INSTALLATION MANUAL

harmoni 100+ thermostat

YEAR

WARRANTY

PRE-INSTALLED

PROGRAMS

Wi-Fi built-in

INTRODUCTION

Important notes, please read carefully before proceeding with installation

The Harmoni brand

Thank you for choosing the Harmoni 100+Wi-Fi Thermostat

from our range of electric underﬂoor heating solutions.

The Harmoni range of products has been manufactured to

surpass all current industry standards. The Harmoni 100+

Thermostat comes with a two-year

warranty.

Harmoni 100+Thermostat

The Harmoni 100+is a Wi-Fi enabled digital thermostat

designed to improve the thermal comfort of your home by

providing programming of your underﬂoor heating system. It

receives temperature signals through the following sensors:

1. Air sensor located inside the thermostat.

2. Sensor installed on the ﬂoor (check underﬂoor

heating instructions for more details).

This thermostat is not a safety device and should only

be used for its purpose. To avoid damaging the ﬂoor, you

must select the correct ﬂoor type during the thermostat

programming process.

Location of Thermostat

• This thermostat must be installed inside an electric wall

box that has a depth of at least 35mm

• For optimum performance, this thermostat should be

located in an area with good ventilation

• It should not be positioned next to a window or door, in

direct sunlight or near a heat source (e.g. a radiator or TV)

• This thermostat is designed to operate between 0°C and

55°C, with a relative humidity below 80%

1. Separate the front cover of the thermostat from the wall

module

2. Place the front cover in a safe place to avoid damage

3. Pass all the cables to the wall box. Make sure you have

included the following:

a. Feed (phase and neutral)

b. Heating element (phase and neutral or only phase of

the switch)

c. Floor sensor or air sensor

4. Pass the wires through the wall box and complete the

wiring

Important Notes

Make sure the cables are fully inserted into the

terminals and tightened securely. All loose wires

should be cut as they could cause a short circuit If

more heating elements are connected, an electrical

bypass box will be required.

Always make sure that the sensor cable is installed

in a conduit separate from the power supply of the

thermostat and the heating system.

Assembly

1. Release the front cover

2. Remove the back plate

3. Screw the back plate to the wall box with a screwdriver

4. After connecting the cables (see connection diagram),

mount the thermostat to the back plate and replace the

housing and frame

Important Safety Notes

• This product uses mains voltage and its installation

must be carried out by a qualiﬁed electrician.

• You should always disconnect the power

supply before attempting to install or repair the

thermostat.

• It should not be switched on unless you are sure

that the entire heating installation complies with

the current general requirements for electrical

installations.

• The electrical installation must comply with the

latest wiring regulations.

INSTALLATION

DISPLAY SYMBOLS

ELECTRICAL DETAILS

Installation must be carried out by a qualiﬁed electrician

Electrical Speciﬁcations

• Supply voltage: 230V +/- 10% at 50Hz

• This thermostat is not designed to be used with an

intermittent power supply.

• Maximum load: 16A resistance or 3,680W

• Insulation class: II

• IP21

• Floor sensor: 10 KOhm

Connection Diagram

NETWORK SYNCHRONISATION /

BACK

DECREASE TEMPERATURE /

MOVE DOWN

ON –OFF /

INCREASE TEMPERATURE /

MOVE UP

FLOOR SENSOR AIR SENSOR

AUTOMATIC

MODE

SET TEMPERATURE /

ENVIRONMENT

CONFIGURATION & PROGRAMMING

The initial conﬁguration starts when the thermostat is switched on for the ﬁrst time

After completing the initial conﬁguration, the

thermostat will display the set-point temperature

and the temperature read by the sensor.

LEAVE FOR

5 SECONDS

WITHOUT

PRESSING

ANYTHING

1. Time and Date

SET DAY OF WEEKSET MINUTESSET HOUR

2. Select Sensor

SENSOR TEMPERATURE

Value blinks

SET TEMPERATURE

Value remains static

PRESS OR

TO CHANGE THE SENSOR

PRESS TO CONFIRM

PRESS OR

TO CHANGE HOUR/DAY

PRESS TO CONFIRM

FLOOR SENSORAIR SENSOR

FACTORY

RESET

Perform a

factory reset

CONFIGURATION MENU

Press for 3 seconds to access the menu

PROGRAMMING

TIME & DATE

BACKLIGHT

ADAPTABLE

START UP

TEMPERATURE

OFFSET

OPEN WINDOWS

LIMIT

TEMPERATURE

DEFAULT

SENSOR

DISABLE

FLOOR SENSOR

Set a programme or

create your own

Set time & day

Turn open windows

function On/Off

Turn adaptable

start up On/Off

Perform a temperature

offset on the sensors

Set maximum

temperature for the

sensors

Modify backlight

intensity of sleep mode

Select the default

sensor

Disable the

ﬂoor sensor

PROGRAMMING

To programme the thermostat, access the Pr1 sub-menu

PROGRAMMING

• To programme the thermostat access the

“programming” (Pr1) sub-menu and select ON.

• Next, you will see the 3 pre-programs

(P1 - P2 - P3) and one editable by the user (Pu).

• To carry out your own programming, choose Pu

and conﬁrm with . Then:

1. SUBMENU SET SET

Set the setpoint

temperatures of the

ECO, COMFORT &

FROST modes

Set setpoints

• COMFORT

• ECO

• FROST-OFF

CON

Set COMFORT

temperature: 19–30 °C

Set temperature

ECO Set temperature

ECO: 7.5–18.5 °C

FRO

OFF

Set mode

FROST (7 °C): OFF

1. SUBMENU SET PEr Perform the time

schedule

Select time

parameters

1d All days equal

5–2d Week / Weekend

7d Each day different

Pre-set programme 3

Start End Temperature

Period 1 8:00 21:00 21°C

Period 2 21:00 8:00 15°C

Pre-set programme 1

Start End Temperature

Period 1 6:00 8:00 21°C

Period 2 8:00 19:00 15°C

Period 3 19:00 23:00 21°C

Period 4 23:00 6:00 15°C

Pre-set programme 2

Start End Temperature

Period 1 7:00 11:00 21°C

Period 2 11:00 18:00 15°C

Period 3 18:00 23:00 21°C

Period 4 23:00 7:00 15°C

PROGRAMMING

To programme the thermostat, access the Pr1 sub-menu

After selecting a

time parameter

(1d / 5-2d / 7d),

set the desired

setpoint for each

hour. The large digits indicate the time; the small value indicates the mode.

Press or to go forwards or backwards in time.

Pressing cycles through the modes.

When the timer

passes 00 it moves

to the next day.

The screen displays

the following day or

week / weekend.

PRE-SET PROGRAMMES

Press to go backwards.

Hour: 12:00

C: COMFORT

Hour: 00:00

E: ECO C: Comfort

E: Eco

F: Frost

-: Off

Days Week Weekend

...

WI-FI FUNCTIONALITY

The Harmoni 100+requires the Harmoni App to use Wi-Fi functionality

Harmoni® guarantees this product will be free from defects

in workmanship or materials, under normal use and service,

for a period of two (2) years from the date of purchase by

the consumer. If during the guarantee period the product is

determined to be defective, Harmoni will assume

responsibility for repair or replacement. If the product is

defective, please:

a. Return it, with a sales invoice or other dated proof of

purchase, to the place from which it was purchased

b. Contact Harmoni directly, who will determine if the

product should be returned or replaced

This guarantee does not cover the costs of removal or

re-installation, and will not apply if Harmoni demonstrates

that the defect or malfunction was caused by damage

occurred whilst in the possession of the end user, by not

following the installation or instructions in this manual or

during installation. The sole responsibility of Harmoni will be to

repair or replace the product within the terms set forth above.

Harmoni® will not be responsible for any loss or damage of

any kind, including consequences that result, directly or

indirectly, from any breach of any warranty, express or

implied, or any other fault of this product. This guarantee is

the only one expressed by Harmoni on this product. The

duration of any implied guarantee, including guarantees of

merchantability and ﬁtness for a particular purpose, is

hereby limited to the two years duration of this guarantee as

stated above.

This Guarantee does not affect your statutory rights.

YEAR

WARRANTY

GUARANTEE

The Harmoni 100 Thermostat has a two-year guarantee

The Harmoni App works on both iOS & Android.

It’s free to download from Apple or

Google Play stores: search ‘Harmoni Heating’

The Harmoni App allows the user to control the Harmoni 100+Thermostat from any smart device. Adjust temperatures and

easily program all the advanced functions wherever you are. Also view statistics, check and manage consumption.
