GUILCOR AR003825 Manuel utilisateur
www.guilcor.com
Web Sensor AR003825
Web Sensor AR004617
Web Sensor AR005351
USER GUIDE
2
©Copyright:
Is prohibited to copy and make any changes in this manual, without explicit agreement of
company Guilcor All rights reserved.
Manufacturer is not responsible for damages caused by using the device in conflict with
this manual. To damages caused by using the device in conflict with this manual
cannot be provide free repairs during the warranty period.
Revision history
This manual describes devices with latest firmware version according the table below. Older
version of manual can be obtained from a technical support.
Document version
Date of issue
Firmware version
Note
IE-SNC-P85x1-09
2011-01-27
4-5-1-x
Latest revision of manual for an old generation
of firmware for P85xx devices.
IE-SNC-P85x1-13
2014-02-07
4-5-5-x
4-5-6-0
Initial revision of manual for new generation of
P85xx firmware.
IE-SNC-P85x1-14
2015-06-30
4-5-7-0
IE-SNC-P85x1-16
2017-01-11
4-5-8-0
IE-SNC-P85x1-17
2017-10-26
4-5-8-1
3
Table of contents
Introduction........................................................................................................................................................4
General safety rules .....................................................................................................................................4
Device description and important notices...............................................................................................5
Getting started....................................................................................................................................................6
What is needed for operation ....................................................................................................................6
Mounting the device....................................................................................................................................6
Device settings .............................................................................................................................................8
Checking functions....................................................................................................................................10
Device setup .....................................................................................................................................................11
Setup using web interface.........................................................................................................................11
Setup using TSensor software .................................................................................................................18
Factory defaults..........................................................................................................................................19
Communication protocols .............................................................................................................................21
Website........................................................................................................................................................21
SMTP –sending e-mails...........................................................................................................................21
SNMP ..........................................................................................................................................................22
Modbus TCP ..............................................................................................................................................23
SOAP...........................................................................................................................................................25
Syslog...........................................................................................................................................................26
SNTP ...........................................................................................................................................................26
Software development kit.........................................................................................................................26
Troubleshooting...............................................................................................................................................27
I forgot the device IP address..................................................................................................................27
I cannot connect to the device ................................................................................................................27
Error or n/a is displayed instead the measured value .........................................................................28
I forgot the password for setup...............................................................................................................28
Factory defaults..........................................................................................................................................29
Technical specifications..................................................................................................................................30
Dimensions.................................................................................................................................................30
Basic parameters ........................................................................................................................................31
Operating terms .........................................................................................................................................33
End of operation .......................................................................................................................................34
Technical support and service .................................................................................................................34
Preventive maintenance............................................................................................................................34
Optional accessories........................................................................................................................................35
4
Introduction
This chapter provides basic information about device. Before starting please read
this manual carefully.
Thermometer Web Sensor AR003825 or Web Sensor AR004617 and Web Sensor
AR005351 are used to measure temperature or relative humidity. Temperature can be
displayed in °C or °F. Relative humidity have unit %RH. Communication with the device is
realized via Ethernet network.
Thermometer Web Sensor AR003825 has compact design and measures the temperature in
place of installation. Web Sensor AR004617 is designed to connect one probe. To Web
Sensor AR005351 is possible connect up to four probes. Temperature or humidity
probes are available as optional accessories.
General safety rules
The following summary is used to reduce the risk of injury or damage the device.
To prevent injury, please follow instructions in this manual.
The device can be services only by a qualified person. The device contains no
serviceable parts inside.
Don’t use the device, if it doesn’t work correctly. If you think, that the device is
not working correctly, let check it by qualified service person.
It’s forbidden to use the device without the cover. Inside the device can be a dangerous
voltage and may be risk of electric shock.
Use only the appropriate power supply adapter according to manufacturer specifications and
approved according to relevant standards. Make sure, that the adapter does not have
damaged cables or covers.
Connect the device only to network parts approved according to relevant standards.
Connect and disconnect the device properly. Don’t connect or disconnect Ethernet cable or
probes, if the device is powered.
The device may be installed only in prescribed areas. Never expose the device to higher or
lower temperatures than is allowed. The device has not improved resistance to moisture.
Protect it from dripping or splashing water and do not use at areas with condensation.
Don’t use device in potentially explosive environments.
Chapter
1
5
Don’t stress the device mechanically.
Device description and important notices
This chapter contains information about basic features. Also there are important
notices concerning to functional safety.
Values from the device can be read using an Ethernet connection. The following formats are
supported:
Web pages
Current values in XML and JSON format
Modbus TCP protocol
SNMPv1 protocol
SOAP protocol
The device can also be used to check measured values and if the limit is exceeded, device
sends warning messages. Possible ways to sending warning messages:
Sending e-mails up to 3 e-mail addresses
Sending SNMP traps up to 3 configurable IP addresses
Displaying the alarm status on web page
Sending messages to Syslog server
The device setup can be made by the TSensor software or web interface. TSensor software
can be free downloaded from the manufacturer’s website. Latest firmware can be obtained
from the technical support. Do not upload to your device firmware which is not designed
for it. Unsupported firmware can damage your device.
Device does not support powering over Ethernet cable (PoE). PoE splitter must be used.
Compatible PoE splitter can be purchased as optional accessories. Splitter must have 5V
output with approximately 1W.
Reliability of warning messages delivering (e-mail, trap, syslog), depends on
actual availability of necessary network services. The device should not be used
for critical applications, where malfunction could cause to injury or loss of
human life. For highly reliable systems, redundancy is essential. For more
information please see standard IEC 61508 and IEC 61511.
Never connect the device directly to the Internet. If it is necessary connect the
device to the Internet, properly configured firewall must be used. Firewall can
be partially replaced with the NAT.
6
Getting started
Here you can find information necessary to put newly purchased equipment to
operation. This procedure is only informative.
What is needed for operation
To install the unit you need to the following equipment. Before installation check if it’s
available.
•Web Sensor AR003825 or Web Sensor AR004617, P8541
•power supply adapter 5V/250mA (or compatible PoE splitter)
•RJ45 LAN connection with appropriate cable
•free IP address in your network
•for Web Sensor AR004617 one probe. For Web Sensor AR005351 up to 4
temperatures probes type DSTR162/C, DSTGL40/C, DSTG8/C or relative
humidity probe DSRH
Mounting the device
check if the equipment from previous chapter are available
install the latest version of TSensor software. This software is used to all device
settings. TSensor software can be free downloaded from the manufacturer’s
website. Software can be also supplied on CD. Device configuration can be
made using web interface. For web configuration is not TSesnor software
necessary.
contact your network administrator to obtain following information for the
connection to the network:
IP address:
_____._____._____._____
Gateway:
_____._____._____._____
DNS server IP:
Netmask:
_____._____._____._____
_____._____._____._____
Chapter
2
7
•check if there is no IP address conflict when you connect the device into
network for the first time. The device has from factory set the IP address to
192.168.1.213. This address must be changed according to information from the
previous step. When you installing several new devices, connect them to the
network one after another.
•connect probes to Web Sensor AR004617 or Web Sensor P8541
•connect the Ethernet connector
•connect the power adapter 5V/250mA
•LEDs on LAN connector should blink after connecting the power
Web Sensor AR003825 connection:
Web Sensor AR004617 connection:
8
Web Sensor AR005351 connection:
Connect via PoE splitter:
Device settings
run configuration software TSensor on your PC
switch to an Ethernet communication interface
press button Find device...
9
the window shows all available devices on your network
click to Change IP address to set new address according to network
administrator instructions. If your device is not listed, then click Help! My
device wasn’t found! Then follow the instructions. MAC address is on
product label. The device is factory set to IP 192.168.1.213.
•gateway may not be entered if you want to use the device only in local network.
If you set the same IP address which is already used, the device will not work
correctly and there will be collisions on the network. If the device detects a
collision of IP address then reboot is performed automatically.
•after changing IP address device is restarted and new IP address is assigned.
Restart of the device takes about 10 seconds.
•connect to device using TSensor software and check the measured values. If
Web Sensor AR004617 or Web Sensor AR005351 values are not displayed, it’s
necessary to find probes using button Search probes (Find probes).
•set the other parameters (alarm limits, SMTP server, etc.). Settings are saved
after click on button Save changes.
10
Checking functions
The last step is to check measured values on the device website. Enter the device IP address
into address bar of the web browser. If the default IP address was not changed, then insert
http://192.168.1.213.
Displayed web page lists actual measured values. If the web pages are disabled, you can see
text Access denied. If the measured value exceeds the measurement range or probe is not
correctly installed, then is shown Error message. If the channel is switched off, the web site
displayed n/a instead of the value.
