Hi-Tec AEE MD 10 Manuel utilisateur

Contents

Precautions...................................................6

Preface.......................................................... 7

Warranty ....................................................... 8

Overview........................................................8

Main Functions and Features..................... 8

List of Accessories ....................................11

Component Guideline ............................... 13

Description of Indicators .......................... 14

LCD Segment Display ............................... 15

Preparations Before Use........................... 16

Charging..................................................... 16

Insert and Remove the Memory Card...... 16

Startup........................................................ 17

Voice-Activated Power-On........................ 18

Language.................................................... 18

Date and Time............................................ 19

Video Mode Selection and Application.... 20

Video Mode Selection ............................... 20

Video Recording ........................................ 21

Video Recording..............................................................22

Video Only.......................................................................22

Voice Recording..............................................................22

Time Lapse .....................................................................22

Timed Recording.............................................................23

Shoot-In-Recording.........................................................23

Photo Shooting.......................................... 24

Single Shot......................................................................24

Fast Shot.........................................................................24

Continuous Shooting.......................................................24

Timed Shooting ...............................................................25

Parameter Settings.................................... 26

Recording Parameters .............................. 26

Time Lapse .....................................................................27

Timed Recording.............................................................27

Shoot-In-Recording.........................................................27

Resolution Setting...........................................................28

View Angle ......................................................................28

Video Content Loop .......................................................29

180° Image Rollover........................................................29

Display Time....................................................................29

Shooting Parameters ................................ 30

Fast Shot.........................................................................30

Continuous Shooting.......................................................31

Timed Shooting ...............................................................31

Shooting Resolution........................................................31

Display Time....................................................................31

Basic Settings............................................ 32

Warning Tone ..................................................................33

Status Indicator ...............................................................33

On-Screen Display..........................................................33

Auto Standby...................................................................33

TV Output Format ...........................................................33

Format.............................................................................33

Recover Factory Settings................................................33

Playback .................................................... 34

Upload (Audio/Video/Photo) Files to PC . 34

View Video/Photo On HDTV...................... 34

Wi-Fi ........................................................... 35

Download Wi-Fi App .......................................................35

Switch on Wi-Fi ...............................................................36

Wi-Fi Control Interface.............................. 39

Download Files to Mobile Device............. 44

Trim Videos ................................................ 46

Wi-Fi Connection Name &Password........ 47

Wi-Fi Based Remote.................................. 48

Guide for Components.............................. 48

Start-Up ...................................................... 50

Pairing ........................................................ 50

Specications ............................................ 52

Precautions................................................ 52

Accessory Application.............................. 53

Waterproof Housing & Anti-Fog Inserts.. 53

Installation of Back Clip............................ 55

Use of Convex Stickers & Flat Stickers... 56

Precautions for the use of 3M double-sided foam tape:.......56

Precautions for The Waterproof Housing .............................57

Specications ............................................ 57

Tips ............................................................. 58

FCC Notices ............................................... 59

Support....................................................... 61

6 7

Preface

Thank you for purchasing your Hitec AEE MD10 series

compact, high- definition (HD) digital video camera, which

features the following:

● Ultra-compact size and structure.

● User-friendly interfaces.

● Easy and intuitive operation.

● Hands-free shooting that allows the user to capture real

scenarios at any time and in any place.

● Superior recording performance thanks to its dynamic HD

shooting technologies that provide the user with an exciting

video shooting experience.

This manual describes how to install and use the MD10 video

camera. It also provides information about the use, operation,

installation precautions, and technical specifications of the

MD10 video camera. Before using the MD10 video camera,

read this manual carefully and keep it handy for future

reference. Designed to professional standards, the Hitec AEE

MD10 video camera will meet the requirements of even the

most discerning user.

Precautions

When using the MD10 video camera, adhere to the following

precautions:

1. Do not drop, knock, or shake the video camera.

2. Do not place the video camera near an object that generates

a strong magnetic eld, like a magnet or motor. Do not put

the video camera close to an object that emits powerful

radio waves like, for example, antenna. A strong magnetic

field may cause interference for the video camera or

damage to image / voice data.

3. Do not expose the video camera to extreme temperatures or

direct sunshine.

4. Do not put the memory card close to an object that

generates strong magnetic fields, like a television set,

speaker, or magnet. Do not put the memory card in a place

subject to static electricity.

5. Disconnect the power supply to immediately stop battery

recharge when overheating, smoking, or peculiar smells

occur during recharging.

6. Keep the video camera out of reach of children during

recharging, as the power cable may cause asphyxia or

electrical shock.

7. Store the video camera in a cool, dry, and dust-free location.

8 9

Warranty

This product has been certified for compliance with related

safety regulations and specifications issued by the Federal

Communications Commission (FCC) and Council of Europe

(CE).

Overview

As a small UHD digital video recorder with advanced Wi-

Fi function, the AEE MD10 provides such industry-leading

functions as HD digital photography, voice storage, real-time

display, video recording, photo shooting, time display, wireless

remote control (optional), Wi-Fi wireless transmission, high-

speed mini USB data transmission and mini USB charging.

Equipped with professional accessories, the MD10 allows you

to record whatever you like, anytime, anywhere. The MD10

carries several patents for invention and technology

Dispose of properly. Recycle it for a greener earth!

Main Functions and Features

● Equipped with a special-purpose HD lens, which supports.

1080P and 720P HD video recording.

● Takes 8M pixelated pictures in 3200 x 2400 resolution.

● Provides extended capacity voice recording.

● Performs 4X digital zooming.

● LCD Screen.

● Wi-Fi function and more “app” application.

● Voice-activated video recording function with long standby

time.

● A multifunctional back clip, dual-pin back clip, sport back clip,

bracket and other professional accessories are available for

your selection.

● Performs shooting in multiple modes such as single shot,

fast shot, and timed shooting.

● Provides a unique fast-shot feature, capturing up to 8 photos

per second.

● Provides better video effects in multiple video output modes

(NTSC system):

1920×1080P 30 frames / second

1280×720P 60 frames / second

WVGA 120 frames / second

● Point-and-shoot operation with red and green work indicator

● Reads battery power and free storage space.

● High-speed dynamic recording quickly responds to light and

shade.

● Provides high color denition for clearer and more realistic

video feed.

● Small size, suitable for various applications.

● Provides HDMI for easy connection to an HD monitor or TV

set to view record les.

● Records video programs in MP4 format to facilitate playback

on a PC and uploading to video-sharing websites.

10 11

● Provides 180° photo rollover function.

● Optional RTC function adds date and time to photos and

videos.

● Supports external T-ash (TF) cards for storage, up to 64 GB

capacity.

● Provides automatic standby for power saving and can be set

to auto- save audio and video data.

List of Accessories

MD10 Camera Waterproof Housing * Remote Control *

Camera Body Tray * Back Shell for Back

Clip *

Waterproof Back

Shell with Strap *

Camera Body Clip

Mount

Power Adapter * Shoulder Clip *

12 13

Flat sticker Convex sticker Quick Release

Buckle

Extended adjusting

bolt unit

Moisture-proof foam * Hand strap *

Cloth bag * Micro SD card * USB data cable

User manual CD-ROM *

The accessories you've received may be slightly different from

above. The package is subject to change without further notice.

You can order the optional accessories marked with " ".

Component Guideline

1. Recording status indicator 8. LCD screen

2. Record key 9. Micro SD card slot

3. Shutter key 10. Strap hole

4. Wi-Fi key 11. Power indicator

5. Power key 12. USB port

6. Lens 13. Mini HDMI port

7. Power/work state indicator

14 15

Description of Indicators

Indicator

Function

Power

Indicator

Recording

status

Indicator

Power/Work

State Indicator

Red Green Red and Green

Powering on Remain on / /

Video

recording Remain on Blink slowly Blink slowly in

green

Discontinuous

recording Remain on Blink slowly Blink slowly in

green

Recording

stopped Remain on / Remain on in red

Photo shooting Remain on Blink once Remain on in red

Continuous

shooting Remain on Blink

continuously Remain on in red

Shooting

stopped Remain on / Remain on in red

Voice

recording Remain on Blink slowly Blink slowly in

green

Low power Blink quickly / Blink quickly in

red

Being charged Blink slowly / Blink slowly in red

Charging

nished Remain on / Remain on in red

Charging

nished

(powered off)

Remain on / Remain on in red

You can long press the Shoot key to switch to a Power/Work

State Indicator.

LCD Segment Display

Explanations for Icons on LCD Screen:

00:00:01

2H30

1080P- 25

100-0088

1888

Icon Functions

Video modes

Photo modes

1080P-25 Video resolution

8M 5M 3M Photo resolution

100-0088 Number of recorded files

00:00:01 Recording timer

2H30 Remaining recordable time

1888 Remaining shots

5M N S View angle

6Wi-Fi

7Battery level

16 17

Preparations Before Use

Charging

Use the supplied power adapter or USB port of a PC to charge

MD10:

When the MD10 is charged in a power-off state, the red

indicator will ash slowly. After the battery is fully charged, the

red indicator will stay on.

Insert and Remove the Memory Card

MD10 supports an external TF card up to 64G. Though all

SD cards above Class 6 can be used on the MD10, a high-

speed card is recommended for high-definition shooting.

When shooting during dynamic motion, brand SDHC cards are

recommended for use to ensure smooth shooting.

• To insert the memory card, first ensure that the MD10 is

switched off. Next, insert your SD card into the memory

card slot in the direction of the arrow, keeping the card at

and pushing it to the end. A click will sound when the card

has been inserted completely.

• To remove the memory card, press the center of the

exposed part of your SD card and it will pop up slightly.

Slide the card out.

Before connecting the host to Wi-Fi or the remote control,

please rst insert the SD card.

Startup

Slide the Power key to "PWR".

• The power indicator will be lit.

• MD10 will enter the recording standby state and display the

following interface:

00:00:01

2H30

1080P- 25

100-0088

1888

Press and hold Shutter and Wi-Fi keys to power On/Off.

(Camera in power-on state.)

18 19

Voice-Activated Power-On

Slide the Power key to "VOX" and the MD10 will enter voice-

activated mode. When the ambient decibel reaches 75db, the

MD10 will begin recording. It may auto-stop recording 3min

later if the ambient decibel becomes lower than 75db. In the

recording process, you can press the Record key to stop

recording without inuencing any other function.

Language

To select the required language:

1. Long-press the Record key for 3s to enter full- screen mode.

2. Press the Shoot key or the Wi-Fi key to adjust the menu

mode to " " and then press the Record key.

3. Press the Wi-Fi key to move the cursor to " " and then

press the Record key.

4. Press the Wi-Fi key to select " " and then press the

Record key.

5. Press the Wi-Fi key to select the required language and then

press the Record key to conrm your selection.

6. Press the Shoot key to exit.

Date and Time

1. Long-press the Record key for 3s to enter the full-screen

mode.

2. Press the Shoot key or the Wi-Fi key to adjust the menu

mode to " " and then press the Record key.

3. Press the Wi-Fi key to move the cursor to " " and then

press the Record key.

4. Press the Wi-Fi key to select " " and then press the

Record key.

5. Press the Wi-Fi key to select the required date format and

then press the Record key to enter the following interface:

Y- M-D H:M

M-D-Y H:M

D-M-Y H:M

14/01/01

YY/MM/DD

16:35

HH/MM

6. Press the Shoot key or the Wi-Fi key to adjust each value

and then press the Record key to confirm the adjustment.

The MD10 will auto-exit from the above interface when all

adjustments are nished.

7. Press the Shoot key to exit.

Table des matières

Autres manuels Hi-Tec Caméra d'action

Hi-Tec

Hi-Tec S60 Manuel utilisateur

Manuels Caméra d'action populaires d'autres marques

Epic

Epic STC-EPC1T Manuel utilisateur

Brinno

Brinno MAC200 DN Manuel utilisateur

GoPro

GoPro HERO5 Manuel utilisateur

ION

ION Air Pro 2 Manuel utilisateur

Firefly

Firefly 6s Manuel utilisateur

Omni

Omni HERO4 Manuel utilisateur

nedis

nedis ACAM41BK Manuel utilisateur

MOFILY

MOFILY YOCAM Manuel utilisateur

ZERO-X

ZERO-X ZX-10 Manuel utilisateur

Pyle

Pyle eXpo PSCHD90 Manuel utilisateur

Action Camera

Action Camera AC32 Manuel utilisateur

Midland

Midland XTC300 Manuel utilisateur

Movii

Movii QC-8075 Manuel utilisateur

Coleman

Coleman C5WP Xtreme Manuel utilisateur

MCM Electronics

MCM Electronics 82-19749 Manuel utilisateur

Aim

Aim SmartyCam 3 Sport Manuel utilisateur

Naxa

Naxa NDC-409 Manuel utilisateur

Panasonic

Panasonic HX-A1M Manuel utilisateur
