Grasslin Feeling Manuel utilisateur

feeling

feeling rf

DBedienungsanleitung

Operating Manual

Mode d‘emploi

Instruzioni per l‘uso

Instrucciones de uso

Manual de instruções

Bedieningshandleiding

Návod k obsluze

122

162

202

242

282

Table of contents

Usermenu/Conguration ................... 76

Installation menu............................... 77

RF commissioning ............................. 79

Safety instructions............................. 43

Product details................................... 44

Installation and assembly................... 48

Operating and adjustment.................. 52

Conguration..................................... 55

Initial start-up.................................... 56

Settings............................................. 62

Operating modes ............................... 66

Operating status ................................ 73

GB 43

Safety instructions

Danger from electric shock!

The connection and installation of electrical devices may only be carried out

byaqualiedelectrician.

DANGER

It is imperative to observe the generally applicable safety measures, e.g. before starting any work

on the appliance, switch off power supply and secure against switching on.

Interventions in and changes to the device result in the voiding of the warranty claim.

Observe your national regulations and the respective safety provisions.

feeling rf

A B

Proper use

feeling/feeling rf are a new generation of chrono-

thermostats with new modern design. The large

LCD display enables the display of information

and control of all integrated functions. The device

may only be used in combination with your

heating system.

Assembly description

AMoveable sliding cover

BKeys for manual override function

CWindow

DKeyboard

EBattery compartment

FDisplay

Product details

GB 45

Technical data – Relay version

Power supply: 2 x 1.5 V AA LR6 alkaline batteries

Batteryservicelife: 2years(dependingonswitchingfrequency) 

Switchingoutput: SPDT(potential-free) 

Switchingcapacity: 8(3)A250VAC 

Wire cross-section to relay terminals: 0.5 mm2– 1.5 mm2

Roomtemperaturedisplayresolution:0.1ºC 

Temperaturesettingdisplay: Program: +5ºC…+32ºC(0.5ºCsteps) 

 Frostprotection: 5ºC(adjustable3ºC…7ºC)

Time setting resolution: Time of day: 1 minute

Program: 30 minutes

Temperature measurement

(heatingsystem): 3K/hour 

Programming: weekly program with up to 48 time and temperature programs

changes

Pre-programmedprograms: 4+1user-dened 

Protection class/type: II/IP40

Operatingtemperaturerange: Max.45ºC 

Operating humidity range: 10% to 90% RH non-condensing

DimensionsHxWxD(mm): 87x154x27

Technical data – RF Set, Transmitter

Power supply: 2 x 1.5 V AA LR6 alkaline batteries

Batteryservicelife: 2years(dependingonswitchingfrequency)

Roomtemperaturedisplayresolution:0.1ºC 

Temperaturesettingdisplay: Program: +5ºC…+32ºC(0.5ºCsteps) 

 Frostprotection: 5ºC(adjustable3ºC…7ºC)

Time setting resolution: Time of day: 1 minute

Program: 30 minutes

Temperature measurement

(heatingsystem): 3K/hour 

Programming: weekly program with up to 48 time and temperature programs

changes

Pre-programmedprograms: 4+1user-dened 

RF signal: 868.3 MHz

RFsignalrange: Indoor30m(2walls+1ceiling)

Protection class/type: II/IP40

Operatingtemperaturerange: Max.45ºC 

Operating humidity range: 10% to 90% RH non-condensing

DimensionsHxWxD(mm): 87x154x27

GB 47

Technical data – RF Set, Receiver

Power supply: 230 V +/-10% 50-60 Hz

Switchingoutput: SPDT(potential-free) 

Switchingcapacity: 5(1)A250VAC 

Wire section to relay terminals: 0.5 mm2– 1.5 mm2

RF signal: 868.3 MHz

RFsignalrange: Indoor30m(2walls+1ceiling) 

Protection class/type: II/IP20

Operatingtemperaturerange: Max.45ºC 

Operating humidity range: 10% to 90% RH non-condensing

DimensionsHxWxD(mm): 87x108x37   

1.5 m

Installation and assembly

General information

GB 49

Open housing Wall mounting

For wired and wireless version.

Connection

For wireless connection, please refer to chapter

RF commissioning.

123

Wiring diagram

Wiring example: Motorized valve

Wiring example: Boiler/heater

1 2 3

230 V~

open

Valve

1 2 3

Boiler/heater

230 V AC
