Grandstream Networks GXP2160 Manuel utilisateur

Grandstream Networks, Inc.

126 Brookline Ave, 3rd Floor

Boston, MA 02215

Voice: (617) 566-9300

Fax: (617) 249-1987

www.grandstream.com

For Warranty and RMA information, please visit www.grandstream.com

GXP2160 Enterprise IP Phone

Quick Installation Guide

English...............................................................................1

简体中文.....................................................................7

Español............................................................................13

Français...........................................................................19

Deutsch............................................................................25

Italiano.............................................................................31

Русскй.............................................................................37

Português....................................................................... 43

Polski............................................................................. 49

Content

3 4

CONNECTING THE PHONE:

PHONE SETUP:

PC Port LAN Port Power Headset Port Handset Port

Installing the Phone (Phone Stand):

For installing the phone on the table with the phone stand, attach the phone stand

to the bottom othe phone where there is a slot or the phone stand (upper part,

bottom part).

Installing the Phone (Wall Mount):

1. Attach the wall mount to the slot on the back othe phone.

2. Attach the phone to the wall via the wall mount hole.

3. Pull out the tab rom the handset cradle (See gure below).

4. Rotate the tab and plug it back into the slot with the extension up to hold the

handset while the phone is mounted on the wall (See gure below).

Tab with extension up

Handset rest

Tab with extension down

Slots for the

wall mount and

phone stand

USB Port

Installing BLF Paper Label:

1. Install the paper label under the plastic notches on the phone and gently lay the

paper down on the phone surace.

2. Install the plastic cover over the paper label by inserting the cover under the

plastic notches on the phone.

Label

Cover

GRANDSTREAM GXP2160

5 6

Tips For Using the Keypad:

PHONE CONFIGURATION:

Confgure the GXP2160 using Web Browser:

1. To access the MENU, press the round MENU button.

2. Navigate the menu by using the UP/DOWN and LEFT/RIGHT buttons.

3. Press the round MENU button to conrm a menu selection.

4. The phone automatically exits MENU mode with an incoming call, the phone

goes o-hook or the MENU mode is let idle or 60 seconds.

1. Ensure your phone is powered up and connected to the Internet.

2. Press the UP button to see the IP address.

3. Type the phone’s IP address in your PC browser (See gure on right).

4. The deault administrator username and password are “admin”; the deault end-

user username is “user“ and the password is “123”.

Confgure the GXP2160 using the Keypad:

1. Make sure the phone is idle.

2. Press the MENU button to access the keypad MENU to congure the phone.

3. Select MENU-> Phone-> SIP-> Account to congure settings or SIP Proxy,

Outbound Proxy, SIP User ID, SIP Auth ID and SIP Password.

4. Follow MENU options to congure the basic eatures othe phone. For ex-

ample: the IP address iusing a static IP. For details, please check GXP2160

User Manual.

5. Please contact your ITSP (Internet Telephony Service Provider) or additional

settings that may be necessary to congure the phone.

GRANDSTREAM GXP2160

Line keys

Soft keys

Message Waiting

Indicator

Multi-Purpose

keys

Message

Contacts

Transfer

Hold

Headset

Conerence

Mute

Menu/OK Key

Standard Keypad

Navigation keys

Send Volume Speaker

Note: For the detailed user manual, please download rom:

http://www.grandstream.com/support

This product is covered by one or more othe U.S. patents (and any oreign patent

counterparts thereto) identied at www.cmspatents.com.

To setup the GXP2160, ollow the steps below:

1. Connect the handset and main phone case with the phone cord.

2. Connect the LAN port othe phone to the RJ-45 socket oa hub/switch or a

router (LAN side othe router) using the Ethernet cable.

3. Connect the 12V DC output plug to the power jack on the phone; plug the power

adapter into an electrical outlet.

4. The LCD will display provisioning or rmware upgrade inormation. Beore con-

tinuing, please wait or the date/time display to show up.

5. Using the phone embedded web server or keypad conguration menu, you can

urther congure the phone using either a static IP or DHCP.
