HBM PMX Instructions d'installation

English Deutsch Français

Documentation and safety

instructions

PMX

Measurement electronics

Safety instructions

A3260-2.0_en/de/fr

PMX

2 A3260-2.0_en/de/fr

Documentation and safety instructions

Documentation

The complete documentation for the PMX amplifier sys

tem is available in electronic format on the supplied CD-

ROM. The documentation is subject to modifications.

The latest edition of the relevant documentation is avail

able as a download at http://www.hbm.com.

Appropriate use

The amplifier system with connected sensors and trans

ducers is to be used exclusively for measurement tasks

and directly related control tasks. Use for any purpose

other than the above is deemed to be inappropriate.

In the interests of safety, the module should only be op

erated as described in the operating manual. It is also

essential to comply with the legal and safety require

ments for the application concerned during use. The

same applies to the use of accessories.

Each time you start up the module, you must first run a

project planning and risk analysis that takes into account

all the safety aspects of automation technology. This par

ticularly concerns personal and machine protection.

Additional safety precautions must be taken in plants

where malfunctions could cause major damage, loss of

data or even personal injury. In the event of a fault, these

precautions establish safe operating conditions.

This can be done, for example, by mechanical interlock

ing, error signaling, limit value switches, etc.

PMX

A3260-2.0_en/de/fr 3

General dangers of failing to follow the safety

instructions

The PMX system is a state of the art unit and as such is

reliable. The module may give rise to residual dangers if

it is inappropriately installed and operated by untrained

personnel.

Any person instructed to carry out installation, starting

up, maintenance or repair of the module must have read

and understood the operating manual and in particular

the technical safety instructions.

Conditions at the place of installation

SProtect the device from direct contact with water.

SProtect the PMX system from moisture and humidity

or weather conditions such as rain and snow, etc. The

PMX device complies with protection class 2 per

DIN EN 60 529.

SDo not expose the device to direct sunlight.

SPlease observe the permissible maximum ambient

temperatures stated in the specifications.

SThe permissible relative humidity at 31°C is 90% (non

condensing); linear reduction to 50% at 40°C.

SInstall the device so that it can be disconnected from

the voltage supply at any time without difficulty.

SIt is safe to operate the PMX system up to a height of

2000 m.

SIt is safe to operate the PMX system up to a height of

2000 m.

Maintenance and cleaning

The PMX system is maintenance-free.

PMX

4 A3260-2.0_en/de/fr

SBefore cleaning, disconnect all connections.

SClean the housing with a soft, slightly damp (not wet!)

cloth. You should never use solvents, since these

could damage the labeling.

SWhen cleaning, ensure that no liquid gets into the

device or connections.

Residual dangers

The scope of supply and performance of the PMX covers

only a small area of measurement technology. In addi

tion, equipment planners, installers and operators should

plan, implement and respond to the safety engineering

considerations of measurement technology in such a way

as to minimize residual dangers. On-site regulations

must be complied with at all times. There must be refer

ence to the residual dangers connected with measure

ment technology.

Working safely

A device must not be directly connected to the DC

voltage supply system. The supply voltage range is

10 V to 30 V (DC).

Before starting up, make sure that you are using a suit

able supply voltage and that the circuit is adequately pro

tected. Only a separated extra-low voltage (SELV) must

be used to supply the device (safety isolating transformer

per DIN VDE 0551 and EN 60742). Do not operate built-

in devices until they are installed in the housing provided.

The device design is based on DIN EN 61010 Part 1

(VDE 0411 Part 1).

If the device is mounted on a support rail, this must be

connected to grounded conductor potential.

PMX

A3260-2.0_en/de/fr 5

Both the support rail and the device must be free of

paint, varnish and dirt at the point of installation.

The supply connection, as well as the signal and sense

leads, must be installed in such a way that electromag

netic interference does not adversely affect device func

tionality (HBM recommendation: "Greenline shielding

design", downloadable from the Internet at

http://www.hbm.com/Greenline).

Automation equipment and devices must be installed in

such a way that adequate protection or locking against

unintentional actuation is provided (e.g. access checks,

password protection, etc.).

When devices are working in a network, these networks

must be designed in such a way that malfunctions in indi

vidual nodes can be detected and shut down.

Safety precautions must be taken both in terms of hard

ware and software, so that a line break or other interrup

tions to signal transmission, such as via the bus inter

faces, do not cause undefined states or loss of data in

the automation device.

Conversions and modifications

The device must not be modified from the design or

safety engineering point of view except with our express

agreement. Any modification shall exclude all liability on

our part for any damage resulting therefrom.

In particular, any repair or soldering work on plug-in

cards is prohibited. When exchanging complete modules,

use only original parts from HBM.

The product is delivered from the factory with a fixed

hardware and software configuration. Changes can only

be made within the possibilities documented in the manu

als.

PMX

6 A3260-2.0_en/de/fr

Qualified personnel

Qualified personnel means persons entrusted with siting,

mounting, starting up and operating the product, who

possess the appropriate qualifications for their function (a

qualified electrician or someone with electrical training).

This device is only to be installed and used by qualified

personnel strictly in accordance with the specifications

and with the safety requirements and regulations which

follow.

This includes people who meet at least one of the three

following requirements:

SKnowledge of the safety concepts of automation tech

nology is a requirement and as project personnel, you

must be familiar with these concepts.

SAs automation plant operating personnel, you have

been instructed how to handle the machinery and are

familiar with the operation of the modules and techno

logies described in this documentation.

SAs commissioning engineers or service engineers,

you have successfully completed the training to qual

ify you to repair the automation systems. You are also

authorized to activate, ground and label circuits and

modules in accordance with safety engineering stand

ards.

The PMX system must only be installed by qualified per

sonnel, strictly in accordance with the specifications and

with safety requirements and regulations.

Maintenance and repair work on an open device with the

power on may only be carried out by trained personnel

who are aware of the dangers involved.

PMX

A3260-2.0_en/de/fr 7

Important

If using an external power supply, please observe the

relevant safety instructions.

Deutsch Français

Dokumentation und

Sicherheitshinweise

PMX

Messelektronik

Sicherheitshinweise

A3260-2.0_en/de/fr

PMX

2 A3260-2.0_en/de/fr

Dokumentation und Sicherheitshinweise

Dokumentation

Die gesamte Dokumentation zum Messverstärkersystem

PMX befindet sich in elektronischer Form auf der mitge

lieferten CD-ROM. Änderungen in der Dokumentation

sind vorbehalten. Die jeweils aktuellsten Dokumentatio

nen stehen zum Download unter http://www.hbm.com

bereit.

Bestimmungsgemäße Verwendung

Das Messverstärkersystem mit den angeschlossenen

Sensoren bzw. Aufnehmern ist ausschließlich für Mes

saufgaben und direkt damit verbundene Steuerungsauf

gaben zu verwenden. Jeder darüber hinausgehende Ge

brauch gilt als nicht bestimmungsgemäß.

Zur Gewährleistung eines sicheren Betriebes darf das

Modul nur nach den Angaben in der Bedienungsanleitung

betrieben werden. Bei der Verwendung sind zusätzlich

die für den jeweiligen Anwendungsfall erforderlichen

Rechts‐und Sicherheitsvorschriften zu beachten. Sinnge

mäß gilt dies auch bei Verwendung von Zubehör.

Vor jeder Inbetriebnahme der Module ist eine Projektie

rung und Risikoanalyse vorzunehmen die alle Sicher

heitsaspekte der Automatisierungstechnik berücksichtigt.

Im Besonderen betrifft dies den Personen- und Anlagen

schutz.

Bei Anlagen, die aufgrund einer Fehlfunktion größere

Schäden, Datenverlust oder sogar Personenschäden

verursachen können, müssen zusätzliche Sicherheitsvor

kehrungen getroffen werden. Im Fehlerfall stellen diese

Vorkehrungen einen sicheren Betriebszustand her.

PMX

A3260-2.0_en/de/fr 3

Dies kann z.B. durch mechanische Verriegelungen, Feh

lersignalisierung, Grenzwertschalter usw. erfolgen.

Allgemeine Gefahren bei Nichtbeachten der

Sicherheitshinweise

Das PMX‐System entspricht dem Stand der Technik und

ist betriebssicher. Von dem Modul können Restgefahren

ausgehen, wenn es von ungeschultem Personal unsach

gemäß eingesetzt und bedient wird.

Jede Person, die mit Aufstellung, Inbetriebnahme, War

tung oder Reparatur des Modules beauftragt ist, muss

die Bedienungsanleitung und insbesondere die sicher

heitstechnischen Hinweise gelesen und verstanden ha

ben.

Bedingungen am Aufstellungsort

SSchützen Sie das Gerät vor direktem Kontakt mit

Wasser.

SSchützen Sie das PMX‐System vor Feuchtigkeit oder

Witterungseinflüssen wie beispielsweise Regen,

Schnee usw. Das PMX‐Gerät entspricht der Schutz

klasse 2 nach DIN EN 60 529.

SSchützen Sie das Gerät vor direkter Sonneneinstrah

lung.

SBeachten Sie die in den technischen Daten angege

benen maximal zulässigen Umgebungstemperaturen.

SDie zulässige relative Luftfeuchte bei 31 °C beträgt

90 % (nicht kondensierend); lineare Reduzierung bis

50 % bei 40 °C.

SStellen Sie das Gerät so auf, dass eine Trennung von

der Spannungsversorgung jederzeit problemlos mög

lich ist.

Autres manuels pour PMX

Table des matières

Langues :

Autres manuels HBM Amplificateur

Manuels Amplificateur populaires d'autres marques

ASTRO

ASTRO HVO V40 P Manuel utilisateur

Marantz

Marantz SUPERSCOPE BLA-545 Instructions de montage

NAD

NAD CI980 Manuel utilisateur

Technics

Technics SE-CH770 Manuel utilisateur

Harman Kardon

Harman Kardon HK6300 Manuel utilisateur

NAD

NAD T975 Manuel utilisateur

McIntosh

McIntosh MA6850 Manuel utilisateur

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manuel utilisateur

Viatron

Viatron Autrix Manuel utilisateur

GME

GME GA9800 Manuel utilisateur

Atlas

Atlas CP700 Manuel utilisateur

Roland

Roland KC-1000 Manuel utilisateur

Pyle

Pyle PFMRA350BW Manuel utilisateur

Advantage

Advantage S-250 Manuel utilisateur

IRT Electronics

IRT Electronics DVA-3007 Manuel utilisateur

Dimavery

Dimavery BA-100 Series Manuel utilisateur

Sony

Sony XM-S400D Manuel utilisateur

Schertler

Schertler ROY X Manuel utilisateur
