Grandstream Networks, Inc.

WP810/WP822/WP825 Series

Cordless Wi-Fi IP Phone

User Guide

WP810/WP822/WP825 - User Guide

WELCOME

The WP810 is a portable Wi-Fi IP phone designed to suit a variety of enterprises and vertical market applications, including

retail, logistics, medical and security. This basic cordless Wi-Fi phone comes equipped with integrated dual-band

802.11a/b/g/n/ac Wi-Fi, an advanced antenna design and roaming support. By adding 6-hour talk time and HD voice with

dual-MICs, the WP810 offers an affordable option and comes equipped with a combination of features, mobility and

durability to suit all portable telephony needs.

The WP822 is a portable Wi-Fi IP phone designed to suit a variety of enterprises and vertical market applications, including

retail, logistics, medical and security. This business-grade Wi-Fi phone comes equipped with integrated dual-band

802.11a/b/g/n/ac Wi-Fi, an advanced antenna design and roaming

support. By adding 8-hour talk time, HD voice with dual-MICs, and a configurable push-to-talk button, the WP822 comes

equipped with a combination of features, mobility and durability to suit all portable telephony needs.

The WP825 is a ruggedized portable Wi-Fi IP phone designed to suit a variety of enterprises and vertical market applications,

including retail, logistics, medical and security. This cordless Wi-Fi phone comes equipped with integrated dual-band

802.11a/b/g/n/ac Wi-Fi, an advanced antenna design and roaming

support. By adding 8-hour talk time and HD voice with dual-MICs, the WP825 offers an affordable option and comes

equipped with a combination of features, mobility and durability to suit all portable telephony needs.

PRODUCT OVERVIEW

Feature Highlights

The following table contain the major features of the WP810, WP822 and WP825:

Contacts Display the list of the registered contacts and also the groups contacts with the ability of searching, adding or

editing the entries and also deleting the selected contacts.

Call History Display the call history:Missed Calls,Accepted Calls,Outgoing CallsorAll Calls. You can add contacts

toShared Contactsdirectly from call logs.

SMS SMSstands for Short Message Service and referred to as a “text message”. With aSMS, you can send a

message by pressing“New Message”of up to 160 characters to another device or check the received ones.

Voice Mail

Select:Play voice mail messages received.

Note: Voicemail ID needs to be conﬁgured, otherwise, “select” softkeys will open conﬁguration settings.

Diagnostics

●LCD Test

●LCD off

●LED Test

●Keypad Test

●Audio Loopback

●Proximity Sensor

●Vibration

●Verify Certiﬁcate

Settings

●Account: Conﬁgure/View SIP accounts settings and account ringtone.

●Call settings:Conﬁgure the account auto answer, call forward, DND and speed dial settings.

Table 1: WP810/WP822/WP825 Features at a Glance

Technical Specifications

The following table resumes all the technical specifications including the protocols/standards supported, voice codecs,

telephony features, languages and upgrade/provisioning settings.

WP810

●Network Settings:Conﬁgure the networks settings including Wi-Fi settings, and additional networks

settings.

●BasicSettings:Conﬁgure the basic settings including voice settings, display settings, Gestures and button

customization, language settings and date/time settings.

●Adv.Settings:Conﬁgure the advanced settings including system upgrade, PTT/Paging settings, system

security settings, syslog settings and factory reset / reboot.

Status

Displays account status, system info, Network status and network statistics

●Account status

●System Info:Press to enter the sub menu for Running memory, Storage status, MAC address, System

version, Recovery version, U-boot version, Kernel version, Hardware version, PN number, Country code

and Running time.

●Network status: Press to enter the sub menu for MAC address, IP setting information (DHCP/Static IP),

IPv4 address, IPv6 address, Subnet Mask, Gateway, DNS server.

●Network Statistics: Press to enter the sub menu for Network SSID, BSSID, IP address, Signal strength,

Connection speed, Channel, Frequency, Tx packets, Tx error packets, Tx error rate, Tx drop packets, Tx

drop rate, Rx packets, Rx error packets, Rx error rate, Rx drop packets, Rx drop rate.
