Haier AE182FCAHA Manuel utilisateur

AE092FCAHA

AE182FCAHA

0010570925

Household MRV

Ceiling Concealed Type Room Air Conditioner

AE092FCAHA

AE182FCAHA

Heating operation indication

For adjusting the clock and

time for timer operation.

Note: This model of air conditioner doesnt provide the air sending direction adjustment function and thus

the "LOU" key is disengaged while the automatic air direction indication may be displayed.

This remote controller hasn't electric-aided heating indication as well as anion generation function

and indication.

Part description Remote controller

ion

Cooling operation indication

Dehumidifying operation indication

Fan only operation indication

Operation indicator

Sleep status indication

Temperature display

Automatic louver indication

LOU key

FAN SPEED key

TEMP step key

Used to select fan speed:

LOW, MID, HI, AUTO.

Used to turn on /off the machine.

Used to select operation mode:

AUTO, COOL, DRY, HEAT, FAN.

For setting a desired temper-

ature value.

Power ON/OFF key

CLOCK key

TIMER key

SET key

HOUR step key

SLEEP key

For checking the clock time.

For selecting timer mode:

TIMER ON

TIMER OFF

TIMER ON/OFF

For setting the clock and time

for timer operation.

For setting the sleep status.

Automatic operation

Clock display

TIMER ONdisplay

TIMER OFFdisplay

Fanspeeddisplay

MODE key

Used to select an automatic

or fixed air supplying direction.

When unit is started for the first time, clock should be adjusted as follows:

1. Press "CLOCK" key, "AM" or "PM" flashes at the clock display area.

2. Press the HOUR " "or " " key to set correct time. Each press will increase or decrease the time by 1 min.

If the key is kept depressed, time will change quickly.

3. After time setting is confirmed, press "SET" key, "AM" or "PM" stop flashing, while clock starts working.

Clock Set

L L M L M H L M H

AUTO

TIMER ON

TIMER OFF LOW MIN HIGH

AUTO

ROOM TEMP

SET TEMP

TIMER

SET

CLOCK

TIME SLEEP TEMP

SWING

FAN

SPEED MODE

Important Points of Safety

The following four important points of safety and suggestions should be paid great attention:

Warning: Misuse may cause fatal result such as death or serious injury etc.

Attention: Misuse may cause human injury or damage of machine, in some case

fatal results.

: Content marked with this ìforbiddenî sign should be absolutely forbid-

den, otherwise may cause damage of machine and human injury of the

user.

: Content marked with this ìcompulsoryî sign should be executed comp-

ulsively, otherwise may cause damage of machine and human injury of

the user.

Comply with the following important points of safety.

Put these important points of attention and suggestions nearby and convenient for reference in need.

Hand over this instruction manual to new user if you resell this machine.

Warning

Warning for installation

l Entrusted Installation

Installation of the machine should

be entrusted to certified person of

after service. Unauthorized install-

ation may cause water leakage,

electric shock or fire hazard for

improper operation.

l To prevent leakage of refrigerant,

let certified person of after service

do it.

Leakage of refrigerant over certain

consistence may result in shortage

of oxygen. Enough precautions

MUST be done to avoid oxygen

shortage in case of refrigerant lea-

king if the room where the air-

conditioner is installed is small.

l The power supply must be fitted with

earth line to ensure valid earthing of

the air-conditioner. No or incomplete

earthing connection may cause the

risk of electric shock.

l Test run

After indoor units are installed,all

cassettes hinded models should be

tested.when the units are confirmed

to be normal,other fitments can be

installed. !

Important Points of Safety

Warning

l Avoid your body being blown

directly by cold wind for long

period, otherwise your health

may be affected.

l Donít extend your fingers or

any other article into the inlet

or outlet during operation of

the machine for touching re-

volving fans may cause human

injury or damage of machine.

l If something abnormal (e.g.: burnt

smell etc.) occurs, stop running the

machine, shut down the manual

power switch and contact after

service. Continuous operation in

disorder may cause fire hazard or

electric shock etc.

Warning for use Warning for move and repair

l When you have to disassemble

and reinstall the machine, entrust

it to after service. Improper inst-

allation may cause fire hazard,

electric shock or damage of ma-

chine.

l Unauthorized alteration or repair

work is strictly forbidden. Impr-

oper alteration or maintenance

may cause fire hazard, electric

shock or water leakage. Repair

work should be entrusted to cert-

ified person of after service.

Attention

Attention points for installation

l Ensure the drainage hose work

normally during installation.

Improper installation of drainage

can cause water leakage and

damp articles.

l DO NOT install the machine in

place where flammable gas

releases easily to avoid fire

hazard.

l Ensure electric leakage breaker

being installed. Electric leakage

breaker MUST be installed,

otherwise electric shock may be

caused.

l If the power supply cord is

damaged, call a certified

electrician of the manufacturer

or other maintenance department

to replace it.

Important Points of Safety

Attention

Attention points for use

* Ensure ventilation of the room

if the machine is used with

burning facilities. Deficient

ventilation can cause oxygen

shortage.

* Check whether installation

bench of the machine is

damaged after a long period

of use. Machine on damaged

bench may fall down and cause

human injury or other damage.

* In place where winds produced

by the machine can reach, donít

lay any animals or plants which

may be hurt otherwise.

* Donít put vases containing water

or other else on the unit assembly.

Otherwise, the machine may be

immersed internally and result in

bad electric insulation causing

electric shock.

* The is machine CANNOT be

used for the purpose of prese-

rving food, animals, plants,

precision instruments and

artwork etc., which may be

destroyed otherwise.

* DONíT replace fuse with ma-

terial other than fuse of proper

capacity. Replacing fuse with

metal wire or copper etc. can

cause fire hazard or other faults.

* DONíT lay any burning facilities

in place where winds produced by

the machine can reach. Incomplete

combustion of burning facility may

be caused otherwise.

* DONíT clean the machine with

water. Electric shock may occur

otherwise.

* DONíT put flammable spray

articles nearby or spray them to

the machine. Fire hazard may

occur otherwise.

* DONíT operate switch with wet

hand. Electric shock may occur

otherwise.

* Stop operation and shut down

manual power switch before

cleaning and maintenance.

* The power supply MUST be of

rated voltage and connected with

special electrical supply circuit.

AUTO, FAN operation

Operating instructions

Unit start

Press the "ON/OFF" key to turn on the unit.

TheLCDontheremotecontrollerdisplaystheprevious

operatingconditions(excludingprevioustimer,sleepand

louver conditions).

Theremotecontrolleroperationindicatorturnson.

Select operation mode

Pressthe"MODE"keytoaltertheworkingmode.Each

pressingwillchangetheoperationmodeinthefollowing

sequence:

AUTO COOL DRY FAN HEAT

Theairconditionerwilloperatewiththedisplayedrunning

mode.

Select AUTO or FAN operation mode,

thedisplaywillstopat" "AUTO,or" "FAN

LOW MID HIGH AUTO

Fan speed adjustment

Pressthe"FANSPEED"keytochangethefanspeed.Every

pressingwillchangethefanspeedinthefollowingsequence:

Theairconditionerwillrunatthedisplayedfanspeed.

Note:AUTOfanspeedisunavailableinFANoperationmode.

L L M L M H L M H

AUTO

Unit stop

The remote controller LCD displays only the clock and room

temperature.

Press the "ON/OFF" key to turn off the unit.

The remote controller possesses a memory function which could remember the setting conditions

in each operation mode. Upon next time of operation, you need only to select the operation mode

and the air conditioner will automatically operate with the previous settings without further setting.

Hints:

LOW MIN HIGH

AUTO

ROOM TEMP

TIMER

SET

CLOCK

TIME SLEEP TEMP

SWING

FAN

SPEED MODE

(Except for the timer, sleep and louver conditions).

Operating instructions COOL, DRY, HEAT operation

Recommended operation mode:

Please use cooling mode in summer

and heating mode in winter.

Please use DRY mode in spring or

autumn humid climate.

Unit start

Pressthe"ON/OFF"keytoturnontheunit.

TheLCDontheremotecontrollerdisplaystheprev-

iousoperatingconditions(excludingprevioustimer,

sleep and louver conditions).

Theremotecontrolleroperationindicatorturnson.

Select operation mode

Pressthe"MODE"keytoaltertheworkingmode.

Eachpressingwillchangetheoperationmodeinthe

following sequence:

AUTO COOL DRY FAN HEAT

Theairconditionerwilloperatewiththedisplayed

running mode.

Selectyourdesiredoperationmodeandgetthedisplay

stop at the corresponding indication.

Select a desired temperature

Press the TEMP setting keys.

Every time pressing the " " key, the temperature

setting will increase by 1oC.

Every time pressing the " " key, the temperature

setting will decrease by 1oC.

Set a suitable temperature value.

Fan speed selection

PresstheFAN"SPEED"keytochangethefanspeed.

Eachpresswillchangethefanspeedinthefollowing

sequence:

LOW MID HIGH AUTO

L L M L M H L M H

AUTO

The air conditioner will run at the fan speed displayed

on the LCD.

Run in COOL mode when

room temp. is higher than

temp. setting Ultra-low air supply

Temp.setting + 2oC

Temp. setting

Run in mild DRY mode when

the room temp. reaches temp.

setting +2oC

In HEAT operation, after unit is turned on,the air conditioner will send out hot air after a short while in order to

prevent cold draft.

In DRY operation,when the room temperature decreases to 2oCabove temperature setting,the air conditioner

will run at low fan speed regardless of the fan speed setting.

Unit stop

Press "ON/OFF"key to turn off the unit.

LOW

AUTO

SETTEMP

TIMER

SET

CLOCK

TIME SLEEP TEMP

SWING

FAN

SPEED MODE

Hints:

The remote controller could remember the setting conditions in each operation mode. Upon next

time turning on the unit,you need only to press the "ON/OFF"key and the air conditioner will

automatically operate with the previous settings. (Except for the timer, sleep and louver conditions).

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Haier Climatiseur

Haier

Haier Room Air Conditioner Manuel utilisateur

Haier

Haier HW-18CE03 Manuel utilisateur

Haier

Haier HSU-07RS03/R2, HSU-09RS03/R2, Manuel utilisateur

Haier

Haier HW-24CE03 Manuel utilisateur

Haier

Haier AS052AZMAA Manuel utilisateur

Haier

Haier ThermoCool HW-09LMA03 Manuel utilisateur

Haier

Haier AS072AZMBA Manuel utilisateur

Haier

Haier Super Match Series Manuel utilisateur

Haier

Haier HSU-18HVB03 Manuel utilisateur

Haier

Haier HFU-09HA03/R(DB) Guide d'installation et d'utilisation

Haier

Haier HSU-22H03/R2(DB) Manuel utilisateur

Haier

Haier AS25XCAHRA Manuel utilisateur

Haier

Haier HSU-09H13 Manuel utilisateur

Haier

Haier AS142AHAIA Manuel utilisateur

Haier

Haier HM-07C03 Manuel utilisateur

Haier

Haier HSU-07HR03 Manuel utilisateur

Haier

Haier AD25S2SS1FA Instructions d'installation et d'utilisation

Haier

Haier 1U26JACFRA Manuel utilisateur

Haier

Haier HWR10XC6 - annexe 1 Manuel utilisateur

Haier

Haier ESAM055-C Manuel utilisateur

Haier

Haier AC282AFEAA Fiche technique

Haier

Haier ESA3259 Manuel utilisateur

Haier

Haier 2U50S2SM1FA-3 Manuel utilisateur

Haier

Haier HSU-12LEA13-M Manuel utilisateur

Manuels Climatiseur populaires d'autres marques

Spheros

Spheros CC 355 Manuel utilisateur

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manuel utilisateur

Panasonic

Panasonic CS-E12HKEW Manuel utilisateur

nedis

nedis ACMB1WT7 Manuel utilisateur

Samsung

Samsung AR KV Series Mode d’emploi

Daikin

Daikin FCFV50A Manuel utilisateur

Fujitsu

Fujitsu Inverter ASBA30JFC Manuel utilisateur

Toshiba

Toshiba RAS-M10SMUV-E Manuel utilisateur

Daikin

Daikin FXLQ20MAVE Manuel utilisateur

Hitachi

Hitachi RAS-E24CAK Manuel utilisateur

CIAT

CIAT Magister 2 Series Mode d’emploi

Bestron

Bestron AAC6000 Manuel utilisateur

Hisense

Hisense 7K Manuel technique

Frigidaire

Frigidaire FFRE0533S1E0 Manuel utilisateur

Samsung

Samsung AS09HM3N Manuel utilisateur

Frigidaire

Frigidaire CRA073PU11 Manuel du propriétaire

Soleus Air

Soleus Air GB-PAC-08E4 Manuel utilisateur

McQuay

McQuay MCK020A Manuel utilisateur
