Hamilton Beach HBFRF513-B Manuel utilisateur
Safety Precautions .....................................................................................3
Parts And Features ...................................................................................5
Freezer Features And Use ........................................................................8
Proper Freezer Care and Cleaning ............................................................11
Troubleshooting .........................................................................................
14
Manual Defrosting Instructions....................................................................13
Installing Your Freezer................................................................................6
Unpacking Your Freezer ...........................................................................6
Adjusting Your Freezer ..............................................................................6
Proper Air Circulation ................................................................................6
Electrical Requirements .............................................................................7
Use of Extension Cords ...................................................................... 7
Install Limitation .......................................................................................7
Operating Your Freezer .............................................................................8
General Features ........................................................................................
8
Food Storage Baskets ............................................................................... 9
Food Storage Information .........................................................................10
Normal Operating Sounds .........................................................................10
Cleaning and Maintenance ........................................................................
11
Power Interruptions ...................................................................................
12
Vacation and Moving Care .........................................................................
12
Congratulations,you have acquired a high-quality Hamilton Beach Chest Freezer
This unit is packed with features that you will find convenient to use.
Please follow the safety precautions and operating instructions provided in this
easy-to-use manual. Please take the time to read it,and save these instructions for
future use. Please also remember to record the series number.The series number
is located on the top of the unit next to the motor. Save your receipt by stapling it
to this manual for convenient access.
Warranty ..................................................................................................16
Product Specifications ................................................................................15
3
Safety Precautions
Read all of the instructions before using this appliance. When using this
appliance, always exercise basic safety precautions, including the
following:
1. Use this appliance only for its intended purpose as described in this use
and care guide.
3. Never unplug your freezer by pulling on the power cord. Always grasp
5. Unplug your freezer before cleaning or before making any repairs.
If for any reason this product requires service, we strongly
6. Do not use any electrical device or any sharp instrument in
defrosting your freezer.
7. If your old freezer is not being used, we recommend that you remove
the doors. This will reduce the possibility of danger to children.
8. After your freezer is in operation, do not touch the cold surfaces in the
freezer compartment, particularly when hands are damp or wet. Skin
may adhere to these extremely cold surfaces.
9. Do not refreeze foods, which have been thawed completely. The United
States Department of Agriculture in Home and Garden Bulletin No.69
reads:"...You may safely refreeze frozen foods that have thawed if they
still contain ice crystals or if they are still cold-below 40F".
off-color should not be refrozen and should not be eaten. Thawed ice
cream should be discarded. If the odor or color of any food is poor or
questionable, discard it. The food may be dangerous to eat."
...Even partial thawing and re-freezing reduces the eating quality of
foods, particularly fruits, vegetables, and prepared foods. The eating
quality of red meats is affected less than that of many other foods. Use
refrozen foods as soon as possible, to save as much of its eating quality
as you can.
4. Repair or replace immediately, all electric service cords that have
become frayed or otherwise damaged. Do not use a cord that shows
cracks or abrasion damage along its length, the plug or the connector
end.
2. This freezer must be properly installed in accordance with the
installation instructions before it is used. See grounding instructions in
the installation section.
4
10. This refrigerator should not be recessed or built-in an enclosed
cabinet. It is designed for freestanding installation only.
11. Do not operate your refrigerator in the presence of explosive fumes.
propellant in this appliance.
13. WARNING: keep ventilation openings, in the appliance enclosure or in
the builtin structure, clear of obstruction.
14. WARNING: do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by
the manufacturer.
15. WARNING: do not damage the refrigerant circuit.
16. WARNING: do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
Staple your receipt to your manual.
You will need it to obtain warranty service.
DANGER: Risk of child entrapment. Before you throw away your old
refrigerator or freezer:
* Take off the doors.
* Leave the shelves in place so that children may not easily climb inside.
Save These Instructions
For Future Reference Please
5
1. Temperature Control Adjustment 2. Plastic Removable Storage Basket
3. Exterior Drain Dial 4. Compressor on Indicator (green)
3
4
1
2
Parts And Features
4
6
1. Remove all packaging material. This includes the foam base and all
adhesive tape holding the freezer accessories inside and
outside.
2. Inspect and remove any remains of padking, tape or printed
materials before powering on the freezer.
Your freezer is designed for freestanding installation only.
It should not be recessed or built-in.
When moving the freezer, never tilt it more than a 45-degree angle.
This could damage the compressor and the sealed system.
If the freezer is tilted let it stand in an upright position for at least 24
hours prior to plugging. This is to allow the refrigerant to settle.
was designed for, you should install it in a locatian where there
is proper air circulation, plumbing and electrical connections.
The following are recommended clearances around the refrigerator:
Sides.................4"(102mm)
Top..................24"(600 mm)
Back..................4"(102mm)
Unpacking Your Freezer
Adjusting Your Freezer
Proper Air Circulation
4
7
Electrical Requirement
Use of Extension Cord
Install Limitations
-
Make sure there is a suitable power Outlet(115 volts, 15 amps
outlet) with proper grounding to power the freezer.
Avoid the use of an extension cord because of potential safety haz-
ards under certain conditions. If it is necessary to use an extension
cord, use only a 3-wire extension cord that has 3.blade grounding
plug and a 3-slot outlet that will accept the plug. The marked rating
of the extension cord must be equal to or greater than the electrical
rating of the appliance.
Do not install your freezer in any location not properly insulated or
heated e.g. garage etc. Your freezer was not designed to operate in
temperature setlings below55° Fahrenheit.
Select a suitable location for the freezer on a hard even
surface away from direcl sunlight or heat source e.g. radiators,
hould be corrected.
Avoid the use of three plug adapters or cutting off the third grounding
in order to accommodale a two plug outlet. This is a dangerous
practice since it provides no effeclive grounding for the freezer and
may result in shock hazard.
This appliance is intended to be used in household and similar applica
tions such as
environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
- staff kitchen areas in shops,office and other working environments;
- farm houses and by clients in hotels,motels and other residential type
4
8
Operating Your Freezer
Adjustable temperature dial: 1)
General Features
Once the freezer is in its proper place, plug it in an electrical outlet
having 115 volts and 15 amps. Turn on power switch. Power light will
come on, the green "run" light will be lit indicating that the freezer
compressor is in operation.
Set the temperature, on the temperature control knob. "1" being the
warmast and "7" being the coldest. Initially set the temperature on
"4". Place faod inside the freezer. After using the freezer for 24 hours
set the freezer to your desired setting.
In case you unplug your freezer or experience an electrical outage,
allow 5 minutes before plugging it back in.
Your freezer will automatically main-
tain the temperature level you select
The temperature control dial has 7
settings plus"0". "1" is the warmest,
"7" is the coldest. Turning the dial to
"0" stops cooling the freezer. Set the
dial to "4" and allow 24 hours to pass
before adjusting the temperature to
your needs.
(Note: If the freezer has been
placed in a horkzontal or
tilted position for any perlod
of time wait 24 hours before
plugging the unit in.)
4
9
Food Storage Basket
Your freezer has a basket. Removable baskets allow you
to slore food more accessibly or you can remove them if not needed.
0
6
1
7
2
4
3
5
temperature control dial
4
10
