DOC302.53.00755

Instruction Sheet

CDC401-01 or CDC401-03 Probe

Safety

To ensure that the protection provided by this equipment is not impaired, do not use or install

this equipment in any manner other than that specified in this document.

Overview

Figure 1shows the CDC401-01 or CDC401-03 Probe, a 4-pole conductivity probe, equipped

with either a 1- or 3-meter cable. The probe is designed for fast, accurate measurement of

conductivity, salinity, resistivity, or total dissolved solids (TDS) in wastewater, drinking water,

and general applications.

Each electrode is supplied with color-code clips for easy identification. There are two each of

five colors (black, yellow, light green, light blue, and magenta), one for the electrode and one

for the cable connector.

This symbol, if noted on the instrument, references the instruction manual for operation and/or safety information.

Electrical equipment marked with this symbol may not be disposed of in European public disposal systems after 12

August of 2005. In conformity with European local and national regulations (EU Directive 2002/96/EC), European

electrical equipment users must now return old or end-of life equipment to the Producer for disposal at no charge to

the user.

Note: For return for recycling, please contact the equipment producer or supplier for instructions on how to return

end-of-life equipment, producer-supplied electrical accessories, and all auxiliary items for proper disposal.

Figure 1CDC401-01 or CDC401-03 Probe

1Sensor Array, including Temperature Sensor and

4-pole Conductivity Sensor

31- or 3-meter Cable

2Color-coded clip locations

HACH COMPANY

WORLD HEADQUARTERS

Telephone: (970) 669-3050

FAX: (970) 669-2932

FOR TECHNICAL ASSISTANCE, PRICE INFORMATION AND ORDERING:

Call 800-227-4224

Contact the HACH office or distributor serving you.

www.hach.com [email protected]

In the U.S.A. –

Outside the U.S.A. –

On the Worldwide Web – ; E-mail –

toll-free

Assembly

1. Attach a pair of color-code clips to the electrode and cable connector (Figure 1, item 2).

2. Rinse probe with deionized water prior to use.

Calibration

For calibration steps, refer to the HQ Portable Meters User Manual. The IntelliCAL™ probes

store the current calibration and calibration history in the probe memory. It is not necessary to

recalibrate when moving a calibrated electrode from one meter to another.

Maintenance

General Maintenance

•Between samples, wipe the probe with a clean towel.

•If the connection to the meter is poor, readings may be unstable. To ensure accurate

readings, check the connection to the meter.

Storage

•Between uses, store the probe dry in ambient conditions.

Specifications

Specifications are subject to change without notice.

Conductivity Range 0.01 µS/cm to 200.0 mS/cm

Conductivity Resolution

0.0–19.99 µS/cm: 0.01 µS/cm

20.0–199.9 µS/cm: 0.1 µS/cm

200.0–1999.0 µS/cm: 1.0 µS/cm

2.0–19.99 mS/cm: 0.01 mS/cm

20.0–200.0 mS/cm: 0.1 mS/cm

Conductivity Accuracy ± 0.5% of Reading

TDS Range 0 to 50,000 mg/L as NaCl

TDS Accuracy ± 0.5% of Reading

TDS Resolution

0.0–199.9 mg/L: 0.1 mg/L

200.0–1999.0 mg/L: 1.0 mg/L

2.0–19.99 g/L: 0.01 g/L

20.0–50.0 g/L: 0.1 g/L

Salinity Range 0 to 42 ppt (‰)

Salinity Accuracy ± 0.1 ppt (‰)

Salinity Resolution 0.01 ppt (‰)

Temperature Range –10.0 to 110.0 ºC

Temperature Accuracy ± 0.3 ºC

Warranty Sensor is covered by a one-year warranty.
