Grundig VCH 9530 Manuel utilisateur
VACUUM CLEANER
VCH 9530
EN
3
___________________________________________
A
B
C
D
E
F
G
4
ENGLISH
SAFETY ___________________________________
Please read this instruction man-
ual thoroughly prior to using this
appliance! Follow all safety in-
structions in order to avoid dam-
ages due to improper use!
Keep the instruction manual for
future reference. Should this ap-
pliance be given to a third party,
then this instruction manual must
also be handed over.
7 Always keep hair, clothing and
any other utensils away from
the appliance during operation
in order to prevent injury and
damages.
7 The appliance is designed for
domestic use only. Warranty
will be voided if the appliance is
used for industrial or commercial
purposes.
7 Observe these instructions in
order to prevent damage to the
appliance or danger arising
from improper use.
7 Do not use on wet surfaces and
do not attempt to use on wet
objects.
7 Do not use the appliance in wet
surroundings.
7 Do not use the appliance with
wet hands.
7 This appliance is designed for
vacuuming dirt and dust particles.
Do not attempt to use it on large
objects which could block and
damage the appliance.
7 Do not use to clean cigarette
stubs, ash from a fireplace or
matches. This could cause a fire.
7 This appliance is not designed
for cleaning people or animals.
7 Do not insert any foreign objects
into the suction intake. Always
keep the suction intake free of
all objects.
7 Never operate the appliance
without the filter.
7 Clean the filter when necessary.
7 Only use original GRUNDIG
accessories when replacing
parts.
7 Check if the mains voltage on
the rating label corresponds to
your local mains supply.
7 Always pull out the power cord
after the charging process,
before cleaning or carrying
out any maintenance on the
appliance or the charging unit.
7 Avoid using extension cables
or multipoint connectors. Plug
the appliance directly in a wall
socket if possible.
5
ENGLISH
SAFETY ___________________________________
7 For additional protection, this
appliance should be connected
to a household residual current
device with a maximum rating of
30 mA. Consult your electrician
for advice.
7 Do not disconnect the plug by
pulling on the cable.
7 Never use the appliance if it
or the power cord is visibly
damaged. This also applies if
the appliance has accidentally
become wet. Please contact a
service centre in this case.
7 Our GRUNDIG Household
Appliances meet all applicable
safety standards; thus if the
appliance or the power cord is
damaged, it must be replaced
by the dealer, a service centre
or a similarly qualified and
authorised service person to
avoid any danger arising. Faulty
or unqualified repair work may
cause danger and risk to the
user.
7 Keep the appliance away from
children.
7 This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge if
they have been given supervision
or instruction concerning use
of the appliance in a safe way
and understand the hazards
involved. Children shall not play
with the appliance. Cleaning
and user maintenance shall not
be made by children without
supervision.
7 Do not dismantle the appliance
under any circumstances. No
warranty claims are accepted
for damage resulting from
improper handling.
7 Do not use the appliance if
the air duct and the ventilation
slot are blocked. Always keep
the air duct and ventilation slot
free of dirt, hair and any other
elements which could obstruct or
block the air flow.
7 Only use the power cord
provided.
6
ENGLISH
OVERVIEW ________________________________
Dear Customer,
Congratulations on the purchase of your new
GRUNDIG rechargeable stick vacuum cleaner
VCH 9530.
Please read the following user notes carefully to
ensure you can enjoy your quality GRUNDIG
product for many years to come.
A responsible approach!
GRUNDIG focuses on
contractually agreed social
working conditions with fair wages
for both internal employees and
suppliers, as well as on the efficient
use of raw materials with continual
waste reduction of several tonnes of plastic each
year – and availability of at least 5 years for all
accessories.
For a future worth living.
For a good reason. Grundig.
HEPA filter
HEPA stands for High Efficiency Particulate Air.
HEPA filters are particulate air filters, which filter
more than 99.9% of all dust particles larger than
0.1 to 0.3 micrometres out of the air. Viruses,
respirable dusts, mite eggs and mite excrement,
pollen, smoke particles, asbestos, bacteria,
diverse toxic dusts and aerosols are removed
from the air.
Controls and parts
See the figure on Page 3.
A Handle
B On/Off button
C Handle folding button
D Body
E Power indicator LEDs
F Brush removal button
G Brush
7
ENGLISH
PREPARATION _____________________________
Installing the parts
Lift the handle A and bring it to the vertical
position till it clicks.
Place the body D in a way to match with the slot
on the brush. Attach the brush till it clicks.
Press brush removal button to remove the body D
from the brush.
Charging the appliance
Note
7 For the first 3 uses, charge the appliance for
12 hours.
7 For the following uses, you can charge the ap-
pliance for 5 hours.
7 When the vacuum cleaner is in power shortage,
red light on the indicator board will be flashing.
Appliance needs to be charged promptly.
8
ENGLISH
PREPARATION _____________________________
OPERATION _______________________________
1 Attach the thin tip of the charging adapter to
the charging port on the body D and then
plug the charging adapter in the socket.
Charging
port
– Charge indicator LEDs E flash white.
– When the charge indicator LED E light
white constantly, charging is completed.
2 Remove the thin tip of the charging adapter
and unplug it from the socket.
Switching on and off your
appliance
Press On/Off button B to switch on and off the
appliance.
Note
7 During operation the LEDs E on the body light
up white, LED at the brush lights up blue.
Warning:
7 While charging, the appliance will not start to
operate even if you press On/Off button B.
7 When a big object is trapped by the brush, the
appliance is switched off automatically for your
safety.
9
ENGLISH
CLEANING AND MAINTENANCE _____________
Cleaning the dust container
Notes
7 It is recommended to clean the dust container
after every use.
Warning
7 Do not clean the appliance while it is running.
1 Press the dust container removal button to
remove the dust container.
2 Remove the filter from the dust container.
3 Empty the full dust container into a bin.
4 Separate HEPA filter, sponge filter and cyclone
element.
Sponge
filter
5 Clean the cyclonic filter, HEPA, sponge filter
and dust container under the running water.
6 Clean the body D of the appliance with a soft
damp cloth.
7 After all parts are dried, place the HEPA and
sponge filter into the cyclonic filter.
8 Place the cyclonic filter into the dust container.
9 Place the dust container into the body of the
appliance.
Cleaning the brush
1 Open the cover by using a screwdriver.
10
ENGLISH
2 Remove the cover, pull out the brush and clean
it.
Cover
Brush
roll
3 After cleaning and drying the brush roll, re-
attach it and secure the cover again with a
screwdriver.
CLEANING AND MAINTENANCE _____________
Storage
Store the appliance in a vertical position or with
its handle folded.
1 If you want to store the appliance with its
handle folded, press the handle folding button
C and fold the handle downwards.
INFORMATION ____________________________
Problem Possible reason/cause Solution
Appliance does not
work.
The battery may be flat. Charge it.
Suction power is get-
ting weaker.
The dust container may be full. Empty the dust container.
HEPA filter may be blocked. Clean or replace HEPA filter.
Air vent or brush may be blocked. Clean the brush.
The appliance is not
charging.
The power cable may not be
plugged in.
Plug in the power cord to the socket.
You may have forgotten to attach the
thin tip of the charging adapter to the
charging port.
Attach the thin tip of the charging
adapter to the charging port.
The appliance stays
in operation for a
very short time after
being charged.
The appliance may not be charged
enough.
Charge the appliance for 5 hours.
Service life of the battery may be
reduced.
Contact your GRUNDIG authorised
service.
Troubleshooting
