17：Electronic amplification and reduction
Press the “freeze” button the image will electronic amplification, the multiple will be showed
on the left of the image, the maximum multiple up to 5 times and image will be vague when
magnification.
After electronic amplification, press on the “capture” button the image will reduction, the
multiple will be shown on the left of the image and it can reduce to the original size
18：Switch photo and video mode
The system default is photo mode, press the “OK” button to take photo.
Press the “MODEL” button to switch video mode, press the “OK” button to start capture and
press “OK” button again to stop recording.
HDMI output
First, make sure the connected monitor is UHD 4K monitor, otherwise the resolution can
not reach 4K 3480x2160P.
Second, power on the microscope and connect it to the hd monitor, make sure there is
power on when using since there is no built-in battery.
Third, turn on the microscope, put the observation on the platform and adjust the working
distance to get a clear image.
Under the HDMI output, the microscope can take picture, but can not record video.
FAQ
1: Why these is no image on the monitor?
Check if all the lines connected properly and power switch is turn on.
2: Why the image vague?
Please adjust the focal distance, lighting angle, check if there is dirt on the lens.
3: Why the remote control can not work?
There is no battery in the package, check if you has installed it.
4: Why there is no image on monitor when playback?
Maybe the video is not kept intact, or the video file is too large, and the system needs run
time.
