Haier MK-2280M Manuel utilisateur

Household Microwave Oven

Contents

Before Use

Features of theProduct ............ 1

Names of theParts ................... 2

Safety Precautions ...................3

Installation Environment ...........5

Open the PackageCarton *

Installation .............................. 5

Microwave control Pannel.........6

Example of prog ramming a cook-

ing programme......................... 7

Usage .....................................9

Selection of the Cooking

Dishware ...............................12

Cooking Tips ..........................13

Maintenance * Repair .............14

Answers to Questions ............ 15

After-sales Service ................ 16

Usage

Maintenance*Repair

* Please read this manual carefully

before use.

* Please keep it attentively.

* See to the physical sample for the

appearence color or pattern.

MK-2280M

MK-2280MG

Time Adjust

Power Level

MK-2280

The door adopts unique anti-choke structure and integrated punch forming,

And thus effectively prevents the microwave from leaking.

It is controlled by two-step interlock switch. The power will be switched off

automatically when the door is open, therefore it is much safer to use.

It has modern appearance and superior quality, and thus becomes the

best choice for the household microwave oven.

The sealing part of the cavity is produced with antiseptic materials, and

can suppress the reproduction of the bacteria effectively.

The special function of the microwave oven can eliminate the germ in the

food quickly and completely.

Safe to use

Features of the Product

Shining appearance

Healthy and germicidal

Names of the Parts

shell

cavity

door

operation

board

door seal

useful volume of the

cavity is 15L

(only for MK-2280MG)

door hook

baking

mesh

glass rotary

tray

tray support

diagrammtic sketch for

the accessory installation

TimeAdjust

Power Level

MK-2280

Please read the safety precautions carefully to guarantee safe and convenient

use of Haier microwave oven.

Do not usethe microwave ovenfor purposes

other than forcooking food

This appliance mustbe earthed

Do not cookeggs in their shells to avoid

bursting

Remember to clear away excess grease

from the insidethe cavity. Otherwise it may

cause smoke orfire during heating.

Do not apply excess force to the door.It

may cause distortionof the door and result

in microwave leakage.

Do not use sealed containers . For those

foods with skin,please prick holes on the

skin.

No one except the professional technicians

are permitted todisassemble the microwave

oven, or itmay result in electric shock.

Do not usemetal rod to enter the interlock'

switch hole onthe front side of the cavity. It

may cause hazard.

Safety precautions

Danger

Danger Danger

interlock switch hole

Warning

Warning Warning

Warning

Warning Warning

Attention

Electric

shock

hazard

dismantle

safe and

reliable

Do not use it withthe cavity empty. It will

damage the microwave oven.

Allow the cavity to cool after long cooking

processes (i.e. Roasting etc) before

starting another cook cycle.

1. If the door seal or the door body is damaged, please do not use the

appliance before it is repaired by professional technicians.

2. Before use, please check if the cooking containers are suitable for

3. If you find smoke in the oven, leave the door in the closed position, and

switch off the power supply of the oven (remove the plugtop from the

4. We do not recommend the use of plastic, paper or other combustible

materials containers for cooking, please be sure to observe the operating

instructions for the microwave oven, in order to avoid accidents

5. When you heat liquid in the oven, please take care of the delayed

splashing of possible boiling liquid.

6. Do not use the microwave oven if there's no food inside, so as to avoid

damaging the appliance by no-load running.

7. Children are not allowed to operate the microwave oven without the

Do not use the product for any industrial and commercial purpose.

When roasting, the faceof the door and

the top of the cabinet maybecome hot to

touch.

Do not use metallic dishware to cook with

microwave as it will cause internal arcing.

microwave oven.

supply socket).

instruction of adults.

warning warning

warning

Warning

Safety Precautions

Ventilation spaceis required in installation

of the microwaveoven.

Do not install the microwave oven in

environment that ishumid or with high

temperature.

Open the

carton user's

manual baking mesh

glass rotary tray

rotary tray support

Install

Put the microwaveoven levelly at the

position you choose. Keep good

ventilation.

Select independent specialsocket,

with current atleast 10A. Be sure to

ground it reliable.

The gaps shallbe all above 15cm

attention attention

Installation Environment

Open the Package Carton* Installation

MICROWAVE control Pannel

Indicator light Seconds

Power levels

Power level mark

The mark must be exactly lined up with a power

level.

In any event, a continuous beep tone indicates

that the mark is between two power levels.

In this case, turn the knob (5) forwards or back-

wards until the beep tone switches off.

7 Power levels:

Low =Low microwave power

Intermediate level Low-Med

Med =Medium microwave power

Intermediate level Med-M.H

M.H =Mediumhigh microwavepower

Intermediate level M.H-High

High =High microwave power

Seethenextpage for anexample of programmming

acookingprogramme

Turn the knob until the mark (6) is in line with

the desired power level.

The power level can be changed during

operation.

Attention! Before using the appliance for the first time,read

the MICROWAVE general instructions(see separate book)

Indicator light Minutes

Lights up when a numberof minutes is shown

in the LED display.

Cooking time display

Cooking timer (Max. 30 min.)

To increase cookingtime: turn the knob clockw-

ise to the right.

To reduce cookingtime: turn the knob to the left

The cooking time set is indicated in theLED dis-

play.

Example:

1st. Cooking time 2 min: LED display 02 &(1)

lights up 2nd. Cooking time 25 sec.: LEDdisplay

25 & (3) lights up While a cooking programme

is being executed, the clock counts down.

The cooking time can also be increased orredu-

ced while the appliance is operating.

3. Programme completed: LED display 00 &

5 Beep signal.

Lights up when a numberof seconds is shown

in the LED display.

LED Display

Function description

Power Level

Time Adjust

Stop

Low

Med

M.H.

High

ID CODE 030MWO

Example of programming

a cooking programme

Appliance is in Stand-by mode

1. Open the appliance door andplace the food

on the turntable inside

2.Close the appliance door.

3. Touch / release knob (5) and turn the

released knob clockwise to the right until

the mark (6) is in line with the M.H power

level.

4. Touch / release knob (4)and turn the released

knob clockwise until the indicator light (1) lig-

hts upand the number of minutes 03 is

shown in the display (2).

The programme starts 2-3 seconds after the

cooking time stops beingaltered.

The remaining cooking time is continuously

shown in the display (2). (The clock counts

down)

5. Lf required, the powerlevel and the cooking

time can be altered while the appliance

oper ates.

6. When the cooking programme is completed,

the figure 00 is shownin the d isplay(2) and

5 short beepsindicate the endof the programme.

7. Open the appliance door andtake the cooked

food out of the appliance. (Use oven gloves)

8.After each programme end, turn the powerlevel

knob (5)tothe Stop position to prevent the

appliance from being inadvertently op erated

without food. (This can damage theappliance)

9. Allow the food to rest to one sidebriefly efore

serving. Lt can thus cook inside a little more

and can cause burns if eaten immediately.

Power Level

Time Adjust

Stop

Low

Med

M.H.

High

3.minutes cooking/simmerin with

Medium high(M.H.)power level

ID CODE 030MWO

Position/Level

available

depending on Model

Function/Application

Turn the power level selector knob to the Stop position each time

after use, to prevent th appliance inadvertently bein operated

without food.

When the selector knob is at the Stop position, the appliance cannot

be operated and cooking times can no longer be set on the cooking

timer(4).

When a cooking programme is running, it can beinterrupted at any

time by turning the selector switch to the Stop position.

An interruption caused in this way is confimed by a ringing tone.

Microwave

Power

285W

510W

650W

Setting the power/programme levels MK-2280M

ID CODE 030MWO

Programme selector knob(5)

Grill

Power

NoneNone

Defrost frozen food

Food heating up milk or other drinks

For steaming/braising/warming up food

For rapid heating up/simmering of food

Full power

800W

(Medium high)

None
