HEIDENHAIN ITNC 530 - CONVERSATIONAL PROGRAMMING Manuel utilisateur

Operating Instructions for

Programming Station

iTNC 530

NC Software

340 494-05

English (en)

12/2008

HEIDENHAIN iTNC 530 Programming Station 3

TNC Model, Software and Features

This manual describes functions and features provided by the TNC

programming station as of the following NC software numbers.

The programming station software is fully compatible with the TNCs

listed below.

Many machine manufacturers, as well as HEIDENHAIN, offer

programming courses for the TNCs. We recommend these courses as

an effective way of improving your programming skill and sharing

information and ideas with other TNC users.

TNC model NC software number

iTNC 530 programming station 340 494-05

TNC model NC software number

iTNC 530 340 490-05

iTNC 530 (export version) 340 491-05

iTNC 530 with Windows XP 340 492-05

iTNC 530 with Windows XP (export

version) 340 493-05

User documentation:

All TNC functions are described in the User’s Manuals for

the iTNC 530. Please contact HEIDENHAIN if you need a

copy of these User’s Manuals. Have your NC software

number handy. It is shown on the iTNC’s MOD screen.

The user documentation is also available as online help,

which can be called with the HELP key of your

Programming Station.

If you have purchased the complete version of the

programming station, you will find all the user

documentation on the TNCguide DVD included in delivery.

HEIDENHAIN iTNC 530 Programming Station 5

Table of Contents Important Information on the Software

for the Programming Station 1

Items Supplied / Installation 2

Table of Contents

HEIDENHAIN iTNC 530 Programming Station 7

1.1 Introduction ..... 10

General information ..... 10

Options/Feature content level (FCL) ..... 10

Compatibility ..... 11

Downward compatibility ..... 11

1.2 Working with the iTNC 530 Programming Station ..... 28

Starting the programming station ..... 28

Defining the window mode ..... 28

Showing the virtual keyboard ..... 29

Exiting the programming station ..... 30

1.3 Data Transfer from the Programming Station to the Machine Tool ..... 31

Prerequisites ..... 31

Preparations at the programming station ..... 31

Calling a program from the machine tool ..... 32

Connection between the programming station and HEIDENHAIN PC software ..... 32

1.4 The Demo Version ..... 33

General information ..... 33

Starting the demo version ..... 33

Keyboard assignment ..... 34

Overview of keyboard assignment ..... 38

Key assignment on portable computers ..... 39

1 Important Information on the Software for the Programming Station ..... 9

Table of Contents

8Table of Contents

2.1 Items Supplied / System Requirements ..... 42

Items supplied ..... 42

System requirements ..... 42

2.2 Connecting the Programming Station ..... 43

Connect the keyboard for the programming station ..... 43

Mounting the cable terminals for USB cable ..... 43

Number stickers ..... 44

Connecting the USB dongle (only for the version with a virtual keyboard) ..... 44

Installing the programming station software ..... 45

Configuring the programming station software for use with an USB network dongle ..... 46

Setting the conversational language ..... 48

Working with the HEIDENHAIN basic PLC program ..... 50

2 Items Supplied / Installation ..... 41

Important Information

on the Software for the

Programming Station

1.1 Introduction

General information

TNC controls from HEIDENHAIN have always been user friendly:

Thanks to their simple programming in HEIDENHAIN conversational

language, field-proven cycles, unambiguous function keys, and clear

and vivid graphic functions, they now count among the most popular

shop-floor programmable controls.

Now there is also software for running a programming station using

Windows. The HEIDENHAIN keyboard included in delivery is simply

connected to the USB interface on your PC. For test purposes you can

also use the iTNC 530 programming station with your standard PC

keyboard (see “The Demo Version” on page 33).

As an alternative, you can also use the virtual keyboard for the

programming station (see “Showing the virtual keyboard” on page

29).

Options/Feature content level (FCL)

Some powerful functions are not available as a standard feature on all

TNC controls, but must be enabled via a keyword.

All functions are available without surcharge on the iTNC 530

programming station. The free demo version, however, only permits

storage of programs up to a certain program length (see “The Demo

Version” on page 33).

This manual describes the special features of the iTNC530

programming station. All available NC functions are

described in the User’s Manual for Cycle Programming.

smarT.NC functions are described in the smarT.NC pilot.

When creating programs with the iTNC 530 programming

station, please ensure that you only use functions actually

available on your machine. Otherwise, the program could

contain ERROR blocks after it has been downloaded to the

machine control, or error messages could appear during

testing or program run.
