ENGLISH

Detailed instruction manual

You can find the detailed

instructions at www.grundig.

de under “Service”.

2 EU directives

3 About your TV set

3 Intended use

4 Safety

5 Environmental information

6 Packing contents

7 Setting up or hanging

8 Connections

9 Control elements

10 Inserting batteries into the remote

control

10 Setting up the TV set

10 Adding new TV stations at a later

point

10 Sorting TV stations in the channel list

11 Remote control

12 Favourites lists

12 Zapping function

12 HbbTV

13 Recording from digital TV stations

13 Watching TV with time shift

14 Media player

14 SMART inter@ctive TV 4.0+

14 Web browser

15 Product data sheet

16 Licence

16 Network interfaces

16 Cleaning the TV set

16 Abbreviations

Table of Contents

EU directives

This product complies with the

following EU directives:

2014 / 53 / EU 2014/30/

EC, 2014/35/EC, 2009/125/ EC,

2017/1369/EU and 2011/65/EU.

TV’s wireless system can only be used in

the countries below.

AT, BE, BG, CH, CY, CZ, DE, DK,

EE, ES, FI, FR, GB, GR, HU, IE,

IS, IT, LI, LT, LU, LV, MT, NL, NO,

PL, PT, RO, SE, SI, SK, HR, TR.

The use the 5150 -5350 MHz band is

restricted to indoor use only. (For Wi-Fi/

Bluetooth built-in model or Wi-Fi Built-in

model).

This device can also be operated in the

countries outside Europe.

ENGLISH

About your TV set

7 With your TV set, you can receive and

watch digital TV programmes over DVB-

S, DVB-T and DVB-C, along with ana-

logue TV.

7 Many features of the TV set require an In-

ternet connection. The TV set is equipped

with WLAN and a LAN port.

The TV set can record TV programmes.

For this feature you need a USB storage

device, such as an external hard drive

(not included). Recorded TV programmes

can only be played on the same TV set.

After the TV st is repaired, it is possible

that recorded programmes may no longer

be able to be played back.

7 The twin-triple tuner enables PIP function

so you can view one TV programme in

the main picture and another in an inset

picture.

You can now also view one TV pro-

gramme while recording another pro-

gramme.

7 You can connect various data media, for

example, an external hard drive, a USB

memory stick or a digital camera to the

USB sockets. Using the file browser, you

can then select and play the file formats

you want (for example, MP4, MP3 or

JPEG data).

7 With the Time Shift function, you can eas-

ily stop and resume a programme with

the remote control in a fast and simple

way. Programme is recorded to the exter-

nal data medium.

Intended use

7 The TV set is designed for use in dry

rooms.

7 Use the TV set with the supplied stand or

a suitable VESA bracket.

7 The TV set is primarily intended for the

playback of TV programmes, streaming

content and audio/video material from

external devices. Any other use is strictly

prohibited.

It is not intended as an information

display or for predominant use as a

computer monitor. If a still image or a

non-full-format image is displayed for

an extended period, visible traces may

remain on the screen for some time.

This is not a defect that can be used as

the basis for a warranty claim.

ENGLISH

Safety

WARNING

Risk of electrical accident

7 Do not open the TV set. Safety risk may

arise and also the guarantee of the

product can be void if the television set is

opened.

7 The TV set can only be operated with the

power cable or the AC/DC adapter sup-

plied with the product.

7 Do not operate the TV set with a dam-

aged power cord/AC/DC adaptor (if

supplied).

7 If the plug on the TV set has an earthing

contact, only insert the plug into a socket

with an earthing contact.

7 Plug the TV set into the mains socket only

after you have connected the external

devices and the antenna.

7 Protect the TV set from moisture. Do not

place any vessels filled with water (such

as vases) on the TV.

Fire hazard

7 To prevent the spread of fire,

keep candles or other open

flames away from this product

at all times.

7 Do not cover the ventilation slots on the

TV set.

7 Always unplug the power plug and an-

tenna plug during a thunderstorm.

7 Keep candles or other open flames away

from the TV set.

7 Do not expose the batteries to extreme

heat such as sunshine, fire or the like.

7 Only use batteries of the same type

(brand, size, properties). Do not use used

and new batteries together.

WARNING

Injuries caused by falling TV set

Never place the TV set on an unstable sur-

face. The TV set may fall, causing serious

injury, possibly leading to death in isolated

cases.

Observe the following precautions:

7 Only use the manufacturer’s recommend-

ed cabinets or stands.

7 Only use furniture that can safely support

the TV set.

7 Make sure that the TV set does not

protrude beyond the dimensions of the

furniture on which it is resting.

7 Do not place the TV set on tall furniture

(such as kitchen cabinets, bookshelves)

without securely anchoring the furniture

and TV set.

7 Do not place the TV set on fabric or other

materials located between the TV set and

furniture.

7 Instruct children that there is danger as-

sociated with climbing on furniture when

the TV set is to be reached.

NOTICE

Shortened service life due to high

operating temperature

7 Do not place the TV set next to heating

units or in direct sunlight.

7 To ensure adequate ventilation, maintain

clearance of at least 10 cm around the

TV set.

Discolouration of furniture due to

rubber feet

7 Some furniture surfaces may discolour

when they come in contact with rubber.

To protect furniture, you can place a

sheet made of glass or plastic under the

stand. Do not use textile underlays or

mats such as doilies.

ENGLISH

Environmental information

7 Do not dispose of batteries in

the household waste. Used

batteries must be returned to

retail stores or public collection points.

You help to protect the environment in this

way.

7 Do not dispose of the product

along with normal household

waste at the end of its service

life. Take it to a recycling centre for

electrical and electronic equipment.

7 Be sure to dispose of packaging materi-

als for your product separately according

to the guidelines of local authorities so

that they can be recycled in an environ-

mentally safe manner.

If you are not using your TV set for a

while, turn it to standby mode. In standby

mode, the TV set uses very little energy

(≤ 0.5 W).

If you do not use the TV set for an ex-

tended period, turn it off with the power

switch or unplug the power cord from

the socket. If you turn off the device or

disconnect it from the power supply, the

switch-on timer and programmed record-

ings will not work.

7 Select a location for the TV set so that

no direct sunlight falls on the screen. This

allows a lower backlight to be selected,

which saves energy.

Electromagnetic noise

Devices connected to the product

(satellite receiver, DVD player, and etc.)

or signal emitting devices (router and

etc.) close to the product may cause

disturbance in the image and noise in the

sound.

Connection cables used on the product

must be shorter than 3 m.

If the product cannot perform its function

due to electrostatic discharge, the user

may need to switch off and then switch

on the product.

A shielded, HDMI-certified and ferrite

cable must be used with the product.

ENGLISH

Packing contents

Standart accessory

1. TV

2. Stand

3. Remote control

4. Batteries for remote controls

5. Screws and mounting instructions

for stand

6. Brief Instruction

Optional accessory

Easy-Use Remote Control

Batteries for Easy-Use remote controls

Cleaning cloth

VESA bracket screws

User

Manual

ENGLISH

Setting up or hanging

7 Select a location so that no direct sunlight

falls on the screen.

Setting up with stand

7 To mount the stand, refer to the installa-

tion instructions included.

7 Place the TV set on a hard, level surface.

Preparing for mounting on

the VESA bracket

You will need:

7 A pair of scissors,

7 A crosstip screwdriver.

Follow the installation instructions for the

VESA bracket.

1. Place the TV set in the film on a smooth

surface with the screen facing down.

2. Cut open the film on the back side us-

ing the scissors.

3. Connect the required cables to the con-

nectors on the TV set. See the “Connec-

tions” section in this manual.

4. Tie the cables so they do not hang

down onto the floor.

5. Screw the VESA bracket onto the TV set

and mount it according to its installation

instructions.

VESA

ENGLISH

Connections

Optic Out ANT-IN

5V max.50mA

SATELLITE

13/18V max.500mA

USB3 HDMI4

(ARC) (MAIN) (SUB)

HDMI3LAN

SERVICE

7 Optic Out: optical audio output

7 LAN: Network connection

7 USB 3: for data media or keyboard.

7 HDMI3: Input for digital audio and im-

age data.

7 HDMI4 (ARC): Input for digital audio

and video data with audio return chan-

nel.

7 SATELLITE:

MAIN: for satellite antenna. Suitable for

single-cable GSCR system.

SUB: for the second satellite signal

(DVB-S).

7 ANT IN: for antenna cable (terrestrial

antenna or cable connection).

7 U: Headphone jack or line output via

adapter.

7 SERVICE: Service only.

7 C I 1, CI2: for CA modules for receiving

encrypted stations.

7 USB 1: connect data media for record-

ing programmes, such as an external

hard disk.

7 USB 2: connect data media for record-

ing programmes, such as an external

hard disk.

7 HDMI1 (MHL): Connect input for digi-

tal audio and video data, mobile devices

with Mobile High-Definition Link here.

7 HDMI2: Input for digital audio and im-

age data.

ENGLISH

Control elements

Switching on the TV

Press or rock the multi-function switch.

Turning the TV to standby

1. Press the multi-function switch.

2. Rock until “Switch to standby” is

selected.

3. Press.

Adjusting the volume or

changing the station

1. Press the multi-function switch.

2. Rock to select the required function.

3. Press.

4. Rocking now performs the selected

function.

P+

P-

ENGLISH

Inserting batteries into the

remote control

1. Open the battery compartment.

2. Insert batteries as marked on the

bottom of the battery compartment

(2 × Micro/R03/AAA).

3. Close the battery compartment.

Setting up the TV set

1. Connect the cables.

2. Insert the power plug into the socket.

3. Switch on the power switch.

4. Switch on the TV set with on the

remote control.

5. Follow the setup wizard on the screen.

Adding new TV stations

at a later point

1. Press .

2. Select »Settings«.

3. Select »Source«.

4. Select »Automatic Channel Search«.

5. Select the antenna type.

6. The next procedure depends on the

selected antenna. Follow the instructions

on the screen.

Sorting TV stations in

the channel list

1. Press .

2. Press .

3. Choose the TV station you want to

move, and highlight it with .

4. Press .

5. Use the navigation keys to move the TV

station to the new position and confirm

with .

ENGLISH

Remote control

Cursor Control

Moves the cursor up and

down in the menus.

Moves the cursor left/right

in menus.

Opens channel list;

activates various functions.

Turns on and off the

television set (stand-by).

Signal source

Turns volume on/off

(mute).

Zapping function;

switches the menus back

one menu level.

Opens the menu.

Opens the Tools menu.

Switches between teletext

and TV modes.

Opens MyApps menu.

Switches on from standby;

selects stations step by step

Adjusts the volume.

Displays information.

Exits menu and

applications.

Opens the channel list.

Opens the electronic TV

guide.

Switches on from standby

mode;

selects channels directly.

Selects the channel list

(»ALL«, »FAV 1« to

»FAV 4«).

Record, playback, pause

or stop (only digital televi-

sion channels);

teletext on half screen.

Opens Screen share Opens Media Player

menu.

Functions according to

the screen help, HbbTV.

Next/previous image/

chapter, next/previous

track.

Select subtitle

Select audio channel

PIP function on/off

Table des matières

Autres manuels Grundig TV

Grundig

Grundig Vision 6 Manuel utilisateur

Grundig

Grundig Meglio series Manuel utilisateur

Grundig

Grundig 43 GHU 7970 B Manuel utilisateur

Grundig

Grundig ELEGANCE 40 LXW 102-8616 DOLBY Manuel utilisateur

Grundig

Grundig ASIS CUC 6301 Manuel utilisateur

Grundig

Grundig 48 VLE 525 BG Manuel utilisateur

Grundig

Grundig CUC 7303 Manuel utilisateur

Grundig

Grundig 32 GFB 6820 Manuel utilisateur

Grundig

Grundig M 72-105/9 iDTV Manuel utilisateur

Grundig

Grundig ARCANCE 37 P 37-5211 Manuel utilisateur

Grundig

Grundig 50 GEU 7900C Guide de référence

Grundig

Grundig 24 GCH 5900B Guide de référence

Grundig

Grundig 48 VLE 5520 BN Manuel utilisateur

Grundig

Grundig 02 GBH 4719 Manuel utilisateur

Grundig

Grundig 32 GFB 6060 Manuel d'utilisation et d'entretien

Grundig

Grundig 49 GUB 8865 Manuel utilisateur

Grundig

Grundig 40 GFB 6825 Manuel utilisateur

Grundig

Grundig 72010-800.00 Manuel utilisateur

Grundig

Grundig 75 GCU 8900B Manuel utilisateur

Grundig

Grundig B50 A 850 B Manuel utilisateur

Grundig

Grundig 24 VLE 4820 Manuel utilisateur

Grundig

Grundig VISION 7 47-7850 Manuel utilisateur

Grundig

Grundig VENTI II series Manuel utilisateur

Grundig

Grundig 55 GHU 8590 Manuel utilisateur

Manuels TV populaires d'autres marques

Philips

Philips Colour Television Manuel utilisateur

Toshiba

Toshiba 27A10 Manuel utilisateur

Philips

Philips 42PF9630A/37 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Philips

Philips Matchline 21CE7551 Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Philips

Philips 25PT4523-16 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Philips

Philips PR0930X3 Manuel utilisateur

Philips

Philips Brilliance 231P4QPY Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Philips

Philips 32HF9385D Guide de dépannage

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Philips

Philips 32PFH5300 Manuel utilisateur
