Key points

•New 0,95" 1080p DLP® chipset

by Texas Instruments

•1920 x 1080 pixel HDTV resolution

•Proprietary SIM2 ALPHA PATH™

light engine

•New 7-segment color wheel

(RGBRGB + NDF Neutral Density

Filter)

•2 HDMI™ HDCP inputs

•Contrast ratio >5000:1

•Lamp: 200W (dimmed)

•SIM2 Live Colors Management and

Gamma Functions

•Intelligent memory functions

•New Dynamic Noise Reduction and

Spatial Noise Reduction

SIM2 Multimedia presents the latest

addition to: their award-winning

Grand Cinema™ HT range:

the all-new Grand Cinema HT3000.

This premier single chip projector

offers true, uncompressed

1920x1080 HDTV

Resolution, thanks to a new 0,95"

1080p DLP® chipset from Texas

Instruments.

Combining this new chipset with

full 10 bit video processing, SIM2’s

ALPHA PATH™ light engine and

Live Colors Management system,

HT3000 is able to reach a new level

of cinematic realism in single chip

projection.

This is achieved in typical SIM2 style

through a balanced design ethos:

a fined tuned system will always

deliver the best results.

HT3000 has a wide range of both

analogue and digital video inputs,

including two HDCP enabled HDMI™

sockets, ensuring compatibility with

the vast array of today’s video

sources (including HD).

Taking styling cues from the C3X

series, HT3000 sports an elegant

Giorgio Revoldini designed cabinet

in SiM2’s signature Gunmetal finish.

SIM2 Grand Cinema™HT3000

The new benchmark for future standards

in single-chip front projection Grand Cinema™ HT3000:

Technical Specifications

LIGHT ENGINE

Technology: 1 chip DMD 0,95” 1080p DarkChip3™

Resolution: 1920 x 1080 pixels

Color Wheel: 7 segment (RGBRGB+NDF Neutral

Density Filter)

Lamp power & life time*: 200W dimmed, 4000 hours*

INSTALLATION

Throw ratio: 1,5-2,0:1

Lens shift: V+/-6°

Digital keystone adjustment: V+/-18°

Picture size (inches diagonal): 50-300

Aspect ratio: 4:3, 16:9 Anamorphic, LetterBox,

panoramic, pixel to pixel + 3 custom-user adjustments

ELECTRONICS

Horizontal & vertical scan freq.: 15-80kHz/48-100Hz

Video and Graphic standards: PAL (B,G,H,I,M,N,60);

SECAM; NTSC 3,58; NTSC 4,43 automatically

selected; HDTV: ATSC (480p, 720p, 1080i, 1080p); EU

576p + 1080i 50Hz; PC graphic: VGA, SVGA, XGA,

SXGA, UXGA

Contrast ratio (Full ON/ Full OFF): >5000:1

Format Board: 10 Bit

Video processor: built in

Special video adjustments: Dynamic Noise Reduction,

Spatial Noise Reduction, Fleshtone Regulation

Other special adjustments: Memories/Overscan, Live

Colors Management (LCM) and Gamma Functions

INPUTS/OUTPUTS

1 x Composite Video (RCA)

1x S-Video (mini Din 4 pin)

1 x RGBS/YCrCb (4x RCA)

1 x RGBHV/YCrCb (1x VGA)

2 x HDMI – HDCP compliant

1 x OUT Digital Audio (Toslink)

1 x RS232 (D-Sub 9 pin)

1 x Input External IR sensor

2 x OUT 12V 100mA (via Jack)

GENERAL SPECIFICATIONS

Software control: upgradable via RS232 serial

interface

Mains voltage range: 100-240Vac ±10% (48/62Hz)

Weight: 11 Kg (24,2 lbs)

Dimensions (WxHxD): 435x195x431mm

(17.1”x7.7”x17”)

SUPPLIED ACCESSORIES

Installation and User Manual; AC power cords (EU,

UK and USA) 2m (6.6 ft); Backlit remote control and

batteries

The DLP® logo and DLP® medallion are trademarks of Texas Instruments.

(*) Lamp life: the hours quoted have been measured in a lab under strict test conditions. Lamp life varies depending on usage conditions and the surrounding
