CASSETTE TYP FAN COIL UNIT SERVICE MANUAL

(GC201409-I)

CONTENTS

PRODUCT.....................................................................................................2

1. MODELS LIST ........................................................................................................2

2. NOMENCLATURE OF THE UNIT ...........................................................................4

3. FUNCTION ..............................................................................................................4

4. PRODUCT DATA.....................................................................................................5

CONTROL...................................................................................................17

1. WIRELESS REMOTE CONTROLLER .................................................................17

2. WIRED REMOTE CONTROLLER.........................................................................24

INSTALLTION .............................................................................................28

1. SELECTION THE MOUNTING POSITION ...........................................................28

2. DRAINAGE PIPE...................................................................................................29

3. PRECAUTIONS FOR DRAINAGE RAISING PIPE...............................................30

4. ELECTRIC WIRING...............................................................................................32

5. INSTALLATION OF PANEL ..................................................................................34

MAINTENANCE..........................................................................................37

1.TROUBLESHOOTING ...........................................................................................37

2.CARE AND MAINTENANCE..................................................................................37

3. WIRING DIAGRAM ...............................................................................................40

4. DISASSEMBLY AND ASSEMBLY PROCEDURE OF MAIN PARTS ...................42

5. EXPLODED VIEWS AND SPARE PART LISTS ...................................................48

Cassette Type Fan Coil

Unit Service Manual

PRODUCT

Cassette Type Fan Coil

Unit Service Manual

PRODUCT

1. MODELS LIST

Model Name Product Code

Cooling

Capacity

(W)

Air ow

Volume

(m3/h)

Power Supply

(V, Ph, Hz) Remarks

FP-8XD-E EM52000051 4600/7500 850 220-240V~ 50Hz

FP-8XD/A-E EM5200045010 4640/7500 850 220-240V~ 50Hz

FP-10XD-E EM52000061 5400/9100 1020 220-240V~ 50Hz

FP-10XD/A-E EM5200046010 5400/9100 1020 220-240V~ 50Hz

FP-12.5XD-E EM52000031 6700/10500 1270 220-240V~ 50Hz

FP-12.5XD/A-E EM5200047010 6700/10500 1250 220-240V~ 50Hz

FP-14XD-E EM52000071 7700/11200 1560 220-240V~ 50Hz

FP-14XD/A-E EM5200048010 7740/11200 1430 220-240V~ 50Hz

FP-16XD-E EM52000081 8700/12900 1640 220-240V~ 50Hz

FP-16XD/A-E EM5200049010 8700/12900 1640 220-240V~ 50Hz

FP-18XD-E EM52000041 9600/14600 1850 220-240V~ 50Hz

FP-18XD/A-E EM5200050010 9600/14600 1800 220-240V~ 50Hz

FP-51XD-E EM52000011 3000/4000 510

220-240V~ 50Hz

FP-68XD-E EM52000021 3500/5000 680

Cassette Type Fan Coil

Unit Service Manual

PRODUCT

Model Name Product Code

Cooling/Heating

Capacity

(W)

Air ow

Volume

(m3/h)

Power Supply

(V, Ph, Hz) Remarks

FP-85XD/B-T

EM520N0930 4150/5600 800 220-240V~ 50Hz

EM520N0940 4160/7800 780 208-230V~ 60Hz

FP-102XD/B-T

EM520N0910 500/6500 1020 220-240V~ 50Hz

EM520N0920 540/9000 1020 208-230V~ 60Hz

FP-125XD/B-T

EM520N0890 6000/7800 1180 220-240V~ 50Hz

EM520N0900 6300/10000 1130 208-230V~ 60Hz

FP-140XD/B-T

EM520N0870 8000/9000 1400 220-240V~ 50Hz

EM520N0880 8000/12000 1350 208-230V~ 60Hz

FP-160XD/B-T

EM520N0850 8700/10000 1550 220-240V~ 50Hz

EM520N0860 9000/14000 1550 208-230V~ 60Hz

FP-180XD/B-T

EM520N0830 9500/11000 1800 220-240V~ 50Hz

EM520N0840 10000/16000 1800 208-230V~ 60Hz

FP-200XD/B-T

EM520N0810 1300/14600 2000 220-240V~ 50Hz

EM520N0820 1300/19000 2000 208-230V~ 60Hz

FP-68XDT/B-K EM520N0990 3500/6000 680 220-240V~ 50Hz

FP-85XDT/B-K EM520N0960 4100/6800 850 220-240V~ 50Hz

FP-125XDT/B-K EM520N0970 6000/9500 1250 220-240V~ 50Hz

FP-180XDT/B-K EM520N0980 8000/13000 1800 220-240V~ 50Hz

Cassette Type Fan Coil

Unit Service Manual

PRODUCT

2. NOMENCLATURE OF THE UNIT

FP - □□□ /□-□

1 2 3 4 5 6

NO. Description Options

1 Fan coil Fan coil unit

2Air ow volume Number×10 m3/h(FP-51XD-E;FP-68XD-E);Number×100 m3/h(8,10,12.5,14,16,18)

3Structure type XD-Cassette Type

4 Pipes type Default- 2 pipes; T-4 pipes

5Design Sequence Arranged by A, B,C…

6Power code E-220-240V~ 50Hz;T-220-240V~ 50Hz, 208-230V~ 60Hz; K-220-240V~ 50Hz

3. FUNCTION

1. Novel pattern: the exposed skin plates of unit looks so elegant and luxurious that they can be taken as

the indoor decorations.

2. Compact design: A large number of non-metallic materials have been used, so that the body of the unit

is quite light-weight and thin, which makes the unit looks sensuous.

3. Low noise: Dynamic principles have been adopted for the design of the fan blades so as to make sure

the air volume is enough and running noise is considerably low.

4. Durable lter screen: The durable lter screen shares a cleaning cycle 20 times longer than that of the

conventional lter screen, needless to clean it frequently.

5. Microcomputer control: The unit is able to automatically adjust the fan speed in accordance with the

indoor ambient temperature to meet a wide range of users’ requirements.

6. Small height of the unit, saving much installation space

7. Large cooling (heating) capacity, low noise, three-speed motor which can adjust the air volume and

meet a wide range of users’ requirements.

8. Excellent material, stringent process control, which guarantee the hi-quality and long life of the unit.

9. Die-formed drain pan, entirely bonded insulating material, carefree about the condensate water.

Cassette Type Fan Coil

Unit Service Manual

PRODUCT

4. PRODUCT DATA

Model FP-8XD/A-E FP-10XD/A-E FP-12.5XD/A-E FP-14XD/A-E

Code EM5200045010 EM5200046010 EM5200047010 EM5200048010

Air ow volume

High

CFM 500 600 735 841

m3/h 850 1020 1250 1430

Medium

CFM 375 464 606 802

m3/h 637 789 1030 1363

Low

CFM 303 362 538 705

m3/h 515 615 915 1200

Capacity

Cooling W 4640 5400 6700 7740

Heating W 7500 9100 10500 11200

Power system

Type V-Ph-Hz 220-240V~ 50Hz 220-240V~ 50Hz 220-240V~ 50Hz 220-240V~ 50Hz

Input W 100 100 150 140

Exterior static pressure Pa 0 0 0 0

Water system

Water ow volume m3/h 0.829 0.964 1.196 1.382

Pressure drop kPa 15 25 25 30

Coil

Type - Aluminum n-

copper tube

Aluminum n-

copper tube

Aluminum n-

copper tube

Aluminum n-

copper tube

Operating pressure MPa ≤1.6MPa ≤1.6MPa ≤1.6MPa ≤1.6MPa

Motor

Type - FN35B FN35B FN35B FN50T

Capacitor µF 2.5 3.5 3.5 2.5

Power output W 35 35 35 50

Sound pressure level dB(A) 46 46 47 52

Connection

pipe size

Water inlet &outlet inch G3/4" G3/4" G3/4" G3/4"

Condensing water drain mm 32 32 32 32

Outline dimension

(W×D×H)

Body mm 840×840×240 840×840×240 840×840×240 840×840×320

Panel mm 960×960×60 960×960×60 960×960×60 960×960×60

Package dimension

(W×D×H)

Body mm 960×960×310 960×960×310 960×960×310 960×960×394

Panel mm 1040×1025×115 1040×1025×115 1040×1025×115 1040×1025×115

Net weight

Body kg 27 27 27 33

Panel kg 6.5 6.5 6.5 6.5

Gross weight

Body kg 35 35 35 42

Panel kg 10 10 10 10

Loading quantity

20'GP 84 84 84 72

40'GP 168 168 168 120

40'HQ 192 192 192 144

Wired remote controller Z5K351/Z4E351B Z5K351/Z4E351B Z5K351/Z4E351B Z5K351/Z4E351B

Wireless remote controller YB1F2(X-FAN) YB1F2(X-FAN) YB1F2(X-FAN) YB1F2(X-FAN)

Cassette Type Fan Coil

Unit Service Manual

PRODUCT

Model FP-16XD/A-E FP-18XD/A-E

Code EM5200049010 EM5200050010

Air ow volume

High

CFM 965 1060

m3/h 1640 1800

Medium

CFM 853 1035

m3/h 1460 1760

Low

CFM 781 932

m3/h 1327 1584

Capacity

Cooling W 8700 9600

Heating W 12900 14600

Power system

Type V-Ph-Hz 220-240V~ 50Hz 220-240V~ 50Hz

Input W 150 155

Exterior static pressure Pa 0 0

Water system

Water ow volume m3/h 1.554 1.714

Pressure drop kPa 30 30

Coil

Type - Aluminum n-copper tube Aluminum n-copper tube

Operating pressure MPa ≤1.6MPa ≤1.6MPa

Motor

Type - FN50T FN50T

Capacitor µF 4.5 4.5

Power output W 50 50

Sound pressure level dB(A) 53 54

Connection pipe size

Water inlet &outlet inch G3/4" G3/4"

Condensing water drain mm 32 32

Outline dimension

(W×D×H)

Body mm 840×840×320 840×840×320

Panel mm 960×960×60 960×960×60

Package dimension

(W×D×H)

Body mm 960×960×394 960×960×394

Panel mm 1040×1025×115 1040×1025×115

Net weight

Body kg 33 33

Panel kg 6.5 6.5

Gross weight

Body kg 42 42

Panel kg 10 10

Loading quantity

20'GP 72 72

40'GP 120 120

40'HQ 144 144

Wired remote controller Z5K351/Z4E351B Z5K351/Z4E351B

Wireless remote controller YB1F2(X-FAN) YB1F2(X-FAN)

Cassette Type Fan Coil

Unit Service Manual

PRODUCT

Model FP-8XD-E FP-10XD-E FP-12.5XD-E FP-14XD-E

Code EM52000051 EM52000061 EM52000031 EM52000071

Power system

Type V-Ph-Hz 220-240V~ 50Hz 220-240V~ 50Hz 220-240V~ 50Hz 220-240V~ 50Hz

Input W 100 100 150 140

Air ow volume

High

CFM 500 600 735 840

m3/h 850 1020 1250 1430

Medium

CFM 375 464 606 802

m3/h 638 789 1030 1363

Low

CFM 303 363 538 705

m3/h 515 617 914 1198

Capacity

Cooling W 4640 5400 6700 7740

Heating W 7500 9100 10500 11200

Electric heater rated power W 1400 1400 1400 1400

Water system

Water ow

volume m3/h 0.81 0.95 1.18 1.36

Pressure

drop kPa 15 25 25 25

Sound pressure level dB(A) 46 46 47 52

Coil

Type - Aluminum n-

copper tube

Aluminum n-

copper tube

Aluminum n-

copper tube

Aluminum n-

copper tube

Operating

pressure MPa ≤1.6MPa ≤1.6MPa ≤1.6MPa ≤1.6MPa

Motor

Type - FN35B FN35B FN35B FN50T

Capacitor µF 2.5 3.5 3.5 2.5

Connection pipe size

Water inlet

&outlet inch G3/4" G3/4" G3/4" G3/4"

Condensing

water drain mm 32 32 32 32

Outline dimension

(W×D×H)

Body mm 840×840×240 840×840×240 840×840×240 840×840×320

Panel mm 960×960×60 960×960×60 960×960×60 960×960×60

Package dimension

(W×D×H)

Body mm 960×960×310 960×960×310 960×960×310 960×960×394

Panel mm 1040×1025×115 1040×1025×115 1040×1025×115 1040×1025×115

Net weight

Body kg 30 30 30 38

Panel kg 6.5 6.5 6.5 6.5

Gross weight

Body kg 38 38 38 46

Panel kg 10 10 10 10

Loading quantity

20'GP 61 61 51 51

40'GP 116 116 116 93

40'HQ 133 133 133 112

Wired remote controller Z5K351/Z4E351B Z5K351/Z4E351B Z5K351/Z4E351B Z5K351/Z4E351B

Wireless remote controller YB1F2(X-FAN) YB1F2(X-FAN) YB1F2(X-FAN) YB1F2(X-FAN)

Cassette Type Fan Coil

Unit Service Manual

PRODUCT

Model FP-16XD-E FP-18XD-E

Code EM52000081 EM52000041

Power system

Type V-Ph-Hz 220-240V~ 50Hz 220-240V~ 50Hz

Input W 160 155

Air ow volume

High

CFM 965 1059

m3/h 1640 1800

Medium

CFM 853 1035

m3/h 1450 1760

Low

CFM 781 932

m3/h 1328 1584

Capacity

Cooling W 8700 9600

Heating W 12900 14600

Electric heater rated power W 1400 1400

Water system

Water ow volume m3/h 1.53 1.68

Pressure drop kPa 27 29

Sound pressure level dB(A) 53 54

Coil

Type - Aluminum n-copper tube Aluminum n-copper tube

Operating pressure MPa ≤1.6MPa ≤1.6MPa

Motor

Type - FN50T FN50T

Capacitor µF 4.5 4.5

Connection pipe size

Water inlet &outlet inch G3/4" G3/4"

Condensing water drain mm 32 32

Outline dimension

(W×D×H)

Body mm 840×840×320 840×840×320

Panel mm 960×960×60 960×960×60

Package dimension

(W×D×H)

Body mm 960×960×394 960×960×394

Panel mm 1040×1025×115 1040×1025×115

Net weight

Body kg 38 38

Panel kg 6.5 6.5

Gross weight

Body kg 46 46

Panel kg 10 10

Loading quantity

20'GP 51 51

40'GP 93 93

40'HQ 112 112

Wired remote controller Z5K351/Z4E351B Z5K351/Z4E351B

Wireless remote controller YB1F2(X-FAN) YB1F2(X-FAN)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Gree Climatiseur

Gree

Gree GWH24YE-S6DBA2A Manuel utilisateur

Gree

Gree Terra GWH09TB-D3DNA1A Manuel utilisateur

Gree

Gree GWCN1407X2B8NK1BA Manuel utilisateur

Gree

Gree GWH18TC-K3DNA1B/I Manuel utilisateur

Gree

Gree TF04A Panel Manuel utilisateur

Gree

Gree Vireo VIR09HP115V1A Manuel utilisateur

Gree

Gree GMV-ND22PLS/A-T Manuel utilisateur

Gree

Gree GJC12BL-A3RNC5A Manuel utilisateur

Gree

Gree GWH09TB-S3DNA1D/I Manuel utilisateur

Gree

Gree GWH18RC-K3DNA3G Manuel utilisateur

Gree

Gree GWH09UC-D3DNA4AGWH12UC-D3DNA4AGWH18UC-D3DNA4A Manuel utilisateur

Gree

Gree GSA228XA Manuel utilisateur

Gree

Gree SAP18HP230V1AH Manuel

Gree

Gree GWH12RB-K3DNA5G Manuel utilisateur

Gree

Gree GWC12NC-K3NNA3E Manuel utilisateur

Gree

Gree GISF209BXAE Manuel utilisateur

Gree

Gree GWH09AB-D3DNA1D/I Manuel utilisateur

Gree

Gree GJC08BK-A6NRNE2D Manuel utilisateur

Gree

Gree GWH09QB-K3DNA6G Manuel utilisateur

Gree

Gree SUPER+ MULTI ULTRA Series Manuel utilisateur

Gree

Gree GWH09NA-K3NNB1C Manuel utilisateur

Gree

Gree GWH07ACC-K6DNA1A/I Manuel utilisateur

Gree

Gree Split Air Conditioner Manuel utilisateur

Gree

Gree GJC09AF-E6RNB3A Manuel utilisateur

Manuels Climatiseur populaires d'autres marques

Spheros

Spheros CC 355 Manuel utilisateur

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manuel utilisateur

Panasonic

Panasonic CS-E12HKEW Manuel utilisateur

nedis

nedis ACMB1WT7 Manuel utilisateur

Samsung

Samsung AR KV Series Mode d’emploi

Daikin

Daikin FCFV50A Manuel utilisateur

Fujitsu

Fujitsu Inverter ASBA30JFC Manuel utilisateur

Toshiba

Toshiba RAS-M10SMUV-E Manuel utilisateur

Daikin

Daikin FXLQ20MAVE Manuel utilisateur

Hitachi

Hitachi RAS-E24CAK Manuel utilisateur

CIAT

CIAT Magister 2 Series Mode d’emploi

Bestron

Bestron AAC6000 Manuel utilisateur

Hisense

Hisense 7K Manuel technique

Frigidaire

Frigidaire FFRE0533S1E0 Manuel utilisateur

Samsung

Samsung AS09HM3N Manuel utilisateur

Frigidaire

Frigidaire CRA073PU11 Manuel du propriétaire

Soleus Air

Soleus Air GB-PAC-08E4 Manuel utilisateur

McQuay

McQuay MCK020A Manuel utilisateur
