To Ensure Safe and

Correct Use

P. 5

P.14

Usage Precautions for

Media Used for Cutting

P.15

When You Have

Problems…

Let’s try out

the Craft ROBO

• To ensure safe and correct use of your Craft ROBO, read this Guide thoroughly before use.

• After having read this Guide, keep it in a handy location for quick reference as needed.

• Do not permit small children to touch the Craft ROBO.

• The following describes important points for safe operation. Please be sure to observe them strictly.

To promote safe and accurate use of the Craft ROBO as well as to

prevent human injury and property damage, safety precautions provided

in this guide are ranked into the three categories described below. Be

sure you understand the difference between each of the categories.

: This category provides information that, if ignored, is

highly likely to cause fatal or serious injury to the

operator.

: This category provides information that, if ignored, is

likely to cause fatal or serious injury to the operator.

: This category provides information that, if ignored,

could cause injury to the operator or physical

damage to the Craft ROBO.

Conventions Used in This Guide Description of Safety Symbols

DANGER

WARNING

CAUTION

The symbol indicates information that requires careful attention

(which includes warnings). The point requiring attention is

described by an illustration or text within or next to the symbol.

The symbol indicates action that is prohibited. Such prohibited

action is described by an illustration or text within or next to the

symbol.

The symbol indicates action that must be performed. Such

imperative action is described by an illustration or text within or

next to the symbol.

To Ensure Safe and Correct Use

WARNING

Safety Precautions

During a cutting or plotting operation, do not

touch the writing panel or moving parts such

as the carriage.

• Such action may cause human injury.

Do not disassemble, repair, or remodel the

Craft ROBO.

• Such action may cause electrical shock or a fire

hazard due to current leakage.

• Contact with the high-voltage parts within the

Craft ROBO may cause electrical shock.

• If the Craft ROBO requires repair, contact your

sales representative or nearest Graphtec

vendor.

Keep your hands, hair, etc. away from the

writing panel and moving parts such as the

carriage even if the Craft ROBO is stopped,

because it may suddenly start moving when

data is received.

• Such action may cause human injury.

Do not connect the Craft ROBO to a

non-rated power supply.

• Use of a different supply voltage may result in

electrical shock or a fire hazard due to current

leakage.

Do not allow dust or metallic matter to adhere

to the power plug.

• A dirty power plug may result in electrical shock

or a fire hazard due to current leakage.

Do not use the power cord or AC adapter if it

is damaged.

• Use of a damaged power cord or AC adapter

may result in electrical shock or a fire hazard

due to current leakage.

• Replace the power cord or AC adapter with a

new one.

Be careful when handling the blade, blade

holder.

• Touching the blade with your bare hand may

cause injury.

• During a cutting operation, keep away from the

blade, blade holder.

Only use the AC adapter that was supplied as

a standard accessory.

• Use of any other AC adapter may cause

malfunctions or result in electrical shock or a

fire hazard.

Do not use the Craft ROBO in a location

where it will be exposed to water, rain or

snow.

• Such location may cause electrical shock or a

fire hazard due to current leakage.

If the Craft ROBO generates smoke,

is too hot, emits a strange odor, or

otherwise functions abnormally, do not

continue using it. Unplug the AC adapter’s

power cord from the electrical socket.

• Use of the Craft ROBO in such status may result in a fire

hazard or electrical shock.

• After confirming that smoke is no longer being generated,

contact your sales representative or nearest Graphtec vendor

to request repair.

• Never try to perform

repair yourself.

Repair work by

inexperienced personnel

is extremely dangerous.

Do not touch

Keep your distance

No disassembly

Prohibited

Avoid water

Beware of electrical shock

Rated

power

supply

Unplug the power

cord from the socket

Prohibited

Beware of electrical shock

Avoid contact

Safety Precautions

Do not use or store the Craft ROBO in a

location exposed to direct sunlight or the

direct draft of an air conditioner or heater.

• Such location may impair the performance of

the Craft ROBO.

Do not place any receptacle containing water

or other fluid on top of the Craft ROBO.

• Fluid falling inside the Craft ROBO may cause

electrical shock or a fire hazard due to current

leakage.

Do not use the Craft ROBO in an excessively

dusty or humid location.

• Such location may impair the performance of

the Craft ROBO.

Do not use the Craft ROBO in a location

subject to excessive mechanical vibration or

electrical noise.

• Such location may impair the performance of

the Craft ROBO.

Do not attempt to lubricate the Craft ROBO’s

mechanisms.

• Such action may cause it to break down.

Do not clean the Craft ROBO using a volatile

solvent such as thinner or benzine.

• Such action may impair its performance.

During cutting or plotting, provide enough

space around the Craft ROBO so that the

loaded sheet will not hit any objects in its

vicinity.

• Such contact may cause cutting or plotting to

go out of alignment.

When using the blade, blade holder, make

sure that the correct blade adjustment cap for

the selected Media Type is installed.

• An overly extended blade will damage the

cutting mat and adversely affect the cutting

quality.

Move the pen carriage slowly when moving it

manually in order to load the sheet for cutting

or for other reasons.

• Moving it quickly may damage the Craft ROBO.

When using indoor lighting such as a

fluorescent lamp or an electrical lamp,

provide a distance of at least one meter

between the Craft ROBO and the light source.

• Closer proximity of such a light source may

cause the sensors to malfunction.

When disconnecting the power cord or an

interface cable, do not pull on the cord/cable.

• Such action will damage the cord/cable,

resulting in a fire hazard or electrical shock. Be

sure to hold the power cord’s plug or the

interface cable’s connector.

If water or foreign matter enters inside the

Craft ROBO, do not continue using it. Turn off

its power and unplug its power cord from the

electrical socket.

• Use of the Craft ROBO in such status may

result in electrical shock or a fire hazard due to

current leakage.

• Contact your sales representative or nearest

Graphtec vendor to request repair.

CAUTION

To Ensure Safe and Correct Use

Prohibited

Avoid water

Beware of electrical shock

Unplug the power

cord from the socket

Prohibited

Contact prohibited

By using the Media Trial Kit, you will be able to learn the basic operations in a short time.

Make

Something

Now!!

Choose an

Application

To Make a Pop-up Greeting Card

To Cut a Vinyl Sticker

Before using the Media Trial Kit, please follow the instructions in the Quick Start Instruction Sheet to install the Craft ROBO driver,

the Craft ROBO Controller, and the ROBO Master.

Also, make sure that the Craft ROBO is connected to your PC.

Explanations for two

different applications

are provided:

To Make a Pop-up Greeting

Card and To Cut a Vinyl

Sticker. Select the

application that best suits

your purpose.

Examples

Application

P. 6

Let’s try out the Craft ROBO

Application

Create a vinyl sticker

Create a greeting card

P.10

Let’s try out the Craft ROBO

To import an image that you have

already captured, click the “Image

Import” button and select the

image file.When you have

returned to the Create Drawing

window, left-click at the position

where you wish the image to be

placed. You can affix any photo

that you have to the pop-up. Or,

you can cut an original photo or

illustration on the Craft ROBO and

then affix it to the pop-up. Sample

images are available in the CD-ROM supplied with the Craft ROBO.

Click the Output Settings button

to display the Output

Settings window.

Select the printer you use in the

Printer box, and make sure that

Graphtec Craft ROBO has been

specified in the Craft ROBO box.

Click “Print Settings” and

uncheck the “Print Cut Lines”

checkbox.

Click the [OK] button to return to

the Create Drawing window.

Click [File]➞[Open] in that order

and select [New Baby pop-up

greeting card (for Practice).GSD].

The file is located in the Samples

folder under the folder you

selected when you installed

ROBO Master. It is usually

located in the following folder:

Program Files\ROBO Master\Samples

Note:The cut line for the pop-up card

has already been specified, and

so there is no need to make any

settings or to change them.

Input a character string here

and then click the [OK] button.

Click the Text tool button to

display the Text Settings window.

Set the font and text size and

then enter a name in the

character string entry box.

Click the [OK] button to return to

the Create Drawing window, and

left-click at the position where

you wish the name to be placed.

Output Settings button

Select Craft ROBO

Click

Enter a name and

then click [OK]

Image import button

Import a photo or an image and

then position it

Click with the mouse at the position where you wish the name to be placed

Check this

checkbox

(Landscape)

Click to remove the check mark

HINT

To change the color of the

characters, click the Line Type

button and then click the

[Change] button in the window displayed.

To Make a Pop-up Greeting Card

11Launch ROBO Master

Load the Pop-up Card

template

3Make the Print Settings 4Create a layout using text and images

1Launch

ROBO Master

Click the desktop icon to launch

[ROBO Master].

ROBO Master

shortcut icon

Application

Let’s try out the Craft ROBO

Click the Output to Craft ROBO button , confirm that the

driver name reads Graphtec Craft ROBO, and then click the

[OK] button to start the Craft ROBO Controller.

Load the [Card without Craft Paper Backing]

sheet from your Media Trial Kit in your

printer.

Click the Output to Printer button to

display the Output to Printer window.

Check that your printer is displayed in the

printer box and then click the [OK] button to

start printing.

Click the Preview buttons to display the Preview window.

Use the Change Display button to display the print data and the

cut data separately, or superimposed.

After checking the data displayed, click the Close button to

return to your usual Create Drawing window.

ROBO Master window

Preview button

Preview of cut data

and print data

Preview of cut data

Preview of print data

Printer output button

Select “Card without Craft Paper Backing” in the Media Type

box.Click the [Next] button to proceed to the “Blade cap

adjustment” step. Install the yellow cap displayed on the

screen to the blade holder tip.

Select “Card without

Craft Paper Backing”

Click

Output to Craft ROBO button

22Print the data you have created and load the sheet in the Craft ROBO

1Check the Cut line and Print data 2

Print the data you have created

Specify the cutting conditions

Preview window

Change display

buttons

Close button

Let’s try out the Craft ROBO

33Make preparations for cutting

Press the Card without Craft Paper

Backing onto the carrier sheet.

HINT

Standby switch

Press the standby switch on the

Craft ROBO, and confirm that the

LED lamp on the switch is lit (blue).

Align the left edge of the sheet

with the vertical guideline indented

on the front guide. While making

sure that the sheet is straight, turn

the feed knob until the top edge of

the sheet touches both pinch

rollers.

Peel off both the inside liner and the liner

strips on both sides from the carrier sheet

so that the entire adhesive surface is

visible.

Press the Card without Craft Paper

Backing onto the adhesive surface of the

carrier sheet, making sure that the edges

of the card are parallel to the edges of the

carrier sheet.

(When pressing the card onto the adhesive surface,

be careful not to cause air bubbles or wrinkles in the

card.)

Close the top cover.

Click the [Next] button to proceed

to the “Registration Marks” step.

Click the [Next] button again to

proceed to the “Start cutting” step.

Load the printed sheet

following the printed

hint line "Feed this side

first".

HINT

Blade holder

Blade adjustment cap

Blade

Liner

Peel off the inside liner and the

liner strips on both sides

Carrier sheet

Adhesive surface

Card without

Craft Paper Backing

Carrier sheet

cap media

Protruding blade length

(approx.)

Blue For thin film 0.1mm

Yellow

For thick film, thin paper

0.2mm

Red For thick paper 0.3mm

such as a postcard

Lock lever

OPEN CLOSE Blade holder

Upper surface of blade holder

Holder protrusion

Turn to this position

Pinch rollers

Guideline

Front

2Load the printed sheet in your Craft ROBO and mount the blade, blade holder

Let’s try out the Craft ROBO

Turn the lock lever to the left

(OPEN direction) to loosen the

clamp bracket.

Check that the yellow blade

adjustment cap has been attached

to the blade holder, and then

mount the blade holder in the Craft

ROBO. Turn the protrusion on the

holder 90 degrees to the right so

that it fits against the protrusion on

the clamp bracket. Firmly insert the

blade holder in the clamp bracket

and then turn the lock lever to the

right (CLOSE direction) to tighten

the clamp bracket.

Click the “Next” button. The

“Design Orientation” screen is

displayed. Click the “Next” button

once again. The “Load Media”

screen is displayed.

Click the [OK] button to start cutting.

Do not touch the Craft ROBO during the cutting

operation.

When cutting has been completed, remove the

sheet. Turn the feed knob to remove it.

44Perform Cutting

1Perform cutting 2Finished!

[OK] button

Click

Click the [Cut...] button. The registration marks are

read automatically. Do not touch the printed sheet

during the reading operation, as this will affect the

accuracy.

3Perform Auto Registration

Mark Reading

HINT

If a “Registration Mark Reading Failure”

error message is displayed, please refer

to the Craft ROBO User’s Manual

(CD-ROM).

33Make preparations for cutting

Let’s try out the Craft ROBO

The pop-up card is complete when you assemble it.

Click the Output Settings button to

display the Output Settings window.

Make sure that Graphtec Craft ROBO has

been specified in the Craft ROBO box.

Click “Print Settings” and uncheck the “Print

Cut Lines” checkbox.

Click the [OK] button to return to the Create

Drawing window.

Click the New button to display the

Document Settings window. Select “ISO A4”

for Document Size and “Landscape” for

Orientation, and then click the [OK] button.

Uncheck the “Use Registration Marks”

checkbox.

A vinyl sticker is a self-adhesive, single-color

sheet of film. Logos and text can be cut out of

the sheet for use on car windows or as store

signs, for example.

Here you can enjoy cutting out your own

name or creating your own original logo, and

then affixing it to a favorite item.

Output Settings button

Select

Craft ROBO

Click

Check

this checkbox

(Landscape)

Click to remove the check mark

Landscape

New

For a name plate

Original Logo

To Cut a Vinyl Sticker

Application

How do I use it?

What is a vinyl sticker?

11Launch ROBO Master

2Set the Document Size 3Make the Print Settings

1Launch ROBO Master

Click the desktop icon to launch

[ROBO Master].

ROBO Master

shortcut icon

Let’s try out the Craft ROBO

Autres manuels pour Craft ROBO CC200

Table des matières

Autres manuels GRAPHTEC Traceur

GRAPHTEC

GRAPHTEC CUTTING PRO FC2250 Series Manuel utilisateur

GRAPHTEC

GRAPHTEC FCX2000 SERIES Guide de l'utilisateur

GRAPHTEC

GRAPHTEC CE7000 Series Manuel utilisateur

GRAPHTEC

GRAPHTEC CE3000-40 Manuel utilisateur

GRAPHTEC

GRAPHTEC CE6000 SERIES Manuel utilisateur

GRAPHTEC

GRAPHTEC FC3100-120 Manuel utilisateur

GRAPHTEC

GRAPHTEC CE5000-60 Manuel utilisateur

GRAPHTEC

GRAPHTEC CE2000-60 Manuel utilisateur

GRAPHTEC

GRAPHTEC FC8000-60 Manuel utilisateur

GRAPHTEC

GRAPHTEC FC8000 Series Manuel utilisateur

GRAPHTEC

GRAPHTEC LABERLROBO DLC1000 Manuel utilisateur

GRAPHTEC

GRAPHTEC FC4500 Manuel utilisateur

GRAPHTEC

GRAPHTEC CE7000-130AP Guide de l'utilisateur

GRAPHTEC

GRAPHTEC Cutting PRO FC2230 Series Manuel utilisateur

GRAPHTEC

GRAPHTEC FC9000 Series Guide de l'utilisateur

GRAPHTEC

GRAPHTEC FC4500 Manuel utilisateur

GRAPHTEC

GRAPHTEC FC8000 Series Manuel utilisateur

GRAPHTEC

GRAPHTEC CE5000 SERIES Manuel utilisateur

GRAPHTEC

GRAPHTEC Craft ROBO CC200 Manuel utilisateur

GRAPHTEC

GRAPHTEC CE6000 SERIES Instructions d'utilisation et de sécurité

GRAPHTEC

GRAPHTEC CE LITE-50 Manuel utilisateur

GRAPHTEC

GRAPHTEC Craft ROBO CC100 Manuel utilisateur

GRAPHTEC

GRAPHTEC Craft ROBO CC100 Guide de l'utilisateur

GRAPHTEC

GRAPHTEC FC8600 SERIES Guide de l'utilisateur

Manuels Traceur populaires d'autres marques

MUTOH

MUTOH Kona 760 Manuel utilisateur

HP 7475a Manuel utilisateur

Vulcan-Hart

Vulcan-Hart FC-500VC Manuel utilisateur

Roland

Roland TrueVIS VG-640 Manuel du propriétaire

Furuno

Furuno RP-180 Manuel utilisateur

Roland

Roland VersaCamm SP-540V Manuel utilisateur

MIMAKI

MIMAKI CF2 Series Manuel utilisateur

Ioline

Ioline Summit Manuel utilisateur

Summa

Summa S CLASS Manuel utilisateur

Gerber Technology

Gerber Technology GERBERplotter MP Series Manuel utilisateur

Furuno

Furuno RP-17 Manuel utilisateur

HP 7470A Manuel utilisateur

SII

SII LP-1010 Manuel utilisateur

Great Computer

Great Computer JII-61 Manuel utilisateur

Roland

Roland VersaUv LEF - 12i Manuel utilisateur

Lectra

Lectra Alys 120 Manuel utilisateur

MUTOH

MUTOH Ultima SC-850D Manuel utilisateur

Skycut

Skycut D Series Manuel utilisateur
