Gree XK60 Manuel utilisateur

Owner's Manual

Original Instructions

Wired Controller XK60

Thank you for choosing our commercial air conditioners. Please

read this owner's manual carefully before operation and retain it for

future reference.

This owner's manual is subject to change without prior notice for

product improvement. GREE Electric Appliances, Inc. of Zhuhai

reserves the final right to interpret this manual.

User Notice

Thanks for choosing GREE duct type air conditioners. Please

read this manual carefully before operating this product and keep it

for future reference. In addition, please take notice of the symbols

below.

WARNING!

This mark indicates procedures which, if improperly performed,

might lead to the death or serious injury of the user.

CAUTION!

This mark indicates procedures which, if improperly performed,

might possibly result in personal harm to the user, or damage to

property.

CAUTION!

Do not install the wired controller in the damp place or under direct sunlight.

Do not beat, toss, or frequently assemble/disassemble the wired controller.

Do not operate the wired controller with wet hands and keep dry at all times.

Do not install or remove the wired controller by yourself. If necessary, please

contact a trained service technican.

This wired controller is applicable to various kinds of air conditioners, While

some specific functions,unavailable to the duct type air conditioners,will not be

covered in this manual.

Before operating the air conditioner, please read this manual carefully and keep

it for future reference.

Contents

1 Introduction to the Wired Controller---------------------------------1

1.1 Appearance and LCD Icons------------------------------------------------- 2

1.2 Introduction to the LCD Icons----------------------------------------------- 2

2 Press Buttons ------------------------------------------------------------5

2.1 Buttons---------------------------------------------------------------------------- 5

2.2 Instruction to the Function of Press Buttons ---------------------------- 5

3 OPERATION INSTRUCTION ----------------------------------------7

3.1 On/off------------------------------------------------------------------------------ 7

3.2 Mode Setting-------------------------------------------------------------------- 8

3.3 Temperature Setting----------------------------------------------------------- 8

3.4 Fan Speed Setting------------------------------------------------------------- 9

3.5 Right and Left Swing---------------------------------------------------------10

3.6 Up and Down Swing----------------------------------------------------------12

3.7 Timer Setting-------------------------------------------------------------------14

3.8 Air Exchange Setting---------------------------------------------------------18

3.9 Sleep Setting-------------------------------------------------------------------21

3.10 Health Setting ----------------------------------------------------------------26

3.11 I-Demand Setting------------------------------------------------------------29

3.12 Vacation Setting -------------------------------------------------------------32

3.13 Turbo Function Setting-----------------------------------------------------35

3.14 SAVE Function Setting-----------------------------------------------------38

3.15 E-HEATER Setting----------------------------------------------------------45

3.16 Blow Function Setting------------------------------------------------------48

3.17 Filter Setting ------------------------------------------------------------------52

3.18 Quiet Function Setting -----------------------------------------------------57

3.19 Ultra-Dry Setting-------------------------------------------------------------59

3.20 Other Functions--------------------------------------------------------------60

4 Installation of the Wired Controller-------------------------------- 66

4.1 Standard Parts-----------------------------------------------------------------66

4.2 Installation Location and Installation Requirements------------------67

4.3 How to Install the Wired Controller---------------------------------------68

4.4 How to Remove the Wired Controller------------------------------------70

5 Error Display------------------------------------------------------------ 70

Wired Controler XK60

1 Introduction to the Wired Controller

Fig.1 Appearance of the Wired Controller

Wired Controler XK60

1.1 Appearance and LCD Icons

Fig.2 Appearance of the LCD

1.2 Introduction to the LCD Icons

Table 1

No.

Icons

Introduction

Left and right swing function

Up and down swing function

Wired Controler XK60

Air exchange function

Sleep function

Auto mode

COOL mode

DRY mode

FAN mode

HEAT mode

Health function

I-Demand function

Vacation function

Status display of master and slave wired controller

Shield function

The button operation, temperature setting, "On/Off" operation,

"Mode" setting, and "Save" setting are disabled

Wired Controler XK60

Fan speed

Memory function

The unit will resume the original setting state after power

recovery

Turbo function

Energy-saving function

Ambient/setting temperature

Electric heater

Blow function

Defrosting function

Filter cleaning

Timer Setting

Keycard control / Detected status sensed by human body

Quiet function

Lock function

Wired Controler XK60

2 Press Buttons

2.1 Buttons

Fig.3 Press Buttons

2.2 Instruction to the Function of Press Buttons

Table 2

No.

Press

Buttons

Function Introduction

Enter/

Cancel

Function selection and canceling

Press it for 5s to enquiry the outdoor and indoor ambient

temperature.

▲

Running temperature setting of indoor unit, range :61~86°F

Timer setting, range:0.5-24hr.

Wired Controler XK60

▼

Air function setting

Save setting

Clean setting.

Fan

Select fan speed from high, mid-high, middle, mid-low, low and

auto levels.

Mode

Selection of the COOL, HEAT, FAN, Auto or DRY mode.

Function

Switchover among these functions of

SWING/AIR/SLEEP/HEALTH/I-DEMAND/VACATION/TURBO/

SAVE/E-HEATER/BLOW/QUIET.

Timer

Timer setting.

On/Off

Turn on/off indoor unit.

mode

and

2 ▲

Memory

Press Mode and ▲ at the same time for 5s under the OFF state of

the unit to activate/deactivate memory function (If memory is set,

indoor unit will resume original setting state after power recovery.

If not, indoor unit is defaulted to be OFF after power recovery.

Memory function is defaulted to be ON) .

2 ▲

and

6 ▼

Lock

Under the ON state of the unit without any malfunction or under

the OFF state of the unit, press ▲and ▼ buttons at the same

time for 5s to go to the lock state. All other buttons won’t respond

when pressed. Repress ▲ and ▼ again for 5s to quit the lock

state.

mode

and

6 ▼

°F/°C

Under the OFF state of the unit, press the Mode and ▼ at the

same time for 5s to switch the temperature scale between Celsius

and Fahrenheit.
