Harbor Freight Tools 91835 Manuel utilisateur

Work Benchork Bench

ork Benchork Bench

ork Bench

ASSEMBLY AND OPERATING INSTRUCTIONS

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit ourWeb site at http://www.harborfreight.com

manual or any artwork contained herein may be reproduced in any shape or form

without the express written consent of Harbor FreightTools.

For technical questions and replacement parts, please call 1-800-444-3353

91835

SKU91835 Page 2

Specifications

Save This Manual

Youwillneedthemanualforthesafetywarningsandprecautions,assemblyinstructions,

operating and maintenance procedures, parts list and diagram. Keep your invoice

with this manual. Write the invoice number on the inside of the front cover. Keep the

manual and invoice in a safe and dry place for future reference.

SafetyWarnings and Precautions

WARNING: When using product, basic safety precautions should always be

followed to reduce the risk of personal injury and damage to equipment.

Read all instructions before using this product!

1. Keep work area clean. Clutteredareas invite injuries.

2. Observe work area conditions. Donot use machines orpower tools in damp

or wet locations. Don’t expose to rain. Keep work area well lit. Do not use

electrically powered tools in the presence of flammable gases or liquids.

3. Keep children away. Childrenmustnever beallowedinthework area. Do not

let them handle machines, tools, or extension cords.

4. Store idle equipment. When not in use, tools must be stored in a dry location

to inhibit rust. Always lock up tools and keep out of reach of children.

5. Use the right workbench for the job.There are certain applications for which

thisworkbenchwasdesigned.Itwilldo the job better and more safely at therate

for which it was intended. Do not modify this workbench and do not use this

workbenchfora purposeforwhichitwasnot intended. Donotstandon,orsit on

theWork Bench.

:lairetaM muideMdnadoowdraH draobrebiFytisneD :hsiniFdooWreuqcaLraelC

:snoisnemiDpoTH"2/1-2xW"52xL"2/1-93:snoisnemiDllarevOH"2/1-13xW"52xL"2/1-93

:seirosseccAesiV,sgoDdooW:thgieWteN.sbl8.25

:yticapaCthgieW.sbl052

SKU91835 Page 3

6. Dress properly when working. Do not wear loose clothing or jewelry as they

can be caught in moving parts. Protective, electrically non-conductive clothes

and non-skid footwear are recommended when working. Wear restrictive hair

covering to contain long hair.

7. Useeyeand earprotection. AlwayswearANSIapprovedimpactsafetygoggles.

Wearafull faceshield ifyouare producingmetal filings orwood chips.Wearan

ANSIapproveddustmaskor respirator when working around metal, wood,and

chemical dusts and mists.

8. Do not overreach. Keep proper footing and balance at all times.Do not reach

overoracross running machines.

9. Maintain tools with care. Keep tools sharp and clean for better and safer

performance.Followinstructionsforlubricatingandchangingaccessories.Inspect

tool cords periodically and, if damaged, have them repaired by an authorized

technician.Thehandles mustbe keptclean, dry,and free from oilandgreaseat

all times.

10. Keep your Work Bench surface clean and orderly. A messy or dirty work

surface invites accidents.Store work pieces and tools properly, and keep this

workbench surface clear and clean for each project you work on.

11. Stay alert. Watchwhat youare doing, use common sense.Do not operateany

toolwhen you are tired.

12. Take caution as some woods contain preservatives such as copper

chromium arsenate (CCA) which can be toxic.Whencuttingthese materials

extra care should be taken to avoid inhalation and minimize skin contact.

13. Check for damaged parts. Before using any product, any part that appears

damaged should be carefully checked to determine that it will operate properly

and perform its intended function. Check for alignment; any broken parts or

mountingfixtures;andanyother condition that may affectproperoperation.Any

part that is damaged should be properly repaired or replaced by a qualified

technician.

14. Guardagainst electricshock whenusing electrictools. Preventbodycontact

with grounded surfaces such as pipes, radiators, ranges, and refrigerator

enclosures.

15. Replacement parts and accessories. When servicing, use only identical

replacement parts. Use of any other parts will void the warranty. Only use

accessoriesintendedforuse with this tool. Approvedaccessoriesareavailable

fromHarborFreightTools.

SKU91835 Page 4

16. Donot operatetoolsifunderthe influenceof alcoholor drugs. Readwarning

labels on prescriptions to determine if your judgment or reflexes are impaired

while taking drugs. If there is any doubt, do not operate the tool.

17. Maintenance. For your safety, service and maintenance should be performed

regularlyby a qualified technician.

18. Whenusing tools,always read thesafetywarnings and instructionsin the tool’s

instruction manual before using the tool.

Warning:Thewarnings,cautions,and instructions discussed inthisinstruction

manual cannot cover all possible conditions and situations that may occur. It

mustbe understood bythe operatorthat common senseand caution arefactors

which cannot be built into this product, but must be supplied by the operator.

Unpacking

This product requires assembly.When unpacking, check to make sure the following

partsareincluded.

(1)Top (1)LowerShelf (2) Cross Braces (2) Leg Assemblies

(1) Vise Assembly (6) 50mm Screws (8) 60mm Bolts (8) Threaded Lugs

(1) HexWrench (4)Wood Dogs (4) Small Anvils (1) 10mm Screw andWasher

Ifanyparts are missing or broken,pleasecall Harbor FreightTools at the numberon

the cover of this manual.

Assembly

1. Inserteachof the 8Threaded Lugs(H)ontotheholescross-drilledintheends of

the Cross Braces (C) as shown in Step 1. Use the slots in the end of each Lug

to align the threads with the holes drilled into the ends of the Cross Braces.

2. Attach one Cross Brace (C) to the two Leg Assemblies (D) as shown in Step 2.

Be sure that the slotted side on the Cross Brace faces the interior of the Leg

Assemblies. Secure in place with 4 60mm Bolts (G).

3. Slide the Lower Shelf (B) into position as shown in Step 3.

4. Install the second Cross Brace (C) as shown in Step 4. Be sure the groove on

this Cross Brace also faces inward, so that the Lower Shelf (B) is held in place

by the grooves in both Cross Braces. Secure the second Cross Brace using 4

60mm Bolts (G) as before.You now have a completed“Chassis”.

SKU91835 Page 5

Assembly Drawing

SKU91835 Page 6

5. Lay theTop (A) upside downonthe floor or other flat surfaceasshowninStep5.

Invert the completed Chassis, and align the screw holes in the Chassis with

those in the Top. Be sure to align the front of the Chassis with the front of the

Top.Secure the Chassis to the top using 6 Screws (F).

6. Install theVise (E) into the holes on the front of the WorkbenchTop.Install the

10mm Screw (E1) into the end of theVise Screw as shown in Step 6.This is to

preventtheVise(E)fromcomingapartwhenyouareusingit.Invertthecompleted

Workbench so that it is standing upright on the floor.You may now install the

Wood Dogs (J) or Small Anvils (K) as needed.

NOTE:TheWoodDogs andSmallAnvilsare used asbracesormeasuring pointsfor

various work materials.They are used optionally as needed.When not in use, store

them in a convenient place.

Operation

1. Install yourWork Bench in a clean, dry, well lighted work space.Observe work

space conditions including ventilation, light, proper electrical service, etc. to be

sure that you will be safe working there.

2. Check to be sure yourWork Bench is stable on a sturdy, level surface.It should

not rock when you push on it. If it does, repair the underlying surface.

3. The Vise is useful for holding objects to be drilled or cut. Open the Vise by

turning the handle counterclockwise. Close the Vise by turning the handle

clockwise.Do not overtightenorforcethehandle.Donothammerorbeatonthe

Vise or materials clamped in it, as this will damage theVise.

4. TheWood Dogs and Small Anvils are useful for holding materials on the Work

Benchsurface.Thesemaybeinsertedorremovedfrom theirholesasnecessary.

Maintenance

1. Protect your workbench from water or corrosive materials. Medium Density

Fiberboard(MDF) is especiallyprone to damage if exposedto water.

2. Whenusingyourworkbench, do not drillor cut into the top.Use pieces of scrap

materialunderyour workpiece to preventdamage to the work bench.

3. Rememberthatthe weightcapacityofthisworkbenchis250lbs.Donotoverload

the work bench. Do not throw or drop heavy objects on the Lower Shelf (B). Its

weight capacity is much less than 250 lbs.

4. Wipegrease,oil,orotherforeignmaterialsofftheworkbenchpromptlywhenever

spills occur.Keep the workbench surface clean and free of clutter.

SKU91835 Page 7

NOTE: Some parts are listed and shown for illustration purposes only and are not

available individually as replacement parts.

Parts List

#traPnoitpircseD.ytQ#traPnoitpircseD.ytQ

ApoT1FwercSmm056

BflehSrewoL1GtloBmm068

CecarBssorC2HtuNguLdedaerhT8

DylbmessAgeL2IhcnerWxeH1

EesiV1JgoDdooW4

1E dnawercSmm01 rehsaW .ae1K livnAllamS4

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM

IN THIS MANUAL AS A REFERENCETOOL ONLY. NEITHER THE MANUFACTURER NOR

DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE

BUYERTHAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TOTHE PRODUCT OR

THAT HE OR SHE IS QUALIFIEDTO REPLACE ANY PARTS OF THE PRODUCT. IN FACT,

THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS

AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND

LICENSED TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK

AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT

OR REPLACEMENT PARTSTHERETO, OR ARISING OUT OF HIS OR HER INSTALLATION

OF REPLACEMENT PARTS THERETO.

PLEASE READ THE FOLLOWING CAREFULLY
