User’s Guide

Quick Check® 890

Bar Code Verifier

Quick Check® ImageData

Disclaimer

Hand Held Products, Inc. (“Hand Held Products”) reserves the right to make

changes in specifications and other information contained in this document

without prior notice, and the reader should in all cases consult Hand Held

Products to determine whether any such changes have been made. The

information in this publication does not represent a commitment on the part of

Hand Held Products.

Hand Held Products shall not be liable for technical or editorial errors or

omissions contained herein; nor for incidental or consequential damages

resulting from the furnishing, performance, or use of this material.

This document contains proprietary information that is protected by copyright. All

rights are reserved. No part of this document may be photocopied, reproduced,

or translated into another language without the prior written consent of Hand

Held Products.

Web Address: www.handheld.com

Quick Check®is a registered trademark of Hand Held Products, Inc.

Microsoft, Windows, Windows Mobile, Windows NT, Windows 2000, Windows

ME, Windows XP, ActiveSync, Outlook, and the Windows logo are trademarks

or registered trademarks of Microsoft Corporation.

The Bluetooth®word mark and logos are owned by Bluetooth SIG, Inc.

Note: Software screens included in this document are in English only and are

included for reference only. They may be different from the screen that

displays on your terminal.

Chapter 1 - Getting Started

Introduction........................................................................... 1-1

Unpacking the QC890 Verifier............................................. 1-1

QC890 Verifier Features....................................................... 1-1

Using the QC890 Verifier..................................................... 1-2

Scan Button........................................................................... 1-2

Scan Button LEDs.......................................................... 1-2

User LED Indications..................................................... 1-3

Physical Connections............................................................ 1-3

Specifications........................................................................ 1-4

Internal Battery ..................................................................... 1-4

Charging the Battery ...................................................... 1-4

Powering On the QC890 Verifier .................................. 1-4

Chapter 2 - Quick Check ImageData

Quick Check ImageData....................................................... 2-1

Installation of Quick Check ImageData ............................... 2-1

Communication Interfaces.................................................... 2-1

USB Communication Interface ...................................... 2-1

USB COM Port Emulation............................................. 2-2

RS-232 Serial Communication Interface ....................... 2-3

RS-232 Selections .......................................................... 2-3

Bluetooth............................................................................... 2-3

Using the QC890 Verifier with Bluetooth Devices ....... 2-4

Enabling Your Device for Bluetooth.................................... 2-5

Enabling QCID for Bluetooth............................................... 2-7

Using Quick Check ImageData ............................................ 2-8

Help System.......................................................................... 2-9

Chapter 3 - Using the Quick Check 890 Verifier System

Scanning a Bar Code Symbol Using the QC890 Verifier .... 3-1

Scanning a Bar Code Symbol Using

Quick Check ImageData .................................................... 3-1

Table of Contents

Calibrating the QC890 Verifier ............................................ 3-2

Scanning Properly Using a Pen/Mouse Wand...................... 3-3

Calibrating an External Pen/Mouse Wand ........................... 3-4

Scanning Properly Using the QC3800V Linear Imager:...... 3-5

Calibration Log..................................................................... 3-6

Reflectometer Mode ............................................................. 3-7

Chapter 4 - Maintenance

Cleaning the External Devices.............................................. 4-1

QC890 Verifier ..................................................................... 4-1

Recertification....................................................................... 4-1

Chapter 5 - Customer Support

Product Service and Repair .................................................. 5-1

Online Product Service and Repair Assistance.............. 5-2

Technical Assistance ............................................................ 5-2

Online Technical Assistance .......................................... 5-3

Limited Warranty.................................................................. 5-3

Chapter A - Apertures

Pen/Mouse Wand Aperture Selection...................................A-1

Chapter B - Menu Setting Bar Codes

Resetting the Standard Product Defaults ..............................B-1

Illumination Timer................................................................B-1

Power Down Timer...............................................................B-1

Chapter C - Symbology Defaults - Operation

Quick Check® 890 User’s Guide 1 - 1

Getting Started

Introduction

The Quick Check® 890 Verifier System (QC890) is a professional quality control

system for verifying the readability and standards compliance of printed linear

bar code symbols. This verification system implements an integrated approach

that consists of the QC890 Verifier unit and the Quick Check® ImageData

(QCID) software.

The QC890 system offers ease of use, stability and repeatability, flexibility,

increased user features and control, and quality testing of the most common

industry applications and symbologies.

Unpacking the QC890 Verifier

After you open the shipping carton containing the product, take the following

steps:

• Check for damage during shipment. Report damage immediately to the

carrier who delivered the carton.

• Make sure the items in the carton match your order.

• Save the shipping container for later storage or shipping.

The standard accessories that should be included in your kit are:

• Quick Start Guide

• CD with QCID software and this User’s Guide

• DC power supply with cord (includes adapters for different countries)

• Interface cables (USB and RS-232)

• Plastic gauge

•Metalruler

• Reference test symbols

• Calibration bar code page

QC890 Verifier Features

The QC890 Verifier is a full-featured bar code verification system compatible with

all major linear bar code symbologies. It is both a quick and easy-to-use pass/

fail analyzer of bar code symbols and a powerful measuring tool for detailed

testing of bar code symbols.

The QC890 Verifier provides all of the information you need to interpret overall

symbol quality.

1 - 2 Quick Check® 890 User’s Guide

The verifier tests the following symbologies:

Using the QC890 Verifier

The QC890 Verifier offers a choice of Automatic, 5, 6, and 10 mil aperture

settings. External devices (i.e., mouse wands, pen wands, and linear imagers)

are available with apertures designed to match the most common X dimensions.

Wands are available with apertures of 3 (Mouse Wand only), 5, 6, 10, and 20

(Mouse Wand only) mil. These aperture sizes correspond to those specified in

ISO/IEC 15416 Bar Code Print Quality Test Specification - Linear Symbols. The

proper aperture should be selected based on the X dimension range shown in

the table in the Pen/Mouse Wand Aperture Selection (page A-1) section.

Choosing an inappropriate scanning aperture results in inaccurate quality

measures. Too small an aperture may detect reflectance non-uniformities (spots

and voids) that would not affect scanning with a "normal" aperture size. Too large

an aperture will not be able to resolve individual elements of the symbol.

Scan Button

The scan button on top of the unit wakes the unit from power down. A first press

of the button turns on illumination and a second press activates reading

capabilities.

Scan Button LEDs

• Red LED - error conditions

• Green LED - good symbols and configuration changes

Codabar Interleaved 2 of 5

Code 11 MSI

Code 16K PDF417

Code 39 Reduced Space Symbology (RSS-14,

RSS Limited, RSS Expanded)

Code 49 Regular 2 of 5

Code 93 Telepen

Code 128 UPC/EAN

IATA 2 of 5

Quick Check® 890 User’s Guide 1 - 3

User LED Indications

Audio Sound

An audio signal (default ON) provides a quick indication if a scan passes or fails

the current test. You can change the pitch/volume of these beeps (see

Illumination Timer on page B-1). After a scan, one short, high pitch beep

indicates that the symbol passes an appropriate group of tests, while one long,

low pitch beep indicates that it fails.

Special Features

The QC890 Verifier supports the Reflectometer mode. In the Reflectometer

mode, the unit operates as a free-running reflectometer. See "Reflectometer

Mode" on page 3-7 for additional information.

Physical Connections

A DC power barrel on the back of the unit connects to a power supply for external

power and battery charging.

The DB9 port on the unit connects to the pen wand, mouse wand, or customized

imager. Refer to "Scanning Properly Using the QC3800V Linear Imager:" on

page 3-5. If you are using any of these devices, refer to "Scanning Properly

Using a Pen/Mouse Wand" on page 3-3 for additional information.

The RJ45 ten pin connector provides the USB or RS-232 serial interface to the

host. Refer to "USB Communication Interface" on page 2-1 and "RS-232 Serial

Communication Interface" on page 2-3 for details on connecting your unit.

LED Indication Cause

Green Solid Charging

Green Flash Good read

Red Solid Error condition

Red Flashing Low battery

1 - 4 Quick Check® 890 User’s Guide

Specifications

Internal Battery

Note: Batteries are factory replaceable only. You must return your unit to Hand

Held Products for replacement (see Product Service and Repair on page

5-1).

Charging the Battery

Note: The battery may be in an unknown charge state at delivery. We

recommend that you charge the battery for at least 6 hours prior to use.

You may use the while charging it.

To charge the batteries:

1. Plug the power supply into the port on the back of the unit.

2. Plug in the power supply to the AC main source.

The QC890 Verifier uses a rechargeable battery. The QC890 Verifier can be

operated from the battery or power supply. With a set of properly charged

batteries, the unit operates for a minimum of 20 hours. When not in use, you can

leave the unit connected to the charger.

Powering On the QC890 Verifier

• If the power supply is attached and plugged into a wall outlet, the QC890

Verifier is on.

• If the QC890 Verifier is attached to the USB host with power on, the verifier

is on.

• If the QC890 Verifier is operating using the battery, it shuts itself off after 15

minutes of inactivity to conserve battery power. Pressing the scan button on

top of the unit one time powers up the unit from the power down mode.

Item Specification

Dimensions 7” (18cm)W x 6”(15.cm)H x 5.4” (14cm)D

Weight 1 lb 8 oz (680 grams)

Temperature Storage: -20° to 70°C

Operational: 0° to 50°C

Humidity 20% to 95% RH non condensing

Battery Built-in factory - Lithium Ion rechargeable

Quick Check® 890 User’s Guide 2 - 1

Quick Check ImageData

The Quick Check ImageData (QCID) program was designed for use in

conjunction with the QC890 Verifier. Use of any other hardware devices with this

program is not supported. Installation of the QCID software for your appropriate

operating system is included on the CD-ROM that accompanied your verifier.

The QCID is the graphical interface to the Quick Check 890 Verifier. The

verification results can be saved for later reference.

Installation of Quick Check ImageData

To install the Quick Check ImageData, insert the CD and follow the instructions

that display.

Communication Interfaces

The QC890 Verifier system supports the following interfaces: USB, RS-232, and

Bluetooth®.

USB Communication Interface

For the USB interface, the Hand Held Products CDC-ACM driver must be

installed prior to using the QC890 Verifier. This driver is copied to the following

directory during install:

<install location>\Drivers\USBCOMPortEmulation/hhpcdc.inf

The default <install location> is C:\Program Files\Hand Held Products\Quick

Check ImageData\drivers\USBCOMPortEmulation.

2 - 2 Quick Check® 890 User’s Guide

Note: Please review the file, readme.htm, in the install location prior to running

the QCID.

Connect the QC890 Verifier to the host as shown in the illustration below.

USB COM Port Emulation

Scan the following bar code to program the QC890 Verifier to emulate an RS-

232-based COM Port. After connecting the QC890 Verifier and upon successful

installation of the USB driver, the driver will use the next available COM Port. All

QC890 Verifiers that have been configured for USB COM Port emulation use this

host assigned port number. USB COM Port Emulation is the default interface for

the QC890 Verifier.

Note: No additional configuration (e.g., baud rate) is necessary.

* USB COM Port Emulation

Autres manuels pour QUICK CHECK 890

Table des matières

Autres manuels Hand Held Products Lecteur de codes-barres

Hand Held Products

Hand Held Products Quick Check PC600 Manuel utilisateur

Hand Held Products

Hand Held Products 4600g Manuel utilisateur

Hand Held Products

Hand Held Products 4800p Manuel utilisateur

Hand Held Products

Hand Held Products 4600g Manuel utilisateur

Hand Held Products

Hand Held Products IMAGETEAM 3800E Manuel utilisateur

Hand Held Products

Hand Held Products 2020 Manuel utilisateur

Hand Held Products

Hand Held Products Scanteam 5700 Manuel utilisateur

Hand Held Products

Hand Held Products Quick Check PC600 Manuel utilisateur

Hand Held Products

Hand Held Products IMAGETEAM 3900 Manuel utilisateur

Hand Held Products

Hand Held Products 4X00 Guide de démarrage rapide

Hand Held Products

Hand Held Products HandHeld 3800 Linear Series Manuel utilisateur

Hand Held Products

Hand Held Products 3800ESD Manuel utilisateur

Hand Held Products

Hand Held Products 3800PDF Manuel utilisateur

Hand Held Products

Hand Held Products 4X00 Manuel utilisateur

Hand Held Products

Hand Held Products 2020 Guide de l'utilisateur

Hand Held Products

Hand Held Products IT4000 Manuel d'utilisation et d'entretien

Hand Held Products

Hand Held Products IMAGETEAM 4410 Manuel utilisateur

Hand Held Products

Hand Held Products 3200 Manuel utilisateur

Hand Held Products

Hand Held Products 4820 Manuel utilisateur

Hand Held Products

Hand Held Products Quick Check QCOLV-SV100 Manuel utilisateur

Hand Held Products

Hand Held Products Valueteam 3060 Manuel utilisateur

Hand Held Products

Hand Held Products 2020 Manuel utilisateur

Hand Held Products

Hand Held Products 4230 Manuel utilisateur

Hand Held Products

Hand Held Products DOLPHIN RF Manuel utilisateur

Manuels Lecteur de codes-barres populaires d'autres marques

POSMicro

POSMicro Datalogic PowerScan D7100 Manuel utilisateur

Marson

Marson MT780 Guide de configuration rapide

NCR

NCR RealPOS Manuel utilisateur

Motorola

Motorola SE3300 Guide de configuration rapide

Element

Element P130BT Manuel utilisateur

Motorola

Motorola Symbol LS3008 Manuel d'installation et d'exploitation

Meec tools

Meec tools OBD-II / VAG Manuel utilisateur

SICK

SICK CLP 100 Manuel utilisateur

Royal Tag SA

Royal Tag SA I-Read Manuel utilisateur

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuel utilisateur

Meteor

Meteor 8310 Manuel utilisateur

Denso

Denso BHT-500B Manuel utilisateur

Datalogic

Datalogic Heron HD3130 Manuel utilisateur

Motorola

Motorola MP6000 Instructions de montage

Newland

Newland NLS-HR15-BT Manuel utilisateur

ARTDEV

ARTDEV AS-1310 Manuel utilisateur

Aopos

Aopos AS290 Manuel utilisateur

ENS

ENS 367-5455 Manuel utilisateur
