Heat Controller BGE H-Series Guide d'application

Heat Controller, Inc. • 1900 Wellworth Ave. • Jackson, MI 49203 • (517)787-2100 • www.heatcontroller.com

REPLACEMENT

PARTS LIST

Room Air Conditioner:

BGE H-Series

BGE H-Series Parts List Thru-the-Wall Room Air Conditioner Heat Controller, Inc.

EXPLODED VIEW

Heat Controller, Inc. Thru-the-Wall Room Air Conditioner BGE H-Series Parts List

BGE-103H REPLACEMENT PARTS

Location Part Description Part No.

130410 Single Base Assembly 3041A10038B

352380 Air Guide Assembly 5239A10002G

349600 Motor Bracket 4960A20005A

346811 AC Motor 4681A20041C

559011 Axial Fan Assembly 5900AR1173A

349480 Orice 4948A10006A

753000 Electric Heater 5300A20003A

W48602 Spring Clamp 3H02932B

149980 Shroud 4998A10007B

435301 Rear Grille MDX33964101

359012 Turbo Fan 5900A20009B

554160 Compressor Set TBZ34841401

567502 Overload Protect EAF34140210

354210 First Evaporator Assembly ADL73081801

552113 Condenser (Out) Tube Assembly 5211A20560P

550140 Compressor Damper 4H00982C

35211A Suction Tube Assembly 5211A21428D

352115 Evaporator (In) Tube Assembly AJR33322503

352113 Discharge Tube Assembly 5211A21421R

249950 Control Case Assembly 4994A10096A

237200 Control Panel 3720A10305A

268711-2 Main PCB Assembly EBR39264504

W0CZZ Capacitor 6120AR2194F

264110 Power Cord Assembly 6411A20056Q

567480 NTC Thermistor 6323A20003F

268711-1 Display PCB Assembly EBR30852201

130900 Cabinet 3090A20003F

135312 Front Grille Assembly 3531A20055K

135303 Inlet Grille 3530A20020B

152302 Air Filter 5230A20007A

147581 Horizontal Louver 4758A20008B

147582-1 Vertical Louver 4758A20009A

147582-2 Vertical Louver 4758A20009B

435300 Rear Grille 4520A20003A

267110 Remote Controller Assembly 6711A20093A

731273 Single Install Part Assembly 3127A20017B

132100 Frame 4918A20001A

238310 Escutcheon MDD37791801

BGE H-Series Parts List Thru-the-Wall Room Air Conditioner Heat Controller, Inc.

BGE-123H REPLACEMENT PARTS

Location Part Description Part No.

130410 Single Base Assembly 3041A10038B

352380 Air Guide Assembly 5239A10002G

349600 Motor Bracket 4960A20005A

346811 AC Motor 4681A20041C

559011 Axial Fan Assembly 5900AR1173A

349480 Orice 4948A10006A

753000 Electric Heater 5300A20003A

W48602 Spring Clamp 3H02932B

149980 Shroud 4998A10007B

435301 Rear Grille MDX33964101

359012 Turbo Fan 5900A20009B

554160 Compressor Set,China TBZ34841401

567502 Overload Protect EAF34140210

354210 First Evaporator Assembly ADL73081801

552113 Condenser (Out) Tube Assembly 5211A20560P

550140 Compressor Damper 4H00982C

35211A Suction Tube Assembly 5211A21428D

352115 Evaporator (In) Tube Assembly AJR33322503

352113 Discharge Tube Assembly 5211A21421R

249950 Control Case Assembly 4994A10096A

237200 Control Panel 3720A10305A

268711-2 Main PCB Assembly EBR39264504

W0CZZ Capacitor,Film,Box 6120AR2194F

264110 Power Cord Assembly 6411A20056Q

567480 NTC Thermistor 6323A20003F

268711-1 Display PCB Assembly EBR30852201

130900 Cabinet 3090A20003F

135312 Front Grille Assembly 3531A20055K

135303 Inlet Grille 3530A20020B

152302 Air Filter 5230A20007A

147581 Horizontal Louver 4758A20008B

147582-1 Vertical Louver 4758A20009A

147582-2 Vertical Louver 4758A20009B

435300 Rear Grille 4520A20003A

267110 Remote Controller Assembly 6711A20093A

731273 Single Install Part Assembly 3127A20017B

132100 Frame 4918A20001A

238310 Escutcheon MDD37791801

04/2009

05/2011
