GTE KMG-LITE Manuel utilisateur
KMG-Lite
Hand-held instrument for measuring dynamic forces at closing
edges of power-operated doors and gates
Operating manual
2
At a glance
①Open the cap
②insert 3 x AA 1,5V batteries
③Start the device
①
②
③
3
Table of Contents
1 About this manual ............................................................... 4
2 Safety information ............................................................... 6
3 Intended use ...................................................................... 8
4 Product description.............................................................. 9
5 Commissioning................................................................. 11
6 Measuring....................................................................... 14
7 Warning- and error signals ................................................. 21
8 Using ‚KMG-Lite App‘ ........................................................ 25
9 Care and maintenance ...................................................... 48
10 Calibration ...................................................................... 51
11 Accessories...................................................................... 53
12 Technical data ................................................................. 54
4
1 About this manual
Read the documentation carefully and familiarize yourself with the operation
of the device before using it. Keep this document handy for future reference.
This manual describes how to use the force gauge KMG-Lite including the
variant KMG-Lite-BT.
The KMG-Lite-BT is equipped with a wireless module and therefore deploya-
ble with the free KMG-Lite App. Contents that are not related to the KMG-Li-
te app and the wireless module also apply to the KMG-Lite-BT.
KMG-Lite can be retrofitted with a wireless module.
5
Identification
Display Meaning Note
Note Offers helpful tips and information
Objective Denotes the objectives that is to be achie-
ved via the steps descripted
Step Carry out steps
Cross reference Refers to more extensive or detail
Display Shows the display output
6
2 Safety information
This chapter gives general rules which must be followed and observed if the
product is to be handled safely.
ÂProduct safety/preserving warranty claims
►Operate the instrument only within the parameters specified in the chap-
ter “Technical Data”. (Chapter. 12, S. 54)
►Always use the instrument properly and for its intended purpose.
►Do not use force.
►Do not open the instrument except for changing the batteries as instruc-
ted in chapters 5 and 9.
►The instrument must be sent for annual calibration. (Kap. 10, S. 51)
►When not used, keep the gauge inside its transport case und protect it
from humidity and mechanical stress.
7
ÂEnsure correct disposal
►Take used batteries to the designated collection points.
►Send the product to GTE Industrieelektronik GmbH at the end of its
service life.
LWe will take care of its proper and ecological disposal..
8
3 Intended Use
KMG-Lite and KMG-Lite-BT are compact handheld measurement instruments
for determining dynamic closing forces of power-operated doors and gates,
according to EN 12453, EN 16005 and ASR A1.7.
►Only use the product for those applications which it was designed for.
LPlease consult „Technical Data“ for the admissible maximum force.
(S.54)
9
Point of force application
Display
Battery plug
Control button
4 Product description
This chapter describes the structure of the product and its display and control
elements.
10
Numeric measurement result
Indicator
Indicator
Indicator
