HIBLOW HP Series Manuel utilisateur

HP-30/40/50

HP Series

STRUCTURE AND PART NAMES

HP-30/40/50

HP-40 1998/8 ─

HP-30

HP-50

1998/8

1998/12

─

HP-30/40/50

漓 FilterCover

滷 SemiCoverPacking

澆 Filter

潺 FittingBoss

潸 UpperHousing

澁

SoundAbsorber(HP50)

澀 CasingBlock

潯 DiaphragmRing

潛 Diaphragm

濳 DiaphragmBase

潭 Electromagnet

澂 ActuatingRod

潼 L-Tube

潘 Frame

澎

VibrationControlRubber



澑 CenterPlate

濂 Gasket

潦 LowerHousing

澳 PowerCord

Air pump Start of production

Discontinuance of production

ReplacingtheChamberBlock

REPLACING THE CHAMBER BLOCK

●Besuretounplugthepumpunit.

●Replacethediaphragmsandthevalveswithnewonesatleastonceayeartooneand

ahalfyearregularlyinordertomaintaintheirinitialperformance.

●Forchamberblockreplacement,besuretochangebothchamberblocksatthesame

time.

●The rod employs powerful permanent magnets. Therefore, be sure to remove your

watchandanyotherprecisionmachinesbeforeoperationastheymaybeaffectedby

thestrongmagneticforce.

●Do not put the actuating rod close to a magnetic card, a magnetic disk or other

magneticmediaasthedatamaybedestroyed.

STEP

REMOVAL OF THE CHAMBER BLOCKS

Toremovetheupperhousing.

Toremovethesoundabsorber.

PullouttheL-tubefromthecasingblock.

Remove the 4 screws holding the chamber block

andthecasingblock.(4screwsoneachside)



STEP

Remove1U-locknutsfromonesideholdingthe

diaphragmmountingblocktotherod.

●Usethenutdrivertoloosen(ortighten)theU-locknut.

STEP

Remove one of the diaphragm mounting blocks

from the actuating rod and pull out the other

diaphragm mounting block with the rod. After

that,separatethediaphragmmountingblockand

therod.

This completes the chamber block removal

procedure.

CAUTION！

HP-

30/40/50

ReplacingtheChamberBlock

REPLACING THE CHAMBER BLOCK

STEP

Mount the casing block with screws (4screws on

eachside).

AndinsertL-tubeintothenozzleofcasingblock.

Completetheothercasingblockatthesameway.

Fittheactuatingrodbyaligningitwiththegroove

andtightenU-locknutandflatwasherbythenut

driver.

●UsenewU-locknutandwasher,otherwise,U-locknut

mayworklooseandcausemalfunction.

STEP

Installthesoundabsorber.(HP-50)

●Beextremelycareful nottopinchtheSoundAbsorber

intheUpperHousing.

Placetheupperhousingbackonbody.

Fastenitwiththebolts.

Then,placethefilterandfiltercoverontheupper

housing. (Refer to

FILTER CLEANING AND

REPLACEMENT

)

Inserttheactuatingrodintothemachinebody.Be

sureto fit thepositioning boss onthe diaphragm

baseintotheconcavepartoftheframestay.

Secure the diaphragm mounting block on the

other side and tighten washers and U-lock nuts

withthenutdriver.

Make sure that gap between the actuating rod

andtheelectromagnetsiseven.

FITTING CHAMBER BLOCKS

HP-

30/40/50

ReplacingtheElectromagnet

REPLACING THE ELECTROMAGNET

●Besuretounplugthepumpunit.

●Whenperformingreplacementwork,thepumpbodymaybestillhotandyoumayget

burnt.Therefore,waituntilthepumphasbeenallowedtocool.

●Be sure to remove the chamber block and the actuating rod before replacing the

electromagnet.

●Itisbettertoletanexperiencedtechnicianhandlethesolderingprocess.

 Takeprecautionsagainstbeingburnt.

●IncaseofHP-10/20,dothesamewayofreplacingtheelectromagnet.

STEP

Cut the wire from the terminals on the

electromagnetwithnippers.

●Itisrecommendedthatyoumakeanoteofthewiring.

STEP

Removethenutswiththeboxdriver.

(7mmwrench.)

STEP

Pulloutelectromagnetsfromthepumpbody.

CAUTION！

REMOVING THE ELECTROMAGNET

HP-

10〜50

ReplacingtheElectromagnet

REPLACING THE ELECTROMAGNET

STEP

Solderthewirestotheterminals.

Thewirerequiresasolderedconnection.

Secure the electromagnets to the body by the

nuts.Usetheboxdriver.(7mmwrench)

STEP

This completes the electromagnet replacement

procedure.

Tiethewiresinabundlewithasilicontube.

Connectthewirestotheterminals.

FITTING THE ELECTROMAGNET

HP-

10〜50
