Haier HDW100SST Manuel utilisateur

61505

Parts Manual

Dishwasher

Model:

HDW100SST HA

Product Code:

61505

61505 - NOVEMBER 2009

Fisher & Paykel Appliances Ltd

78 Springs Road,

East Tamaki,

PO Box 58-732, Botany,

Manukau 2163,

New Zealand

Telephone: 09 273 0600

Facsimile: 09 273 0656

PRODUCT

Brand Haier

Voltage 220-240V, 50Hz

Model HDW100SST HA

Product Code 61505

61505

CONTENTS

CABINET & BASKET AREA .............................................................................................................6

RETICULATION AREA.....................................................................................................................8

DOOR AREA...................................................................................................................................12

61505

CABINET & BASKET AREA

61505

CABINET & BASKET AREA

REF PART DESCRIPTION

1 H0120103797 COMPLETE TOP

2 H012G2150035 SHELF FASTENING SMALL BLOCK

3 H0120200964 WHEEL FOR LOWER BASKET

4 H012G2150037 DOOR HOOK

5 H012G1310020 UPPER REAR CROSSPIECE

6 H0120104772 PAINTED RIGHT SIDE PANEL

7 H0120104771 PAINTED LEFT SIDE PANEL

8 H0120807361 INSULATED TUB ASSEMBLY

9 H0120300248 TUB GASKET

10 H0120200967 BASKET RAIL STOP

11 H012G1020069 MOBILE RAIL FOR BASKET

12 H0120200966 RAIL SUPPORT ASSEMBLY

13 H0120200124 UPRIGHT SMALL BLOCK

14 H0120200656 RIGHT BASEBOARD SIDE PLATE

15 H0120200655 LEFT BASEBOARD SIDE PLATE

16 H0120200654 BASEBOARD

17 H0120200065 COVER FOR FRONT CROSSPIECE

18 H012G1310027 LOWER FRONT CROSSPIECE

19 H012G1451091 FRONT FOOT SUPPORT

20 H012G1610002 ADJUSTABLE FOOT

21 H012G1310023 REAR INTERMEDIATE CROSSPIECE

22 H012G2160204 DRAIN HOSE STOP

23 H0120101601 LOWER REAR CROSSPIECE

24 H0120105715 TRAY

25 H012G1610002 ADJUSTABLE FOOT

26 H0120106652 UPPER BASKET

27 H0120200963 WHEEL FOR UPPER BASKET

28 H0120200965 WHEEL SUPPORT PIN

29 H0120201235 RACK FOR UPPER BASKET

30 H0120801727 CUTLERY BASKET

31 H0120106687 FIX LOWER BASKET

32 H0120106568 STRENGTHEN IRON (LEFT)

33 H0120106569 STRENGTHEN IRON (RIGHT)

61505

RETICULATION AREA

61505

RETICULATION AREA

REF PART DESCRIPTION

34 H012G2160241 OUTER DUCT

35 H012G4050157 O-RING GASKET

36 H0120202777 UPPER SPRAYER BASE

37 H0120202779 INNER DUCT COVER

38 H0120202780 INNER DUCT SEALING

39 H0120300947 DIVERSION PIPE SEALING

40 H0120201019 UPPER SPRAYER ASSEMBLY

41 H0120202056 SUPPORT FOR FLOAT

42 H0120505219 FLOAT FOR ACQUASTOP

43 H012G6050040 MICRO SWITCH

44 H012G5060020 1-WAY SOLENOID VALVE

45 422680P HOSE INLET LONG (2M) PKD

46 H0120400440 POWER SUPPLY CABLE

47 H012G2160197 AIR BREAK NOZZLE

48 H0120201008 BREATHER RING NUT

49 H012G6010009 THERMO LIMITER

50 H012G1450902 BUSH FOR FASTENING OF HEATING ELEMENT THERMIC SWITCH

51 H012G8040038 ELASTICITY RETAINER

52 H0124000661 DRAIN PUMP

53 H012G4050158 O-RING GASKET

54 H012G1040020 BAND

55 420667P GUIDE DRAIN HOSE

56 H012G2140061 DRAIN HOSE

57 H012G6050043 WATER-LEVEL PRESSURE SWITCH

58 H012G2140067 PRESSURE SWITCH TUBE

59 H012G8050084 BAND

60 H0120202556A INSULATED TUB INLET

61 H012G1040020 BAND

62 H0124000163 THERMO LIMITER ASSEMBLY

63 H012G4050150 O-RING GASKET

64 H012G8060036 DENTIFORM RETAINER

65 H0120203065 WATER GUTTER

66 H012G4050151 CUP GASKET

67 H0120201292 RING NUT FOR CUP FASTENING

68 H012G1040014 MICROFILTER (POLYESTHERE)

69 H0120200949 INNER FILTER SCREEN

70 H012G1040012 PLANE FILTER SCREEN

71 H0120201009 EXTRACTABLE GLASS-FILTER

72 H0120202778 INNER DUCT

73 H012G4050152 RUBBER COUPLING

74 H012G1040028 BAND

75 H012G2160193 LOWER SPRAYER BASE FIXING PIECE

76 H012G4050153 O-RING GASKET

77 H0120201006 RING NUT FOR LOWER SPRAYER FASTENING

Continued next page

61505

RETICULATION AREA
