saving Parameters, click Update Reader.

Page 6 of 17 March 24, 2010

OMNIKEY 2061 Bluetooth Reader 2061-905_ A.1

User Manual, Firmware V1.27

4 .2 Rea der Ma na gem ent

Using the Reader menu you can install, select and configure a USB connected OMNIKEY 2061

Bluetooth reader.

4 .2 .1 Re a de r Se le ct io n

With the Select Reader dialog, select USB connected OMNIKEY 2061 Bluetooth reader. The list

box lists connected readers. The dialog shows also the vendor (VID), the product id (PID) and the

firmware version (FW) of the selected reader.

The USB path of the selected reader is shown as a suffix to the reader name. In the following

example, the USB path 0:2 indicates this reader is connected on the second USB port on the first

USB hub.

Reset Selection Deselects the currently selected reader.

Reset Reader Resets the currently selected reader.

Update List Updates the list of USB connected readers.

OK Approves the selected reader and loads the reader settings.

March 24, 2010 Page 7 of 17

2061-905_A.1 OMNIKEY 2061 Bluetooth Reader

User Manual, Firmware V1.27

4 .2 .2 Re a de r I n st a lla t ion

Install the OMNIKEY 2061 Bluetooth reader with the Installation dialog.

Note: Connect the reader using the USB cable and switch on.

Clicking Start pairs the reader and installs the Bluetooth device driver. After finishing the

installation process the reader is ready to use.

4 .2 .3 I n st a lla t io n Pr op er t ie s

The Installation Properties dialog configures the installation behaviour of the reader.

The default option, Accept Bluetooth Pairing from any host indicates that the reader accepts

pairing requests from computers which are currently not paired with the reader.

If the option Accept Bluetooth pairing from paired host only is set, it is impossible to pair the

reader with new computers.

Define the reader a friendly name using the friendly name field. The friendly name displays in the

Bluetooth Devices dialog of the Bluetooth stack currently in use.

Page 8 of 17 March 24, 2010

OMNIKEY 2061 Bluetooth Reader 2061-905_ A.1

User Manual, Firmware V1.27

4 .2 .4 En e rg y Sa vin g Pa r am e t e rs

The Energy Saving Parameters dialog configures the reader settings affecting the power

consumption.

Timeouts are defined in seconds. If a timeout is set to zero, the timeout is deactivated. The

timeouts are deactivated while the reader is connected to a computer with a USB cable.

4 .2 .5 Re se t Re a de r Se t t in gs

Reset Reader Settings resets the active reader settings to default values. The default values are

stored in the file default.ini in the installation directory of the Bluetooth Configuration Software.

4 .2 .6 Set Re ader PI N

Set Reader PIN sets the OMNIKEY 2061 Bluetooth reader PIN. The PIN is required for pairing

your reader manually.

March 24, 2010 Page 9 of 17

2061-905_A.1 OMNIKEY 2061 Bluetooth Reader

User Manual, Firmware V1.27

4 .2 .7 Firm w ar e Upda t e

The Firmware Update dialog updates the reader firmware. New firmware images are available at

www.hidglobal.com/omnikey.

Select a firmware image by clicking Browse and going to the firmware file location. Select the

firmware file, click Download. The Firmware Update dialog shows the vendor ID (VID), the

product ID (PID) and the firmware build number of the selected firmware image.

4 .2 .8 Pair ed H ost s I nform a t ion

Paired Hosts Information displays information about the hosts paired with the reader. The left

column displays the index of the paired host. The right column displays the Bluetooth address of

the connected host radio.

Clear the list of paired hosts by clicking Reset.

CAUTION: When resetting the paired host information, the reader is no longer usable with

all hosts where it is installed.

4 .2 .9 Ba t t e ry St a t us

The Battery Status indicates the current battery status. 100% means the battery is fully charged.

Page 10 of 17 March 24, 2010
