Haier HM-G552-FL Manuel utilisateur
·Please read the instructions carefully before use
·Haier reserves the right to explain the instructions
·The pictures are for reference only
UserManual
4G Smart Phone
Model:
G7lite
HM-G552-FL
Haier Europe Trading SRL
http://www.haier.com
3-5 Rue des Graviers, 92200, Neuilly-sur-Seine, France
Safety Cautions
4
7
8
10
10
12
14
16
17
18
23
23
25
27
28
31
34
35
37
38
41
42
Trouble Shooting 52
MobilePhone-UserManual
1
Knowing Your Phone
5
1
4
6
7
2
3
89
12
11
13
10
15 14
MobilePhone-UserManual
2
MobilePhone-UserManual
3
Removing the back cover
You must remove the back cover to install 4G LTE RUIM card,
SIM card and SD card. Hold the lower half of the phone with
battery cover upwards, and lift the bottom of the battery
cover, then the battery cover can be removed.
MobilePhone-UserManual
4
●Please turn the phone off before open the battery to
Caution
Caution
prevent damage.
●Please be careful when opening the back cover, follow it
accordingly to prevent damage.
Inserting the RUIM and SIM Card
You must insert SIM card on the phone to enjoy and enable
all the features. Your card contains all your subscription
information.
Insert 4G LTE RUIM and SIM card with the metal contacts
facing down and the cut corner is aligned with the cutting on
the slot.
●If SIM card is not installed, or there are errors in the
insertion, or the card is damaged, “No service notification
will appear on the screen after your phone is powered on.
●If the PIN is enabled you need input the PIN number to
unlock it before you contrast using the phone.
●The GSM function will not work if SIM card is not present.
MobilePhone-UserManual
5
Inserting SD Card
Insert Micro SD Card with the metal contacts facing down
and the cut corner aligned with that of the slot.
●Please insert or remove the Micro SD Card when the
phone is powered off, or the Micro SD Card or the phone
might get damaged and the data on the Micro SD Card
could be lost.
Micro
SIM 1
Micro
SIM 2
TF card
MobilePhone-UserManual
6
Caution
●You might need to restart your phone after setting the
storage to SD-Card or when inserting an SD-Card.
Installing the battery
You must install and charge the battery to use your phone.
Insert the ridge at the top of the battery into the base of the
phone, make sure to touch the metal contact on the phone,
then push the battery down and snap it into place.
●Do not forces to turn the phone back on over and over if
the battery is too low, it might cause damage to the phone
and the battery.
●Please turn the phone off before open the battery to
prevent damage.
Note:
Caution
Your phone is designed to be used only with the original
batteries and chargers. The use of other batteries or
chargers is not recommended it may cause damage to your
phone and the warranty will be void.
MobilePhone-UserManual
7
Removing the battery
Make sure your phone is powered off before taking out the
battery to prevent data loss from the phone.
Charging the battery
New batteries are shipped partially charged. Before you can
use your phone, you need to charge the battery. Some
batteries will have best performance after several full
charge/discharge cycles, follow the instruction bellow:
MobilePhone-UserManual
8
1）Connect data cable and charger, plug one end into your
phone’s data port.
2）Plug the other end of the charger into the appropriate
electrical outlet (100~240V AC).
3）When your phone indicates that the battery is fully
charged, remove the charger.
Notes:
●The battery is removable, please properly install them to
prevent damage, and use the original battery and charger
●The battery can discharge gradually even when your
phone is powered off. If the battery is drained for a long time,
the information stored in the phone could possibly be lost.
●Even when you are not using the phone, it would be best to
charge your phone periodically to keep it away from draining.
●If the battery is charged after draining, the phone cannot
be turned on. The battery needs to be charged for a while,
after wardthen the phone will go to power-off charging
mode and you can turned on the phone.
●You need longer charging period with the lower voltage.
●Recommening do not operate phone during charging.
●The normal charge temperature is during 0⁰C- 40⁰C.
●Please avoid prolonged charging when the battery is full.
MobilePhone-UserManual
9
