Grizzly G1035 Manuel utilisateur

11⁄2HP HEAVY-DUTY SHAPER

MODEL G1035

PARTS LIST

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

REVISED OCTOBER, 2002. PRINTED IN TAIWAN

ONLINE PARTS LIST DISCLAIMER

THESE PARTS REPRESENT THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED. THE MACHINE CONFIGURATION CAN

CHANGE AS PRODUCT IMPROVEMENTS ARE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF THE MACHINE, THIS PARTS LIST MAY NOT

EXACTLY DEPICT YOUR MACHINE. CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS ABOUT PART DIFFERENCES. PREVIOUS PARTS

LIST VERSIONS ARE NOT AVAILABLE ONLINE.

G1035 Heavy-Duty Shaper-B-

11A

25 26

20A

22 19

33A

33B

38A

31A

13A

41A

G1035 Heavy-Duty Shaper -C-

23 PW07 FLAT WASHER 5⁄16"

24 P1035024 FENCE ADJ. SCREW

25 PSS03 SETSCREW 1⁄4" - 20 x 3⁄8"

26 P1035026 FENCE MOUNT RIGHT

27 PN02 HEX NUT 5⁄16"-18

28 PW07 FLAT WASHER 5⁄16"

29 P1035029 WOOD FACING

30 PFH07 FLT HD SCRW 5⁄16" - 18 x 11⁄4"

31A P1035031A SWITCH BOX

32 PSW03 FWD⁄REV SWITCH

33A P1035033A SWITCH BOX COVER

33B PFS04M FLANGE SCREW M4-.7 X 6

34 P1035034 MOUNT BRACKET

35 P1035035 MOTOR CORD, 5 WIRE

36 P1035036 POWER CORD, 3 WIRE

37 P1071075 STRAIN RELIEF

38A PN07 HEX NUT 10-24

39 PHTEK1 SELF TAPPING SCREW

40 P1026041 SCALE

41 P1035041 NAMEPLATE LABEL

41A P1035041A WARNING LABEL

42 P1035042 GROMMET

45 PTLW01 EXT TOOTH WASHER #10

01 P1035001 STAND

02 P1035002 MOTOR COVER

03 PS06 PHLP HD SCRW 10-24 x 3⁄8"

04 PB21 HEX BOLT 3⁄8" - 16 x 3⁄4"

05 PLW04 LOCK WASHER 3⁄8"

06 PW02 FLAT WASHER 3⁄8"

07 P1035007 TABLE

08 P1035008 TABLE INSERT

09 P1035009 TABLE INSERT

10 P1035010 BARREL SCREW

11A PFH21 FLAT HD SCRW 10-24 x 3⁄4"

12 P1035012 STARTING PIN

13A P1026046 LOCK HANDLE 5⁄16"-18 x 1"

14 PW07 FLAT WASHER 5⁄16"

15 P1035015 FENCE MOUNT, LEFT

16 PLW04 LOCK WASHER 3⁄8"

17 PSB16 CAP SCREW 3⁄8" - 16 x 3⁄4"

18 PSB07 CAP SCREW 5⁄16" - 18 x 3⁄4"

19 P1035019 MAIN FENCE HOUSING

20A PSS05 SETSCREW 5⁄16" - 18 x 1⁄4"

21 P1035021 KNURLED KNOB

22 P1035022 ADJ. SCREW BRACKET

REF PART # DESCRIPTION REF PART # DESCRIPTION

G1035 Heavy-Duty Shaper-D-

129A

128A

126

131A 133

134

135

136

141A

147A

148

117

119

118

146

145

139

150

140

144A

123

122

121

111

114

110

108

107A

106

103

101

104

116

115A

127A

143

142

149

105

132

120

123-1

G1035 Heavy-Duty Shaper -E-

REF PART # DESCRIPTION

101 P1035101 HANDLE W/#102

103 P1035103 HANDWHEEL

104 PSS02 SETSCREW 5⁄16" - 18 x 3⁄8"

105 PSS11 SETSCREW 1⁄4" - 20 x 1⁄4"

106 P1035106 COLLAR W/#109

107A PSB17 CAP SCREW 1⁄4" - 20 x 3⁄8"

108 P1035108 SHAFT MOUNT

110 P1035110 WORM SHAFT

111 P1035111 HAND KNOB W/#112,113

114 P1035114 GIB

115A PSS20 SETSCREW 5⁄16" - 18 x 11⁄2"

116 PN02 HEX NUT 5⁄16"-18

117 P1035117 ELEVATION HOUSING

118 PB16 HEX BOLT 3⁄8" - 16 x 11⁄2"

119 PLW04 LOCK WASHER 3⁄8"

120 PLN06 LOCK NUT 1⁄2"-13

121 P1035121 GEAR 25T

122 PK20M KEY 5 x 5 x 15mm

123 P1035123 ELEVATION LEADSCREW

123-1 P51102 BEARING 51102

126 P1035126 SPINDLE SLIDE

127A PW07 FLAT WASHER 5⁄16"

128A PB15 HEX BOLT 5⁄16" - 18 x 3⁄8"

129A PB12 HEX BOLT 5⁄16"-18x1

1⁄4"

131A PB19 HEX BOLT 1⁄4" - 20 x 1⁄2"

132 PW06 FLAT WASHER 1⁄4"

133 P1035133 “L” BRACKET

134 P1035134 POINTER

135 PW07 FLAT WASHER 5⁄16"

136 PB15 HEX BOLT 5⁄16" - 18 x 3⁄8"

137 P1035137 CABLE CLAMP

139 P1035139 V-BELT 7 x 600L

140 P1035140 MOTOR STEP PULLEY

141A PB12 HEX BOLT 5⁄16" - 18 x 11⁄4"

142 PW07 FLAT WASHER 5⁄16"

143 PLW01 LOCK WASHER 5⁄16"

144A PK12M KEY 5 x 5 x 30MM

145 P1035145 MOTOR 11⁄2HP

146 P1035146 MOTOR MOUNT PLATE

147A PB16 HEX BOLT 3⁄8" - 16 x 11⁄2"

148 PW02 FLAT WASHER 3⁄8"

149 PLW04 LOCK WASHER 3⁄8"

150 PSS02 SETSCREW 5⁄16" - 18 x 3⁄8"

REF PART # DESCRIPTION

G1035 Heavy-Duty Shaper-F-

217

218A

219

201D

232

201C

231

201A

233

201B

202

203

204

205

216

214

213

208

229

208

206

207

215

220

REPLACEMENT SPINDLE CARTRIDGES P/N 204 SUPPLIED WITH PIN P/N 203

G1035 Heavy-Duty Shaper -G-

201A P1035201A 1⁄2" SPINDLE

201B P1035201B 3⁄4" SPINDLE

201C P1035201C 1⁄2"SPINDLE NUT SET

201D P1035201D 3⁄4" SPINDLE NUT SET

202 PR15M SNAP RING 30mm

203 P1035203 PIN

204 P1035204 SPINDLE CARTRIDGE

205 PK14M KEY 5 x 5 x 18mm

206 P1035206 HOUSING CAP

207 PS01 PHLP SCRW 10-24 x 1⁄2"

208 P6204 BEARING 6204-2RS

213 P1035213 SLEEVE

214 P1035214 BEARING HOUSING

215 P1035215 DRAW BAR

216 PR13M SNAP RING 65mm

217 P1035217 STEP PULLEY

218A P1035218A TOOTHED WASHER 3⁄4"

219 P1035219 SPANNER NUT

220 P1035220 DRAW BAR NUT

221 G2454 1⁄2" x 1" x 1⁄4" SPACER

222 G2455 1⁄2" x 1" x 3⁄8" SPACER

223 G2456 1⁄2" x 1" x 1⁄2" SPACER

224 G2457 1⁄2" x 1" x 3⁄4" SPACER

225 G2460 3⁄4"x1

1⁄4" x 1⁄4" SPACER

226 G2461 3⁄4"x1

1⁄4" x 3⁄8" SPACER

227 G2462 3⁄4"x1

1⁄4" x 1⁄2" SPACER

228 G2463 3⁄4"x1

1⁄4" x 3⁄4" SPACER

229 P1035229 SPACER, LONG

231 P1026223A 1⁄2"SPINDLE WASHER

232 P1026224A 3⁄4"SPINDLE WASHER

233 P1026226 SPINDLE WRENCH SET

REF PART # DESCRIPTION REF PART # DESCRIPTION

G1035 Heavy-Duty Shaper

-H-

413 410

414

405

416 406

409

402

401

404

403

415

401 PSS02 SETSCREW 5⁄16" - 18 x 3⁄8"

402 P1035402 SHAFT MOUNT

403 PLW04 LOCK WASHER 3⁄8"

404 PB21 HEX BOLT 3⁄8"-16 x 3⁄4"

405 P1035405 EXTENSION BRACKET

406 P1026306 LOCK KNOB ASSEMBLY W/#407, 408

409 P1026309 SHAFT

410 P1035410 HANDLE ASY. W/#411, 412

413 PN05 HEX NUT 1⁄4"- 20

414 P1035414 EXTENSION BAR

415 P1035415 GUARD

416 PFH04 FLT HD SCRW 1⁄4"-20 x 5⁄8"

REF PART # DESCRIPTION REF PART # DESCRIPTION

G1035 Heavy-Duty Shaper -I-

REF PART # DESCRIPTION

501

504

503

502

504

501 P1035501 HOLD-DOWN BAR

502 P1035502 HOLD-DOWN

503 P1035503 BRACKET, HOLD-DOWN

504 PSS03 SETSCREW 1⁄4"-20 x 3⁄8"

G1035 Heavy-Duty Shaper

-J-

601A

602A

603

612

607

608A

604A

609A

610

614

611

615

601A P1023401A MITER HANDLE

602A PW07 FLAT WASHER 5⁄16"

603 P1023403 MITER GAUGE BODY

604A P1035604 MITER BAR

607 PN07 HEX NUT 10-24

608A PSS32 SETSCREW 10-24 X 3⁄4"

609A PSS29 SETSCREW 10-24 X 1⁄4"

610 P1023410 STOP

611 P1023411 POINTER

612 P1023212 SCALE

614 PRP54M ROLL PIN 1.5 X 3MM

615 P1023SL415 MITER HINGE PIN

616 P1035616 COMPLETEMITER GAUGE

REF# PART# DESCRIPTION
