ASSEMBLY & OPERATING INSTRUCTIONS

HARLEY 30” (POLICE)

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit our Web Site at www.harborfreight.com

TOY ROCKER

90033

90033 Police Harley .p65 10/30/03, 1:16 PM1

THANK YOU for choosing a HARBOR FREIGHT TOOLS product. For future reference, please complete the

owner’s record below:

Model______________ Serial No._____________ Purchase Date_______________

SAVE THE RECEIPT, WARRANTY AND THESE INSTRUCTIONS. It is important that you read the entire

manual to become familiar with the unit BEFORE you begin assembly.

Technical Specifications

Construction: Pine Wood

For ages: 3-8

Maximum Weight: 100 LBS.

Batteries: (3 qty.) 1.5V LR44 Button Cell

Safety Warnings and Precautions

WARNING: When using product, basic safety precautions should always be followed to

reduce the risk of personal injury and damage to equipment.

Read all instructions before using this product!

1. Keep work area clean. Cluttered areas invite injuries.

2. Observe work area conditions. Do not use this product in damp or wet locations. Don’t

expose to rain. Keep work area well lighted.

3. Store idle equipment. When not in use, products must be stored in a dry location to inhibit

rust.

4. Check for damaged parts. Before using any product, any part that appears damaged should

be carefully checked to determine that it will operate properly and perform its intended function.

Check for any broken or damaged parts and any other conditions that may affect its operation.

Replace or repair damaged or worn parts immediately.

5. Replacement parts and accessories. When servicing, use only identical replacement parts.

Use of any other parts will void the warranty.

6. Use eye protection. Always wear ANSI approved impact safety goggles when assembling this

product.

7.Always check hardware and assembled parts after assembling. Use in an area that is

flat and level. All connections should be tight and hardware tightened.

8. All assembly should be done by an adult.

9. The Toy Rocker should be played with in the presence of an adult. The Toy Rocker is for

indoor use. Use on a padded surface, like a carpet.

10.This product contains small parts and therefore represents a choking hazard.

Warning: The warnings, cautions, and instructions discussed in this instruction manual cannot

cover all possible conditions and situations that may occur. It must be understood by

the operator that common sense and caution are factors which cannot be built into

this product, but must be supplied by the operator.

#90033 Page 2

90033 Police Harley .p65 10/30/03, 1:16 PM2

Assembly

Your Toy Rocker will require complete assembly prior to use. It is important that you read the entire

manual to become familiar with the product BEFORE you use the Toy Rocker. Before assembling

the Toy Rocker be sure that you have all parts described in the Parts List and Assemby Diagram

located on the last pages of this manual.

Step 1) At each end of the Rocker Support (#2), insert the protruding dowel of the

Connecting Plate (#3) through the center hole in the Rocker Support (#2) and into

the Body (#1). The hole in Connecting Plate (#3) must line up with the holes in

Body (#1)-see Figure 1.

Figure 1-Body to Rocker Support

#90033 Page 3

Connecting Plate (#3)

Step 2) Secure the protruding dowel (on the Connecting Plate (#3) to the Body (#1)

by inserting two-sided Bolt (C) through Body (#1), extension of Connecting Plate (#3)

and out other side of Body (#1). On each end of Two-Sided Bolt (C), slide on Big

Washer (J), Spring Washer (L), and tighten on Nut (G)-see Figure 1.

Big Washer (J),

Spring Washer (L),

and Nut (G).

Big Washer (J),

Spring Washer (L),

and Nut (G).

(protruding dowel)

Step 3) Securing the Connecting Plate (#3) to the Rocker Support (#2). Insert the two (2)

Hex Bolts (B) down through the front Rocker Support (#2) and through each of the

outside holes in the Connecting Plate (#3)-see Figure 2. Slide on Small Spring

Washer (M), Medium Washer (K) and tighten on Nut (F).

Step 4) Connecting the Side Bags. The Side Bags have 4 side pieces (#6) and two front

pieces (#7). Connect the pieces as shown in Figure 2. Once in place, insert one

Hex Bolt (D) through each corner (4 corners on each side)-see Figure 2.

Hex Bolt (B)

Small Spring Washer (M),

Medium Washer (K)

and Nut (F).

Figure 2-Attaching Side Bags

Side View

Rocker Support (#2)

Side Bag

Hex Bolt (D)

Bolt (C)

Seat (#8)

90033 Police Harley .p65 10/30/03, 1:16 PM3

Step 5) Attach the rear Siren with Nut (H)-see Figure 3.

Figure 3

Step 6) To attach the Seat Bottom (#8), insert 2 Hex

Bolts (A) down through Seat Bottom (#8) - See

Figure 2.

Step 7) Insert Handlebar (#9) through top hole in forks.

Slide one Washer (I) onto each Screw (E) and

thread into hole in front of fork and into Handlebar

to secure in place-see Figure 4.

Siren

Handlebar (#9)

Screws (E) with

Washers (I)

Step 8) If decals are not attached, apply decals as shown on manual cover. Peel off decal

from paper and attach to Toy Rocker.

Siren Sound-Replacing Batteries

The Toy Rocker has a button on the console which makes a motor sound. The batteries are

replaceable as follows:

Step 1) Remove the Wooden Console cover by unscrewing the 2 Phillips Head Screws.

Remove cover from the plastic assembly-see Figure 5.

Step 2) Remove the 3 batteries and dispose of properly. Replace with new batteries.

Replace plastic assembly cover. Replace Console Cover and thread in 2 Phillips

Head Screws-see Figure 5.

#90033 Page 4

Figure 4

Wooden Console

Figure 5

90033 Police Harley .p65 10/30/03, 1:16 PM4

Unpacking

UNPACK AND CHECK CONTENTS

When unpacking your Harley 30” (Police) Toy Rocker, check to make sure the following parts are included. If

any parts are missing or broken, please call HARBOR FREIGHT TOOLS at 1-800-444-3353.

Part # Description Quantity Part # Description Quantity

1 Body 1 7 Side Bag-Front 2

2 Rocker Support 5 8 Seat 1

3 Connecting Plate 2 9 Handlebar 1

5 Rocker Slats 2

6 Side Bag-Sides 4

Part # Description Quantity Part # Description Quantity

A Hex Bolt 2 H Nut 1

B Hex Bolt 4 I Small Washer 2

C Bolt 2 J Big Washer 4

D Hex Bolt 8 K Medium Washer 4

E Screw 2 L Spring Washer 4

Hardware

F Nut 4 M Small Spring 4

G Nut 4 N Wrench 2

#90033 Page 5

Note: Some parts are listed and shown for illustration purposes only and are not available

individually as replacement parts.

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL AS A REFERENCE

TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY

KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS

QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY

STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED

TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER

REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER

INSTALLATION OF REPLACEMENT PARTS THERETO.

O Allen Wrench 1
