Service Manual

Change for life

GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI

Service Manual

Table of Contents

Part I : Technical Information ..................................... 1

1. Summary......................................................................... 1

2. Specications............................................................... 2

2.1 Specication Sheet..................................................................................................2

2.2 Capacity Variation Ratio According to Temperature .................................10

2.3 Cooling and Heating Data Sheet in Rated Frequency...............................10

3. Outline Dimension Diagram................................. 11

3.1 Indoor Unit ................................................................................................................11

3.2 Outdoor Unit.............................................................................................................13

4. Refrigerant System Diagram ............................... 15

5. Electrical Part ............................................................. 16

5.1 Wiring Diagram .......................................................................................................16

5.2 PCB Printed Diagram............................................................................................20

6. Function and Control .............................................. 23

6.1 Function Buttons of Air Conditioner...............................................................23

6.2 Remote Controller Introduction of YAP1F11(WiFi).....................................25

6.3 GREE+ App Operation Manual ..........................................................................29

6.4 Ewpe Smart App Operation Manual.................................................................30

6.5 Description of Each Control Operation..........................................................31

Part II : Installation and Maintenance .................. 35

7. Notes for Installation and Maintenance.......... 35

8. Installation ................................................................... 38

8.1 Installation Dimension Diagram........................................................................38

8.2 Installation Parts-checking ................................................................................41

8.3 Selection of Installation Location.....................................................................41

8.4 Electric Connection Requirement ....................................................................41

Table of Contents

Service Manual

Table of Contents

8.5 Installation of Indoor Unit....................................................................................42

8.6 Installation of Outdoor Unit ................................................................................43

8.7 Vacuum Pumping and Leak Detection............................................................45

8.8 Check after Installation and Test Operation .................................................45

9. Maintenance................................................................ 46

9.1 Error Code List........................................................................................................46

9.2 How to Check Simply the Main Part of Indoor ............................................49

9.3 How to Check Simply the Main Part of Outdoor .........................................59

9.4 Troubleshooting for Normal Malfunction ......................................................61

10. Exploded View and Parts List........................... 63

10.1 Indoor Unit..............................................................................................................63

10.2 Outdoor Unit ..........................................................................................................67

11. Removal Procedure ............................................... 75

11.1 Removal Procedure of Indoor Unit ................................................................75

11.2 Removal Procedure of Outdoor Unit.............................................................86

Appendix:.......................................................................... 94

Appendix 1: Reference Sheet of Celsius and Fahrenheit...............................94

Appendix 2: Conguration of Connection Pipe .................................................94

Appendix 3: Pipe Expanding Method.....................................................................95

Appendix 4: List of Resistance for Temperature Sensor................................96

Technical Information

Service Manual

Outdoor Unit:

1. Summary

Indoor Unit:

GVC24AMXF-K3NTC7A/I

GVH24AMXF-K3NTC7A/I

(CG156N07700)

GVC36ALXL-K3NTC7A/I

GVH36ALXL-K3NTC7A/I

GVH24AMXF-K3NTC7A/I

(CG156N07701)

Remote Controller:

Model list:

No. Model Product code Indoor model Indoor product

code Outdoor model Outdoor product

code

Remote

Controller

1 GVC24AMXF-K3NTC7A CG156007800 GVC24AMXF-K3NTC7A/I CG156N07800 GVC24AQXF-K3NTD1A/O CG082W01700

YAP1F11

(WiFi)

2GVH24AMXF-K3NTC7A CG156007700 GVH24AMXF-K3NTC7A/I CG156N07700 GVH24AQXF-K3NTD1A/O CG082W01600

3 CG156007701 CG156N07701

4 GVC36ALXL-K3NTC7A CG156008300 GVC36ALXL-K3NTC7A/I CG156N08300 GVC36ALXL-K3NTC7A/O CG156W08300

5 GVH36ALXL-K3NTC7A CG156008400 GVH36ALXL-K3NTC7A/I CG156N08400 GVH36ALXL-K3NTC7A/O CG156W08400

GVC24AQXF-K3NTD1A/O

GVH24AQXF-K3NTD1A/O

GVC36ALXL-K3NTC7A/O

GVH36ALXL-K3NTC7A/O

YAP1F11(WiFi)

2Technical Information

Service Manual

Model GVC24AMXF-K3NTC7A

Product Code CG156007800

Power

Supply

Rated Voltage V~ 220-240

Rated Frequency Hz 50

Phases 1

Power Supply Mode Indoor

Cooling Capacity W T1: 7200 / T3: 6100

Heating Capacity W /

Cooling Power Input W T1: 2320 / T3: 2700

Heating Power Input W /

Cooling Power Current A T1: 10.5 / T3: 12

Heating Power Current A /

Rated Input W 3100

Rated Cooling Current A 16

Rated Heating Current A /

Air Flow Volume m3/h 1150/1100/1000/950

Dehumidifying Volume L/h 2.5

EER W/W T1: 3.10 / T3: 2.26

COP W/W /

SEER /

HSPF /

Application Area m232-50

Indoor

Unit

Model of indoor unit GVC24AMXF-K3NTC7A/I

Indoor Unit Product Code CG156N07800

Fan Type Centrifugal

Fan Diameter Length(DXL) mm Φ352×130

Cooling Speed r/min 490/420/380/340

Heating Speed r/min /

Fan Motor Power Output W 64

Fan Motor RLA A 0.7

Fan Motor Capacitor μF 4.5

Evaporator Form Aluminum Fin-copper Tube

Evaporator Pipe Diameter mm Φ7

Evaporator Row-n Gap mm 2-1.3

Evaporator Coil Length (LXDXW) mm 724×25.4×392

Swing Motor Model MP35CK / MP35CD

Swing Motor Power Output W 2.5 / 2.5

Fuse Current A 5

Sound Pressure Level dB (A) Cooling: 47/44/42/38

Sound Power Level dB (A) Cooling: 57/54/52/48

Dimension (WXHXD) mm 507X1770X320

Dimension of Carton Box (LXWXH) mm 1985X620X425

Dimension of Package (LXWXH) mm 1988X623X440

Net Weight kg 38

Gross Weight kg 50

2. Specications

2.1 Specication Sheet

Technical Information

Service Manual

The above data is subject to change without notice; please refer to the nameplate of the unit.

Outdoor

Unit

Outdoor Unit Model GVC24AQXF-K3NTD1A/O

Outdoor Unit Product Code CG082W01700

Compressor Manufacturer ZHUHAI LANDA COMPRESSOR CO., LTD.

Compressor Model QXAH-E265H070

Compressor Oil RB68EP or equivalent

Compressor Type Rotary

Compressor LRA. A 56

Compressor RLA A 9.6

Compressor Power Input W 2180

Compressor Overload Protector HPD-456

Throttling Method Capillary

Set Temperature Range ºC 16~30

Cooling Operation Ambient Temperature Range ºC 18~52

Heating Operation Ambient Temperature Range ºC /

Condenser Form Aluminum Fin-copper Tube

Condenser Pipe Diameter mm Φ7

Condenser Rows-n Gap mm 2-1.4

Condenser Coil Length (LXDXW) mm 811×38.1×616

Fan Motor Speed rpm 740

Fan Motor Power Output W 60

Fan Motor RLA A 0.6

Fan Motor Capacitor μF 3.5

Outdoor Unit Air Flow Volume m3/h 3200

Fan Type Axial-ow

Fan Diameter mm Φ520

Defrosting Method /

Climate Type T3

Isolation I

Moisture Protection IPX4

Permissible Excessive Operating Pressure for

the Discharge Side MPa 4.3

Permissible Excessive Operating Pressure for

the Suction Side MPa 2.5

Sound Pressure Level dB (A) 57

Sound Power Level dB (A) 67

Dimension(WXHXD) mm 958X660X402

Dimension of Carton Box (LXWXH) mm 1029X453X715

Dimension of Package(LXWXH) mm 1032X456X737

Net Weight kg 52.5

Gross Weight kg 57

Refrigerant R410A

Refrigerant Charge kg 1.5

Connection

Pipe

Connection Pipe Length m 5

Connection Pipe Gas Additional Charge g/m 15

Outer Diameter Liquid Pipe inch 1/4

Outer Diameter Gas Pipe inch 5/8

Max Distance Height m 10

Max Distance Length m 25

Note: The connection pipe applies metric diameter.

2. Specications

4Technical Information

Service Manual

Model GVH24AMXF-K3NTC7A

Product Code CG156007700/CG156007701

Power

Supply

Rated Voltage V~ 220-240

Rated Frequency Hz 50

Phases 1

Power Supply Mode Indoor

Cooling Capacity W T1: 7034 / T3: 6100

Heating Capacity W 7300

Cooling Power Input W T1: 2280 / T3: 2700

Heating Power Input W 2190

Cooling Power Current A T1:10.5 / T3: 12

Heating Power Current A 9.5

Rated Input W 3100

Rated Cooling Current A 16

Rated Heating Current A 11.5

Air Flow Volume m3/h 1150/1100/1000/950

Dehumidifying Volume L/h 2.5

EER W/W T1: 3.09 / T3: 2.26

COP W/W 3.333

SEER /

HSPF /

Application Area m232-50

Indoor

Unit

Model of indoor unit GVH24AMXF-K3NTC7A/I

Indoor Unit Product Code CG156N07700/CG156N07701

Fan Type Centrifugal

Fan Diameter Length(DXL) mm Φ352×130

Cooling Speed r/min 490/420/380/340

Heating Speed r/min 490/420/380/340

Fan Motor Power Output W 64

Fan Motor RLA A 0.7

Fan Motor Capacitor μF 4.5

Evaporator Form Aluminum Fin-copper Tube

Evaporator Pipe Diameter mm Φ7

Evaporator Row-n Gap mm 2-1.3

Evaporator Coil Length (LXDXW) mm 724×25.4×392

Swing Motor Model MP24TA/MP35AA

Swing Motor Power Output W 1.5 / 2.5

Fuse Current A 5

Sound Pressure Level dB (A) Cooling: 47/44/42/38

Heating: 47/44/42/38

Sound Power Level dB (A) Cooling: 57/54/52/48

Heating: 57/54/52/48

Dimension (WXHXD) mm 507X1770X320

Dimension of Carton Box (LXWXH) mm 1985X620X425

Dimension of Package (LXWXH) mm 1988X623X440

Net Weight kg 38

Gross Weight kg 50

2. Specications

Technical Information

Service Manual

The above data is subject to change without notice; please refer to the nameplate of the unit.

Outdoor

Unit

Outdoor Unit Model GVH24AQXF-K3NTD1A/O

Outdoor Unit Product Code CG082W01600

Compressor Manufacturer ZHUHAI LANDA COMPRESSOR CO., LTD

Compressor Model QXAH-E265H070

Compressor Oil RB68EP or equivalent

Compressor Type Rotary

Compressor LRA. A 56

Compressor RLA A 9.6

Compressor Power Input W 2180

Compressor Overload Protector HPD-456

Throttling Method Capillary

Set Temperature Range ºC 16~30

Cooling Operation Ambient Temperature Range ºC 18~52

Heating Operation Ambient Temperature Range ºC -7~24

Condenser Form Aluminum Fin-copper Tube

Condenser Pipe Diameter mm Φ7

Condenser Rows-n Gap mm 2-1.4

Condenser Coil Length (LXDXW) mm 811×38.1×616

Fan Motor Speed rpm 740

Fan Motor Power Output W 60

Fan Motor RLA A 0.6

Fan Motor Capacitor μF 3.5

Outdoor Unit Air Flow Volume m3/h 3200

Fan Type Axial-ow

Fan Diameter mm Φ520

Defrosting Method Automatic Defrosting

Climate Type T3

Isolation I

Moisture Protection IPX4

Permissible Excessive Operating Pressure for

the Discharge Side MPa 4.3

Permissible Excessive Operating Pressure for

the Suction Side MPa 2.5

Sound Pressure Level dB (A) 57

Sound Power Level dB (A) 67

Dimension(WXHXD) mm 958X660X402

Dimension of Carton Box (LXWXH) mm 1029X453X715

Dimension of Package(LXWXH) mm 1032X456X737

Net Weight kg 54

Gross Weight kg 58.5

Refrigerant R410A

Refrigerant Charge kg 1.8

Connection

Pipe

Connection Pipe Length m 5

Connection Pipe Gas Additional Charge g/m 50

Outer Diameter Liquid Pipe inch 1/4

Outer Diameter Gas Pipe inch 5/8

Max Distance Height m 10

Max Distance Length m 25

Note: The connection pipe applies metric diameter.

2. Specications

6Technical Information

Service Manual

Model GVC36ALXL-K3NTC7A

Product Code CG156008300

Power

Supply

Rated Voltage V~ 220-240

Rated Frequency Hz 50

Phases 1

Power Supply Mode Outdoor

Cooling Capacity W T1: 10550 / T3: 9100

Heating Capacity W /

Cooling Power Input W T1: 3700 / T3: 4300

Heating Power Input W /

Cooling Power Current A T1: 17 / T3: 19

Heating Power Current A /

Rated Input W 5700

Rated Cooling Current A 26

Rated Heating Current A /

Air Flow Volume m3/h 1900/1700/1550/1400

Dehumidifying Volume L/h 3.5

EER W/W T1: 2.85 / T3: 2.14

COP W/W /

SEER /

HSPF /

Application Area m246-70

Indoor

Unit

Model of indoor unit GVC36ALXL-K3NTC7A/I

Indoor Unit Product Code CG156N08300

Fan Type Centrifugal

Fan Diameter Length(DXL) mm Φ379×180.5

Cooling Speed r/min 510/440/400/360

Heating Speed r/min /

Fan Motor Power Output W 150

Fan Motor RLA A 1.5

Fan Motor Capacitor μF 6

Evaporator Form Aluminum Fin-copper Tube

Evaporator Pipe Diameter mm Φ7

Evaporator Row-n Gap mm 2-1.4

Evaporator Coil Length (LXDXW) mm 876x472x25.4

Swing Motor Model MP35AB / MP24TA

Swing Motor Power Output W 2.5 / 1.5

Fuse Current A 5

Sound Pressure Level dB (A) Cooling: 53/51/49/46

Sound Power Level dB (A) Cooling: 63/61/59/56

Dimension (WXHXD) mm 587X1882X394

Dimension of Carton Box (LXWXH) mm 2150X735X530

Dimension of Package (LXWXH) mm 2153X738X545

Net Weight kg 55

Gross Weight kg 77.5

2. Specications

Technical Information

Service Manual

The above data is subject to change without notice; please refer to the nameplate of the unit.

Outdoor

Unit

Outdoor Unit Model GVC36ALXL-K3NTC7A/O

Outdoor Unit Product Code CG156W08300

Compressor Manufacturer ZHUHAI LANDA COMPRESSOR CO., LTD.

Compressor Model QXAS-F41N450B

Compressor Oil Ze-GLES RB68EP or FVC 68D or FV 50S or equivalent

Compressor Type Rotary

Compressor LRA. A 81

Compressor RLA A 16

Compressor Power Input W 3560

Compressor Overload Protector UP14SE5115-M

Throttling Method Capillary

Set Temperature Range ºC 16~30

Cooling Operation Ambient Temperature Range ºC 18~52

Heating Operation Ambient Temperature Range ºC /

Condenser Form Aluminum Fin-copper Tube

Condenser Pipe Diameter mm Φ7

Condenser Rows-n Gap mm 2-1.4

Condenser Coil Length (LXDXW) mm 794×38.1×1232

Fan Motor Speed rpm 850

Fan Motor Power Output W 68

Fan Motor RLA A 0.65

Fan Motor Capacitor μF 4

Outdoor Unit Air Flow Volume m3/h 6000

Fan Type Axial-ow

Fan Diameter mm Φ472

Defrosting Method /

Climate Type T3

Isolation I

Moisture Protection IPX4

Permissible Excessive Operating Pressure for

the Discharge Side MPa 4.3

Permissible Excessive Operating Pressure for

the Suction Side MPa 2.5

Sound Pressure Level dB (A) 60

Sound Power Level dB (A) 70

Dimension(WXHXD) mm 978X1260X412

Dimension of Carton Box (LXWXH) mm 1025X435X1285

Dimension of Package(LXWXH) mm 1033X443X1405

Net Weight kg 87

Gross Weight kg 97

Refrigerant R410A

Refrigerant Charge kg 3.2

Connection

Pipe

Connection Pipe Length m 5

Connection Pipe Gas Additional Charge g/m 15

Outer Diameter Liquid Pipe inch 3/8

Outer Diameter Gas Pipe inch 5/8

Max Distance Height m 20

Max Distance Length m 30

Note: The connection pipe applies metric diameter.

2. Specications

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Gree Climatiseur

Gree

Gree HNTF24/A-D Manuel utilisateur

Gree

Gree Livo+ LIVS09HP230V1B Manuel utilisateur

Gree

Gree GWH12AAB-K3NNA1A Manuel utilisateur

Gree

Gree GRP-E08SH-R4W Manuel utilisateur

Gree

Gree SEER13 Series Manuel d'utilisation

Gree

Gree FLR09HP230V1AF Manuel utilisateur

Gree

Gree GMV-ND22T/B-T Manuel utilisateur

Gree

Gree GFH(09)EA-K6DNA1B/I Manuel utilisateur

Gree

Gree GWH18PD-K3NNA1A Manuel utilisateur

Gree

Gree GUHD09NK3FO Manuel utilisateur

Gree

Gree Trendy Series Manuel utilisateur

Gree

Gree GWH09KF-K3DNA5G Manuel utilisateur

Gree

Gree SAP09HP230V1AO Manuel utilisateur

Gree

Gree GJC10BL-A6NRNE2D Manuel utilisateur

Gree

Gree Admiral Series Manuel utilisateur

Gree

Gree U-match Series Manuel utilisateur

Gree

Gree FP-8XD/A-E Manuel utilisateur

Gree

Gree GKH24S3GI Manuel utilisateur

Gree

Gree GMV-ND36TS/A-T Manuel utilisateur

Gree

Gree GMV-60WL/C-T Manuel utilisateur

Gree

Gree GWHD(48S)NM3DO Manuel utilisateur

Gree

Gree GUHD18ND3FO Manuel utilisateur

Gree

Gree GMV-280WL/C1-X Manuel utilisateur

Gree

Gree GPH12AO-K5NNA1A Manuel utilisateur

Manuels Climatiseur populaires d'autres marques

Spheros

Spheros CC 355 Manuel utilisateur

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manuel utilisateur

Panasonic

Panasonic CS-E12HKEW Manuel utilisateur

nedis

nedis ACMB1WT7 Manuel utilisateur

Samsung

Samsung AR KV Series Mode d’emploi

Daikin

Daikin FCFV50A Manuel utilisateur

Fujitsu

Fujitsu Inverter ASBA30JFC Manuel utilisateur

Toshiba

Toshiba RAS-M10SMUV-E Manuel utilisateur

Daikin

Daikin FXLQ20MAVE Manuel utilisateur

Hitachi

Hitachi RAS-E24CAK Manuel utilisateur

CIAT

CIAT Magister 2 Series Mode d’emploi

Bestron

Bestron AAC6000 Manuel utilisateur

Hisense

Hisense 7K Manuel technique

Frigidaire

Frigidaire FFRE0533S1E0 Manuel utilisateur

Samsung

Samsung AS09HM3N Manuel utilisateur

Frigidaire

Frigidaire CRA073PU11 Manuel du propriétaire

Soleus Air

Soleus Air GB-PAC-08E4 Manuel utilisateur

McQuay

McQuay MCK020A Manuel utilisateur
